Summary of Contents for Daewoo DABL2600
- Page 1 DABL2600 Gasoline leaf Blower USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. NOMENCLATURE ........................... 3 2. SPECIFICATIONS ............................ 3 3. ASSEMBLING THE BLOWER ......................... 4 4. STARTING THE BLOWER ........................9 5. USING THE BLOWER ........................... 11 6. SPARK ARRESTOR MAINTENANCE ....................13 7. TROUBLESHOOTING GUIDE ....................... 16 8. LOW POWER OUTPUT.......................... 17 9. - Page 3 ATTENTION STATEMENTS This manual contains special“attention statements” surrounded by boxes and preceded by the triangular Attention Symbol. WARNING! A statement preceded by the word “WARNING” contains information that should be acted upon to prevent serious bodily injury. CAUTION! A statement preceded by the word “CAUTION” contains information that should be acted upon to prevent machine damage.
-
Page 4: Nomenclature
1. NOMENCLATURE 2. SPECIFICATIONS Engine: 2 stroke, single cylinder, air cooled Displacement: 26 cc Power: 0.75 kW Fuel tank capacity: 680 ml Air flow: 0.13 m³/s Noise: 96 dB (A) -
Page 5: Assembling The Blower
3. ASSEMBLING THE BLOWER Place the blower upright on the ground or on a sturdy work surface. 1. Grasp the straight tube as shown,and push the tube over the blower dischange port and locking pins. 2. Lock the straight tube to the blower discharge port by rotating the tube as shown. 3. - Page 6 CAUTION! Never attempt to mix fuel in the blower fuel tank! Always mix all fuels in a clean,approves container! Some gasoline contain alcohol as an oxy genate! Oxy genated fuels may cause increased engine operating tempatures! Under certain conditions,alcohol - based fuels may also reduce the lubricating qualities of some mixing oils! Never use any fuel containing more than 10% alcohol by volume! When an oxy genated fuel must be used,fuel containing an ether - based oxy genates such as MTBE is to be preferred over alcohol!
- Page 9 IMPORTANT! Mix only enough fuel for your immediate needs! If fuel must be stored longer than 30-days,is should first be treated with a stabilizer or equivalent product! FILLING THE FUEL TANK WARNING! Danger of fire and burn injury! Always use extreme care when handing fuel! Fuel is highly flammable! ...
-
Page 10: Starting The Blower
4. STARTING THE BLOWER WARNING! Danger from rotating impeller! The impeller will rotate whenever the blower is operated! Never operate this blower unless the intake cover and blower tubes are properly installed and in good working order! Danger from thrown dust or debris! Always wear eye protection when operating this machine! Never direct the blower stream toward people or animals. - Page 11 When the engine starts IMPORTANT! For maximum blower performance and operating life,allow the engine to warm before use. 1. Run the engine at idle speed until operating temperature is reached(2 to 3 minutes). 2. As the engine warms open the choke gradually by slowly pushing the choke control in to the fully retracted position.
-
Page 12: Using The Blower
IMPORTANT! Blower tubes and intake cover must be installed while adjusting engine idle! Engine idle speed will also be affected if either the intake cover or blower tubes are blocked, damaged or incorrectly installed! STOPPING THE ENGINE 1. Cool the engine by allowing it to run at idle for 2 to 3 minutes. 2. - Page 13 ROUTINE MAINTENANCE Daily Maintenance - Remove dirt and debris from the blower exterior. - Inspect the engine,tank,and hoses for possible fuel leaks,and repair as necessary. - Inspect the engine cooling fins for accumlations of dirt or debris,and clean as necessary. - Inspect the entire blower for damage,loose or missing components or fastenings,and repair as necessary.
-
Page 14: Spark Arrestor Maintenance
CAUTION！ Never allow dirt or debris to enter the cylinder before! Before removing the spark plug,thoroughly clean the spark plug and cylinder head area! Allow the engine to cool before servicing the spark plug! Cylinder tightening or loosening the spark plug while the engine is hot! Incorrect spark plug installation can result in serious engine damage! EVERY 50 HOURS (move frequently if you note reduced performance) -
Page 16: Troubleshooting Guide
1. Remove the spark plug. 2. Remove three self-tapping screws and two machine screws from the eng-ine cover,and then gently move the engine cover aside. 3. Remove the three spark arrestor retaining screws,then remove the sparkarrestor cover, screen,gasket,and chamber. 4. Use a plastic scraper or wire brush to remove carbon deposits from the arrestor screen,chamber and cover. - Page 17 7. TROUBELSHOOTING GUIDE ENGINE DOES NOT START WHAT TO CHECK POSSIBLE CAUSE REMEDY...
-
Page 18: Low Power Output
8. LOW POWER OUTPUT... -
Page 19: Additional Problems
9. ADDITIONAL PROBLEMS... -
Page 20: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 2 years for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 21 Manufactured under license of Daewoo International Corporation, Korea...
