- Page 1 FO-382, FO-384, FO-388 DIGITAL A/V HDMI SPLITTER N Instruction manual FO-382 FO-384 FO-388...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Controls And Functions Front Panel
DTV/HDTV: 480i, 480p, 576i, 576p, 1080i, 1080p VGA: 604x480, 800x600, 1024x768 and 1920x1200 The range of splitters is formed by the models FO-382, FO-384 and FO-388 which incorporate 2, 4 and 8 HDMI outputs respectively. CONTROLS AND FUNCTIONS FRONT PANEL 1.- OUTPUT: LED output indicators. -
Page 5: Connection And Operating
CONNECTION AND OPERATING 1.- Connect the HDMI signal source to the HDMI input on the splitter. 2.- Then connect the HDMI outputs to each one of the monitors or to another HDMI splitter in order to make a connection in series and increase the number of monitors or the signal distribution distance. 3.- Supply the system using the AC/DC adapter by connecting it to the DC input on the splitter and to the mains. -
Page 6: Specifications
SPECIFICATIONS FO-382 FO-384 FO-388 CHARACTERISTICS Digital A/V HDMI Splitter. Compatible with Full HD 1080p and HDCP 1.0, 1.1. INPUTS 1 gold-plated female HDMI connector OUTPUTS 2 gold-plated female 4 gold-plated female 8 gold-plated female HDMI connectors HDMI connectors HDMI connectors... -
Page 7: Declaration Of Conformity
This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los Consumidores y Usuarios, Real Decreto Legislativo 1/2007 16 Noviembre.
