  • Page 1 Cat. No. E502-E2-01 F3S-B Series Safety Light Curtain Instruction Manual...
  • Page 3 (1) The F3S-B has not received the type approval provided by Article 44-2 of the Industrial Safety and Health Law of Japan. Therefore, it cannot be used in Japan as a safety device for pressing or shearing machines provided by article 42 of that law.
  • Page 4 Do not install the F3S-B in a location affected by wall reflections (see “2-1 Installation Conditions”). Do not short the output lines to the +24 V line. Doing so will cause the output to be always ON, creating a hazardous situation.
  • Page 5 When using cables with a connector other than the F39-JB series cable, make sure the connector is rated IP54 or higher. The F3S-B will start operating in two seconds after the power is turned ON. Make sure that no op- eration faults will occur in the control system during this time.
  • Page 6 F3S-B PRIOR TO USE Make sure the following items were supplied with each F3S-B, contact your nearest OMRON representative or distributor if any item is missing. F3S-B unit (emitter qty. 1, receiver qty. 1) Mounting brackets (top and bottom) qty. 4...

  • Page 7: Table Of Contents

    Stand-alone type........................15 1-10-2 Series connection types......................15 WIRING and MOUNTING ....................Section 2......16 2-1 Installation Conditions........................16 2-1-1 Detection Zone and Intrusion Path ..................16 2-1-2 Safety Distance........................16 2-1-3 Distance from Reflective Surfaces..................19 2-1-4 How to Prevent Mutual Interference ..................19 2-2 Dimensional Drawings ........................

  • Page 8: Description

    This function keeps the F3S-B in the OFF-state after power ON and every interruption of the detection zone. To reset this condition, 17 VDC to Vs (nominal 24 VDC) must be applied to the Interlock selection input of the emitter for 15 to 2500 ms. Otherwise the OFF-state continues even if nothing interrupts the detection zone.

  • Page 9: Instability Output

    The state of the MPCEs can be checked with the Relay monitoring function. A voltage of 17 VDC to Vs has to be applied to the Relay monitoring input through the NC contacts of the MPCEs when the F3S-B control outputs are in the OFF-state (see “2-3-2 Wiring diagram”). To ensure this logic relation, the MPCEs must be safety approved types, with forcibly guided contacts.

  • Page 10: Detection Zone

    “the Optical-axis line mark above the indicator area” to “the end of the yellow metal case”. Optical-axis line mark The center line for optical axes is indicated by the triangle mark. This position is a reference line for meas- uring safety distance.

  • Page 11: Series Connection Types

    Series connection types have the same character- Protective height istics as a stand-alone types. When the detection zone of the master unit or that of the slave unit is interrupted, the outputs of the master unit go to the OFF-state.

  • Page 12: Ratings And Performance

    Light source Infrared LED (880 nm wavelength). Lifetime: 50,000 hrs. at 25 °C. Effective Within ± 5° for the emitter and receiver at a detection distance of at least 3 m aperture angle according to IEC 61496-2 Operating mode Light ON Two PNP transistor outputs, operational current (load current) 200 mA max., re-...

  • Page 13: Indicators

    IEC 61496-2 TYPE 2 AOPD (Active Opto-electronic Protective Devices) *1 For detailed type names and optical specifications, see “1-9 Table of Types”. *2 Nominal value (Set time). The accuracy is – 0 / + 70% of ON to OFF response time. *3 Only with F3S-B 2P and BM *4 For the 1,050 mm protective height and longer types.

  • Page 14: Table Of Types

    $ Stand-alone or slave unit $ No. of optical axis of the connected slave unit for 25mm optical pitch type : 12, 18, 24, or 30 for 50mm optical pitch type : 06, 09, 12, or 15 for 75mm optical pitch type : 04, 06, 08, or 10...

  • Page 15: Table Of Response Time

    F3S-B227P 1-10-2 Series connection types The following chart shows the response time of combinations of a master unit and a slave unit connected in series. For example, the response time of the combination of F3S-BM122P30 and F3S-BS302 is 30 ms.

  • Page 16: Wiring And Mounting

    Section 2 2-1 Installation Conditions WARNING Do not use the F3S-B on machines that can not be stopped by electrical control in case of an emer- gency. Do not use the F3S-B in flammable or explosive environments. 2-1-1 Detection Zone and Intrusion Path...
  • Page 17 30 mm optical resolution type Substitute K = 2,000 mm/s and C = 8 (d-14 mm) in equation (1) and calculate as shown below. S = 2,000 mm/s x ( Tm + Ts ) + 8 ( d - 14 mm )
  • Page 18 Calculation for intrusion perpendicular to the detection zone 30 mm and 55 mm optical resolution type Substitute K = 1,600 mm/s and Dpf = 3.4 x ( Os – 6.875 mm ) in equation (4) and calculate as shown be- low.

  • Page 19: Distance From Reflective Surfaces

    L x tan 5° = L x 0.087 (m) 2-1-4 How to Prevent Mutual Interference Take action to prevent mutual interference when two or more sensors are installed. The following figures show configurations in which mutual interference may occur. (Incorrect)
  • Page 20 RS-485 Install barriers (Correct) RS-485 RS-485 Keep enough distance between each set of sensors Arrange the sets so that distance between their protective height marks is greater than “D” in the following table. (Correct) (Correct) Receiver 1 Emitter 1 Emitter 2...

