DABL2600D
Gasoline Blower/ Benzines fúvógép
USER'S MANUAL / HASZNÁLATI UTASÍTÁS
www.daewoopowerproducts.com
Manufactured under license of Daewoo International Corporation, Korea
A Daewoo International Corporation, Korea, engedélye alapján gyártva

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DABL2600D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo DABL2600D

Summary of Contents for Daewoo DABL2600D

  • Page 1 DABL2600D Gasoline Blower/ Benzines fúvógép USER’S MANUAL / HASZNÁLATI UTASÍTÁS www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea A Daewoo International Corporation, Korea, engedélye alapján gyártva...

  • Page 2: Table Of Contents

    INDEX 1. INTRODUCTION ................3 2. SAFETY INSTRUCTIONS .............. 3 3. ASSEMBLY ................... 9 4. FILLING FUEL TANK ..............11 5. OPERATION ................12 6. MAINTENANCE ................15 7. TECHNICAL DATA ............... 17 8. EXPLODED VIEW ................ 18 WARRANTY ..................20...

  • Page 3: Introduction

    1. INTRODUCTION Description Blower tube Tube/collector bag connector ON/OFF switch Vacuum tube Trigger Housing of vacuum tube Handle Collector bag Fuel tank Collector bag adaptor Starter throttle control 2. SAFETY INSTRUCTIONS WARNING: For your own safety, please read this manual before at- tempting to operate your new unit.
  • Page 4 READ YOUR USER MANUAL THOROUGHLY BEFORE OPERATING YOUR UNIT. - Never allow children, handicapped or inexperienced people to use the machine. Local regulations may restrict the age of the user. - Keep children, bystanders and animals away from the machine when using it (at least 15 meters).
  • Page 5 - Never start the engine in a closed or poorly ventilated room as the exhaust gases can be fatal. - Only operate the machine at reasonable times - not too early in the morning or late at night, when people may be disturbed. - Never use the machine in bad weather or if there is a risk of lightning or thunderstorms.
  • Page 6 - Never attempt to burn spilled fuel. - When replacing, use only replacement parts and accessories recom- mended by the manufacturer. Failure to do so could reduce the efficien- cy of your machine and put you at risk of injury. - Maintain your machine with care, according to the instructions in the “Care &...
  • Page 7 • Always allow the machine to cool before storing. • Replace worn or damaged parts for safety. Use only genuine replacement parts and accessories. • Never attempt to override the interlocked feature of the guard. Residuals risks Even if you use this product in compliance with all safety requirements, potential risks of injury and damage remain.
  • Page 8 Risk of projections! Keep bystanders away Warning: Wear eye and ear protection Guarantee noise emission Attention, hot surface Intended use • This vacuum blower is intended to be used for the vacuuming and the blowing of leaves, dust, and similar little materials. It must not mable material, metal or wood and others dangerous objects.

  • Page 9: Assembly

    prohibited. • Any other use might lead to damage of the appliance, property or personal injury. 3. ASSEMBLY For safety reasons, the product is equipped with safety contactors. It will start only when accessories are installed. It is strictly forbidden to modify safety system installed by the manufac- turer.
  • Page 10 Tighten the two screws to secure the tubes to the machine. VACUUM MODE -Assemble the two suction tubes together. Open the cover on the side of the machine. Insert the suction tube and twist it slightly to lock it. Open the collection bag and insert the adapter into it. Bring out the smaller part through the hole at the end of the bag.

  • Page 11: Filling Fuel Tank

    -Install the collection bag in the machine by inserting the end of the adapter into the connection hole of the collection bag. Tighten the screws to secure the installation. Screws the bag and empty it. Then unscrew the two security screws and remo- ve the adapter.

  • Page 12: Operation

    • Always use extreme care when handling fuel! Fuel is highly • Never attempt to fuel the line trimmer if the fuel system compo- nents are damaged or are leaking. • Never attempt the refuel the engine while it is running or still warm, allow it to cool before fueling.
  • Page 13 Move the ON/OFF switch to the ON position (I). Move the throttle control to the idle position Move the choke lever upwards to the start position (cold start). Note. This is not required if the engine is already warm. in and out of the discharge hose located above the fuel tank. Pull the recoil starter 2-3 times until you hear the engine star- ting.
  • Page 14 starter until the engine starts. Allow the engine to run idle for around 10 seconds to let it warm Pull the trigger to start the operation. You can set the throttle control position to lock the trigger in the operating position. To unlock the trigger, pull the throttle control or push the trigger.

  • Page 15: Maintenance

    Inspect the work area before starting. Remove any debris or objects that could be thrown or those that can get caught or obstruct the device. Put the shoulder strap. Hold the handle of the tool and the tube to raise and maintain the machine.
  • Page 16 -Check all nuts, bolts and screws are tight and that the safety devices are properly positioned. -Check if the machine has not suffered damage. If the machine is da- ne and makes repairs. WARNING only original manufacture’s replacement parts, accessories and attachment.

  • Page 17: Technical Data

    7. TECHNICAL DATA Displacement (cc): 25.4 cc Engine type: 2-Stroke Power kW: 0.75 kW/7000r/min Max engine speed: 7500r/min Fuel tank capacity: 450ml AIr speed: 70m/s Gross Weight(KG): 7.5 kg/pc Net Weight(KG): 6.5 kg/pc Sound power level: 94 dB Guaranteed sound power level according to 2004/14/EC: 113 dB Vibration measurement: 3.132 m/s²...

