- Page 1 D -864 UHF ANTENNA SPLITTER INSTRUCTION MANUAL...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
- Page 3 The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use.
- Page 4 DESCRIPTION - Antenna splitter for 4 UHF wireless system receivers. - It improves the antenna signal reception if the receivers are in racks. - It uses 2 front antennas to distribute the antenna signal to 4 receivers. CONTROLS AND FUNCTIONS FRONT PANEL ANTENNA A/ANTENNA B: LED signal status and A and B input signal amplification indicators.
- Page 5 - Connecting the UHF directional antenna directly with an integrated amplification circuit mod. ADU-823AMP. This antenna is powered via the antenna cable itself with an 8 V signal provided by the DA-864 splitter. - Finally, connect all the devices in the installation to the mains supply.
- Page 6 2. CONNECTION WITH AMPLIFIER AMP-818G - In distances below 100 meters the AMP-818G amplifier is powered through the antenna splitter itself. - In distances over 100 meters the AMP-818G amplifier must be powered by a mains adapter. - 6 -...
- Page 7 Mounts for antenna installation on the front with female TNC - female TNC connectors 10 x 0.5 m cables, male TNC - male TNC, to connect the antenna to the splitter and the device outputs OPTIONAL AMP-818G: antenna amplifier COMPATIBILITY For wireless FONESTAR systems, mods. MSHR-45 and MSHR-46D - 7 -...
- Page 8 2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
