- Page 1 O-528 1 x 8 HDMI SPLITTER INSTRUCTION MANUAL...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
- Page 3 The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use.
- Page 4 DESCRIPTION The FONESTAR HDMI splitter mod. FO-528 allows a signal to be distributed from 1 HDMI input to 8 HDMI outputs simultaneously, store a signal in a buffer and amplify it, allowing cable lengths of 15 or 20 metres to be reached in the best conditions.
- Page 5 CONNECTION AND OPERATING Connect the HDMI signal source to the splitter FO-528 INPUT. Then connect the required OUTPUTS to each of the monitors. Power the splitter with the mains adapter by connecting it to the 5 V DC input and the mains.
- Page 7 2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
- Page 8 www.fonestar.com...