  • Page 18: Exploded View

    8. EXPLODED VIEW...
  • Page 19 NUMBER DESCRIPTION NUMBER DESCRIPTION spark plug cover throttle trigger screw ST5*16 extinguishing switch dust cover starter puller extinguishing switch hull cylinder cover screw ST5*14 screw M4*20 Self-locking switch bushing starter left handle knob Self-locking switch Spring seat screw ST5*16 screw M5*55 shock absorber spring choke iron block screw M6...

  • Page 20: Warranty

    TARTALOM BEVEZETÉS ....................3 ÁLTALÁNOS BIZTONSÁGI UTASÍTÁSOK ..........5 HASZNÁLAT ....................17 TISZTÍTÁS ÉS KARBANTARTÁS ............20 ................... 23 PERSPEKTIVIKUSAN BONTOTT NÉZET ..........24...
  • Page 21 BEVEZETÉS Leírás Fogantyú Indítás BIZTONSÁGI UTASÍTÁSOK...
  • Page 22 ladó távol tárolja.
  • Page 23 – a gépet.
  • Page 24 való •...
  • Page 25 • • • • • • • • •...
  • Page 26 és Rendeltetés • • • • •...
  • Page 27 ÖSSZESZERELÉS – –...
  • Page 28 anyacsavar –...
  • Page 29 – Csavarok AZ ÜZEMANYAGTARTÁLY FELTÖLTÉSE • • • • Csavarja • • artály...
  • Page 30 • • • • • • • • • •...
  • Page 32 Leállítás:...
  • Page 33 KARBANTARTÁS – – – – – A –...
  • Page 34 – – FIGYELMEZTE • • • • • • • • A gyújtógyertyát egy gyújtógyertya- • -re. • • egy gyújtógyertya-...
  • Page 35 Hangteljesítmény szint: 94 dB Garantált hangteljesítmény szint a 2004/14/EC szerint: 113 dB Rezgésgyorsulás: 3,132 m/s² K=1,5 m/s²...
  • Page 36 ROBBANTOTT NÉZET...
  • Page 37 csavar ST5*16 csavar ST5*14 csavar M4*20 csavar ST5*16 csavar M5*55 csavar M6 csavar M5*30 csavar 3*8 csavar M5*12 -alátét csavar M5*25 csavar ST5*16 csavar ST5*16 -alátét csavar M5*22 9*14*32 acélpersely Gyújtógyertya. -alátétje csavar M5*55 csavar M8*1 csavar M4*20 csavar ST5*16 gyújtás csavar ST5*14 csavar ST4*8...
  • Page 38 Jordan, Kowloon, Motor típusa: 1E34F Engedélyezési szám: e9*2016/1628*2016/1628SHA1/P*1189*00 2016/1628/ EU Kézre ható rezgés: 3,132 m/s2 K=1,5 m/s2 Hangteljesítmény szint: LpA: 94,0 dB(A) Bizonytalanság K=3dB(A) Lwa:106,2dB(A) K=3,0 dB(A) Garantált hangteljesítmény szint: 113dB(A)
  • Page 39 Jótállási szelvény Jótállás iránti igény bejelentése: 20__ _____________hó _____ nap A javításra átvétel 20___ _____________hó _____ nap Megjavítva átadták 20___ _____________hó _____ nap Hiba oka: _________________________________________________________________________ A javítás módja: ___________________________________________________________________ Szerviz neve: _____________________________ Munkalap száma: _________________________ ______________________________________________________ jótállás határideje a készülékre: 20___ _____________hó...
  • Page 40 Í LIST Í LIST Poskytujeme záruku 12 Poskytujeme záruku 12 ode dne nákupu (uvedení do provozu), záruka neovliv ode dne nákupu (uvedení do provozu), záruka neovliv vyplývající ze zákona, ani je neomezuje. vyplývající ze zákona, ani je neomezuje. Datum vystavení záru Datum vystavení...
  • Page 41 ITÉ INFORMACE ITÉ INFORMACE Uvedení Uvedení stroje do provozu a jeho nastavení nepat do stroje do provozu a jeho nastavení nepat do ích povinností, tyto služby vykoná servis na ích povinností, tyto služby vykoná servis na Vážený Vážený e, že Vámi zakoupené za e, že Vámi zakoupené...
  • Page 42 Poskytujeme záruku 12 vedenia do prevádzky), záruka Typ a názov spotrebného tovaru: slo: Dátum nákupu: Dátum nahlásenia: ......Nahlásená chyba: ........Dôvod chyby: ..........Výrobné Spôsob opravy: ........: ..............dní. Dátum predaja: ........... (Doba opravy.) d..... m....20 ..(slovom) Termín vrátenia opraveného výrobku: Dátum: ........
  • Page 43 DÔLEŽITÉ INFORMÁCIE Uvedenie prístroja do prevádzky a jeho nastavenie nepatria povinností, tieto služby vykoná servis na základe objednávky zákazníka za príplatok, a to v by sme Vás radi upozornili na (split klimatizácie a plynové nasledujúce Dôležité Informácie! zariadenia), ako aj v uvedenia do prevádzky, ale zákazník si to objedná.
  • Page 44 Manufactured under license of Daewoo International Corporation, Korea A Daewoo International Corporation, Korea, engedélye alapján gyártva...