  • Page 21: Dimensional Drawings

    F3S-B 122 , B 065 , B 047 ----- F3S-B 182 , B 095 , B 067 ----- F3S-B 242 , B 125 , B 087 ----- F3S-B 302 , B 155 , B 107...
  • Page 22 Full length Mounting hole Intermediate height the sensor with brackets center width mounting bracket position F3S-B 422 , B 215 , B 147 1050 1093 1143.5 1121 560.5 F3S-B 482 , B 245 , B 167 1200 1243 1293.5 1271 635.5...
  • Page 23 F3S-B 122 , B 065 , B 047 F3S-B 182 , B 095 , B 067 F3S-B 242 , B 125 , B 087 F3S-B 302 , B 155 , B 107 F3S-B 362 , B 185 , B 127...
  • Page 24 1. The intermediate bracket and mounting screw holes are only applied to types which have a protective height of 1050 mm or longer. 2. The master unit has an M12 connector on both ends of the sensor (for the extension cable and the se- ries connection cable).

  • Page 25: Mounting Bracket (Top And Bottom)

    Unit: mm 2-2-3 Mounting Plate Only supplied with types which have a protective height of 1050 mm or longer. The mounting plates are only required when the F3S-B is mounted in the rear mounting configuration with the intermediate brackets. 42.74 36.5...

  • Page 26: Mounting Bracket (Intermediate)

    F3S-B 2-2-4 Mounting Bracket (Intermediate) Only supplied with types which have a protective height of 1050 mm or longer. MOUNTING SCREW FOR SENSOR (M6x8) FLAT INTERMEDIATE BRACKET RUBBER U-SHAPED INTERMEDIATE BRACKET FIXING SCREW FOR BRACKET (M4x10) L-SHAPED INTERMEDIATE BRACKET Unit: mm...

  • Page 27: Wiring

    2-3-1 Power Supply Units and Loads WARNING DC power supply units must satisfy all of the conditions below so that the F3S-B can comply with the applicable standards IEC 61496-1, and UL 508. The power supply voltage should be within rating (24 VDC ± 20 %).

  • Page 28: Wiring Diagram

    E1: 24 VDC Power supply S1: External test switch K1, K2: Relay or PLC input to control the dangerous movement of a machine Load: Inductive load with surge suppressor (Note) or resistive load to indicate unstable condition When using Start/restart interlock Function...

  • Page 29: Wiring Procedure

    F3S-B 2-3-3 Wiring Procedure 1. Connect the emitter extension cable (F39-JB A-L optional, gray color outer jacket) to the emitter. (The emitter uses gray color plastic caps.) 2. Connect the receiver extension cable (F39-JB A-D optional, black color outer jacket) to the receiver.

  • Page 30: Adjustment

    There should be no light-interrupting objects in the F3S-B detection zone. 2. Adjust the torsion angle of the emitter while monitoring the indicator on the receiver and locate the point where the ON-state indicator (lit: green) is lit and the Instability indicator (UNSTAB: orange) goes OFF.
  • Page 31 (green) of the receiver will light. 11. % A test rod can be detected at any position in the detection zone. In other words, the OFF-state indi- cator (red) will remain lit and the ON-state indicator (green) will be never lit as long as the test rod is present in the detection zone.

  • Page 32: I/O Circuit

    Yellow Interlock selection input (*1) Blue ON-state OFF-state Instability indicator indicator indicator Brown Green Pink Control output 1 Load Main receiver circuit White Grey Control output 2 Load Yellow Instability Load output Blue *1 See “2-3 Wiring” for wiring information...

  • Page 33: Applications

    KM1, KM2: Electromagnet contactor (with Reinforced insulation) Note: KM1 and KM2 must have reinforced insula- Note: KM1 and KM2 must have reinforced insula- tion between the coil and contacts. tion between the coil and contacts as well as between contacts.

  • Page 34: Maintenance

    6-3 Cleaning If the surface of the F3S-B is extremely dirty, F3S-B will stop activating outputs. In this case, use a clean soft cloth and clean the surface without pressure. Do not use any solvents such as paint thinners, benzene or...

  • Page 35: Accessories (Optional)

    F39-E1 Interface Unit F39-U1E Optional Function Software Contained on one 3.5 Inch floppy disk and runs with Windows 95, Windows 98 or Windows NT Hardware requirements: PC/Laptop Pentium 133 (32 MB for Windows 95, 64 MB for Windows NT )

  • Page 36: Troubleshooting

    TROUBLESHOOTING Section 8 The F3S-B runs internal self-tests after the power is turned ON and while the F3S-B is in normal opera- tion. The external test is also available. If a failure is detected, a corresponding flicker pattern is indicated by the red LED (OFF-state indicator) of the receiver.
  • Page 37 OMRON EUROPE SENSOR BU Carl-Benz-Str.4 71154 Nufringen GERMANY Tel: +49-7032-811-0 / Fax: +49-7032-811-199 OMRON ELECTRONICS, INC. 1 East Commerce Drive, Schaumburg, IL 60173 Authorised Distributor: U.S.A. Tel: +1-847-843-7900 / Fax: +1-847-843-7787 OMRON ASIAPACIFIC PTE. LTD. 83 Clemenceau Avenue, #11-01, UE Square,...
