- Page 1 DALLB18-1 Lithium Leaf Blower USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. SAFETY INSTRUCTIONS ........................2 2. TECHNICAL DATA ............................ 7 3. DESCRIPTION ............................7 4. ASSEMBLY ............................... 9 5. OPERATION ............................10 6. MAINTENANCE ............................10 7. EXPLODED VIEW AND SPARE PARTS LIST ..................12 EC DECLARATION OF CONFORMITY ..................... 13 WARRANTY ............................... -
Page 3: Safety Instructions
1. SAFETY INSTRUCTIONS Read the enclosed safety warnings, the additional safety warnings and the instructions. Failure to follow the safety warnings and the instructions may result in electric shock, fire and/or serious injury. Save the safety warnings and the instructions for future reference. The following symbols are used in the user manual or on the product: Read the user manual. - Page 4 Do not dispose of the product in unsuitable containers. The product is in accordance with the applicable safety standards in the European directives. GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
- Page 5 c) Prevent unintentional starting. Ensure the switch is in the offposition before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents. d) Remove any adjusting key or wrench before turning the power tool on.
- Page 6 ejected from the battery may cause irritation or burns. e) Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury. d) Bajo condiciones extremas de abuso la batería podría expulsar un líquido; evite todo contacto. Si se produjese contacto accidentalmente, lávese bien con agua.
- Page 7 removed from the power supply. • Only use extension leads that are suitable for outdoor use. The cord must be kept away from excessive heat, oil, solvents and sharp edges. • Periodically check that all bolts and screws are tight. •...
-
Page 8: Technical Data
• The times when the tool is switched off or when it is running but not actually doing the job, may significantly reduce the exposure level. Only use the following batteries of the Daewoo POWER 18 V. Using any other batte -ries could cause serious injury or damage the tool. Model: DALB-20-1. -
Page 10: Assembly
4. ASSEMBLY Before any work on the power tool, remove the battery. The battery must be charged before first use. Inserting the battery into the machine (Fig. A, C) Ensure that the exterior of the battery is clean and dry before connecting to the charger or machine. -
Page 11: Operation
Green LED status Charger status Red LED Status No power Standby mode: - No battery is inserted or, - Battery inserted but charging has finished Battery charging in progress • Fully charging the 2Ah battery may take up to 60 minutes. •... - Page 12 ned with soapsuds. Do not use any solvents such as gasoline, alcohol, ammonia, etc. Chemicals such as these will damage the synthetic components. ENVIRONMENT Faulty and/or discarded electrical or electronic apparatus have to be collected at the appro priate recycling locations. Only for EC countries Do not dispose of power tools into domestic waste.
-
Page 13: Exploded View And Spare Parts List
7. EXPLODED VIEW AND SPARE PARTS LIST 1. Dust blowing pipe 2. Machine shell 3. Magnetic ring + wire 4. Motor 5. Motor fixing plate 6. Spring pad 7. Screw 8. Wind leaf 9. Electric resistance 10. Contact piece shelf 11. -
Page 14: Ec Declaration Of Conformity
1.80kg 150mm 410mm 170 mm The DAEWOO Products authorized representative declares that these products described under "technical data" are in compliance with: Machinery Directive (2006/42/EC), Electromagnetic Compatibility Directive (2014/30/EU), EN 55014-1:2017 and EN 55014-2:2015. is herewith confirmed to fulfill all the relevant provisions of - A-weighed sound power level according to 8.6 of EN ISO 3744... -
Page 15: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 2 years for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 16 Manufactured under license of Daewoo International Corporation, Korea...
