- Page 1 DABL7662 Blower USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. SAFETY WARNINGS..........................1 2. DESCRIPTION............................8 3. ADDING FUEL............................9 4. ASSEMBLY.............................10 5. MAINTENANCE............................12 6. USING THE CHAINSAW..........................14 7. MAINTENANCE............................17 8. TECHNICAL DATA..........................21 9. EXPLODED VIEW..........................22 WARRANTY ..............................27... -
Page 3: Safety Warnings
1. SAFETY WARNINGS WARNING: For your own safety, please read this manual before attempting to operate your new unit. Failure to follow instructions can result in serious personal injury. Spend a few moments to familiarize yourself with your blower before each use. If you give this tool to another person, also hand over this manual. - Page 4 and lightning. ORIGINAL INSTRUCTIONS -In case of accident, immediately stop using the machine. Turn the machine off and check the problem. Do not use the machine while the machine is damaged. - If the machine should start making any unusual noise or vibration, immediately shut off the power source and allow the machine to stop.
- Page 5 WARNING: DO NOT ADD, REMOVE OR ALTER ANY COMPONENTS OF THIS PRODUCT. Doing so could cause personal injury and/or damage the unit, voiding the manufacturer’s warranty. DO NOT OPERATE UNIT WHILE TIRED, SICK OR UNDER THE INFLUENCE OF ALCOHOL OR DRUGS. DO NOT operate your unit near or around flammable liquids or gases whether in or out of doors.
- Page 6 Allow the machine to cool before making any inspections, adjustments, etc. Maintain the machi- with care and keep it clean. Store the machine in a dry place out of the reach of children. Always allow the machine to cool before storing. Replace worn or damaged parts for safety.
-
Page 7: Description
Risk of fire Hot surface Risk of inhalation of exhausted gas ORIGINAL INSTRUCTIONS Intended use -This blower is meant to be used for blowing leaves, dust or garden debris into a desired direction. It must not to be used for blowing water, chemical products, flammable material, metal or wood and other dangerous objects. -
Page 8: Assembly
4. ASSEMBLY caution: before performing any work on the blower, always stop the engine and pull the spark plug cap off the spark plug. caution: start the blower only after having assembled it completely. caution: always wear protective gloves. Assembling blower pipes 1. - Page 9 3. Attach the flexible pipe to the elbow -(6). Elbow (7). Hose band 4. Fixez le long tuyau 1 au tuyau pivotant. Tournez-le dans le sens horaire pour le verrouiller en place. Fixez ensuite le deuxième long tuyau. Tournez-le dans le sens horaire pour le verrouiller en place.
- Page 10 WARNING: Exhaust gas from the engine is toxic. Do not operate the engine in a poorlyventilated place, such as in a tunnel, building, etc. Operating the engine in the poorlyventilated place may cause poisoning by exhaust gas. WARNING: In case of detection of any abnormality in sound, odor, vibration after starting, stop the engine immediately and carry out inspection.
- Page 11 ORIGINAL INSTRUCTIONS When the engine is warm (warm start). 1. Put the blower on a flat surface. 2. Push the primer pump several times. 3. Make sure that the choke lever is open. 4. Stump the pedal with your right foot, and hold the top of the unit cover with left hand to prevent the engine from moving.
- Page 12 1. Throttle trigger 2. Stop control lever Transporting the blower CAUTION: When transporting the blower, be sure to stop the engine. NOTE: Open the choke lever fully before pulling the throttle. NOTE: In cold temperature or when the engine is not warm enough, never open the choke lever suddenly.
- Page 13 For tube throttle model: Release the throttle trigger and then set the stop control lever to “O” position. 1. Throttle trigger 2. Stop control lever Adjusting shoulder strap 1. Adjust the shoulder strap to a length that is comfortable to work while carrying the blower. To fasten the strap, pull the end of the strap downwards.
- Page 14 To loosen the strap, pull up the end of the fastener. 1. Fastener ORIGINAL INSTRUCTIONS Hip belt Optional accessory The hip belt enables the operator to carry the tool more stably Adjusting the control lever position For tube throttle model: Move the control handle along the swivel pipe to the most comfortable position.
- Page 15 Blower Operation 1. While operating the blower, adjust the throttle trigger so that the wind force is appropriate for the work location and conditions. 2. Adjusting engine speed. ORIGINAL INSTRUCTIONS For tube throttle model: Engine speed increases by pulling the throttle trigger. To decrease the engine speed, loosen the throttle trigger.
-
Page 16: Maintenance
NOTICE: Do not drag the blower when transporting. Otherwise the blower housing may be damaged. 7. MAINTENANCE CAUTION: Before inspection and maintenance, stop the engine and allow it to cool down. Remove the spark plug and plug cap. Otherwise the operator may suffer burn or serious injury due to an accidental start-up. - Page 17 ORIGINAL INSTRUCTIONS Deteriorated engine oil shortens the life of the sliding and rotating parts to a great extent. Be sure to check the period and quantity of replacement. Interval of replacement After first 20 operating hours, followed by every 50 operating hours Recommended oil •...
- Page 18 CAUTION: Do not touch the spark plug while the engine is running. Otherwise electrical shock may result. CAUTION: Set the stop control lever/stop switch to OFF “O” position. CAUTION: Check the spark plug cord regularly. If it is dam- aged or torn, replace it. Otherwise electrical shock may result.
- Page 19 4. The appropriate clearance between two electrodes of spark plug is 0.7 to 0.8 mm (0.028 to 0.031). Adjust to the correct clearance when it is too wide or too narrow. Clean thoroughly or replace the spark plug if it has accumulated car- bon or contaminated. ORIGINAL INSTRUCTIONS Cleaning the fuel filter CAUTION: Make sure there is no damage on the fuel tank.
-
Page 20: Maintenance
NOTICE: Replace the fuel filter if it is excessively contaminated. After checking, cleaning or replacing, insert the fuel filter into the fuel pipe and fix it with the hose clamp. Reset the fuel filter in the fuel tank and tighten firmly the fuel tank cap. Inspecting bolts, nuts and screws and other parts Retighten loose bolts, nuts, etc. -
Page 21: Technical Data
8. TECHNICAL DATA Engine type: 4 Stroke Power: 2.2 kW Max engine speed: 7000r/min Fuel tank capacity: 2000 ml Oil tank capacity: 300 ml Air speed: 82 m/s Air volume: 950m³/h... -
Page 22: Exploded View
10. EXPLODED VIEW... - Page 24 R i ght depr essi on Fl at w asher 6*16*1. 5 Scr ew M 6*30 N ut M 6 Lef t depr essi on Scr ew M 6*16 D A B L 7662 E ngine spare parts list Item N O . D escription unit Item N O .
- Page 25 Item N O . D escription unit Item N O . D escription unit El bow B ack w i nd cover cl am p 80- 100 N ut M 5 Fl exi bl e pi pe B ase D am pi ng Pr ess pl at e of B ase cl am p 70- 90 D am pi ng...
- Page 26 EC DECLARATION OF CONFORMITY EC Declaration of Conformity Model Name: Gasoline BLOWER Model Code: DABL7662 Brand: Daewoo We GBR Corp. LTD, Room 1002, 10/F., David House, 8-20 Nanking Street, Jordan, Kowloon, Hong Kong, China, declare under our sole responsibility that this product is in conformity and accordance with the following standards and regulations.
-
Page 27: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 2 years for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 28 Manufactured under license of Daewoo International Corporation, Korea...
