FONESTAR FO-420HV Manual

FO-420HV
N
HDMI TO VGA CONVERTER
DESCRIPTION
- HDMI to VGA converter.
CONTROLS AND FUNCTIONS
CONNECTION AND OPERATING
- Connect the digital A/V source to the converter's INPUT.
- Connect the VGA output to a projector or to a TV monitor.
- Connect the audio jack output to a mixer, amplifier or
autoamplified loudspeakers.
- Power the converter FO-420HV with the mains adapter provided.
TECHNICAL SPECIFICATIONS
CHARACTERISTICS
INPUTS
OUTPUTS
INDICATORS
INPUT RESOLUTION
OUTPUT RESOLUTION
POWER SUPPLY
DIMENSIONS
This product has been tested and has passed the corresponding quality control prior to being put on the market.
FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods
as expressed in the Spanish law 'La Ley General para la Defensa de los Consumidores y Usuarios, Real Decreto Legislativo 1/2007 16 Noviembre.
The lack of conformity in the first six months after purchase, due to a manufacturing defect, will be rectified with no more than showing the proof of purchase. After six months
FONESTAR reserves the right to demand proof of the product being sold with that problem.
This warranty does not include damage produced by: inappropriate use or negligence, accidents, worn out parts due to use, breakages, burns, spilt liquids or other substances,
excessive humidity, battery deterioration and internal manipulation of the device, the software or its components by unauthorized persons, and in general any use that is unrelated
to the nature and purpose of the product.
If any service is needed during the warranty period because of lack of conformity, please contact the business or distributor where the product was purchased in no more than
2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it.
To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
This document adds information, and never decreases the consumers' rights, which in all cases are protected by the Spanish law 'La Ley General para la Defensa de los
Consumidores y Usuarios, Real Decreto Legislativo 1/2007 16 Noviembre.
1.- POWER: converter LED power indicator.
2.- VGA OUTPUT: received VGA signal output to connect to a monitor or projector,
female D15 connector.
3.- AUDIO OUTPUT: stereo audio output, 3.5 mm jack connector.
4.- HDMI INPUT: digital A/V signal input, HDMI connector.
5.- 5 V DC: power supply input for mains adapter provided.
FO-420HV
HDMI to VGA converter.
Allows connection of a player to a screen or projector with VGA input.
Converts HDMI signal into VGA and stereo audio signal.
Maximum resolution 1080p (1920 x 1080).
Bandwidth 6.75 Gbps.
Compatible with HDCP.
1 gold-plated female HDMI connector
1 VGA
1 audio, 3.5 mm jack
LED power indicator
480p 60 Hz, 720p 50/60 Hz, 1080p 50/60 Hz, 800 x 600 60 Hz, 1024 x 768 60 Hz, 1920 x 1080 60 Hz
640 x 480 60 Hz, 1280 x 720 50/60 Hz, 1920 x 1080 50/60 Hz, 800 x 600 60 Hz, 1024 x 768 60 Hz
5 V DC, 1 A with adapter included
95 x 19 x 59 mm depth
WARRANTY
