Alto S12 Service Manual

12-channel mixing console
Hide thumbs Also See for S12:

Advertisement

Table of Contents

Service Manual
Model: S12
(12-CHANNEL MIXING CONSOLE)
www.altoproaudio.com
Version: 1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alto S12

Summary of Contents for Alto S12

  • Page 1 Service Manual Model: S12 (12-CHANNEL MIXING CONSOLE) www.altoproaudio.com Version: 1.2...

  • Page 2: Table Of Contents

    CONTENTS 1. Specification 2. Block Diagram 3. Schematic Diagram 4. Printed Circuit Board 5. Wiring Diagram 6. Test Procedure 7. Electrical Parts List 8. Exploded Views & Mechanical Parts List 9. Notes...

  • Page 3: Specification

    1. SPECIFICATION (S12) 8. TECHNICAL SPECIFICATIONS Mono input channels Microphone input electronically balanced, discrete input configuration Frequency response 10Hz to 55kHz, +/-3dB Distortion (THD&N) 0.005% at +4dBu, 1kHz Gain range 0dB to 60dB(MIC), SNR (Signal Noise Rated) 115dB Line input...

  • Page 4: Block Diagram

    2.Block Diagram...

  • Page 5: Schematic Diagram

    100n 100n 100n 100n 100n 100n 100n 100n 100n 100n 100n TR17 VR53 R121 W50K PGND Titel MAIN INPUT STAGE PCB# S12MN1.PCB Size Model No: Revision ALTO S-12 VER021115 Date: 12-May-2003 Sheet 1 of File: S12MN1.SCH Drawn By: KEVIN LIN.
  • Page 6 C226 C228 C230 C232 C234 C236 C238 C240 C242 C374 100n 100n 100n 100n 100n 100n 100n 100n 100n 100n 100n 100n Titel PCB#S12MN1.PCB Size Model No: Revision ALTO S-12 VER021115 Date: 12-May-2003 Sheet File: S12MN1-2.SCH Drawn By: KEVIN LIN.
  • Page 7 C250 C271 C272 100n 100n 100n 100n 47u/25V 47u/25V 47u/25V C214 R374 PGND PGND PGND PGND -VCC 100n R-METER R342 Titel PCB#S12MN1.PCB Size Model No: Revision ALTO S-12 VER021115 Date: 12-May-2003 Sheet 3 of File: CTRL-R.SCH Drawn By: KEVIN LIN.
  • Page 8 120R CTRL-R-R R162 R118 120R JY-6351G-02-250 JY-6351G-02-250 R122 CTRL-R-L U20B 120R U20A BA15218N Titel BA15218N INPUT STAGE ( CH1-CH4 ) PCB# S12PU2.PCB Size Model No: Revision ALTO S-12 VER020906 Date: 19-Sep-2003 Sheet 1 of File: S12PU2.Sch Drawn By: KEVIN LIN.
  • Page 11 4. PRINTED CIRCUIT DIAGRAM PCB : S12MN1 Top Overlay...
  • Page 12 PCB : S12MN1 Top Layer...
  • Page 13 PCB : S12MN1 Bottom Layer...
  • Page 14 PCB : S12PU2 Top Overlay PCB : S12PU2 Top Layer...
  • Page 15 PCB : S12PU2 Bottom Layer PCB : S12-PU1 Top Overlay PCB : S12-PU1 Bottom Layer...
  • Page 16 PCB : S8PWR Top Overlay PCB : S8PWR Bottom Layer...

  • Page 23: Wiring Diagram

    5. Wiring Diagram...

  • Page 24: Electrical Parts List

    7. Electrical Parts List...
  • Page 40 8. Exploded Views...
  • Page 41 Mechanical Parts List Model No. ALTO S-12 Item No Item Description S-12 PT-S12_230V S-12 P-S12 PU1-DIP...
