- Page 1 INSTRUCTION MANUAL Cordless Cutter CC301D Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: CC301D Diamond wheel diameter 85 mm Max. wheel thickness 0.8 mm Max. Cutting depth at 0° bevel 25.5 mm at 45° bevel 16.5 mm Rated speed 1,600 min Rated voltage D.C. 10.8 V - 12 V max Battery cartridge BL1016, BL1021B BL1041B Overall length... - Page 3 Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non- nated battery packs. Use of any other battery skid safety shoes, hard hat, or hearing protection used for When battery pack is not in use, keep it away Prevent unintentional starting.
- Page 4 Do not use damaged wheels. Before each movement at the point of pinching. Abrasive wheels use, inspect the wheels for chips and cracks. may also break under these conditions. If power tool or wheel is dropped, inspect for Kickback is the result of power tool misuse and/or damage or install an undamaged wheel.
-
Page 5: Functional Description
Use of non-genuine Makita batteries, or batteries that tions. Improper storage may damage the wheels. have been altered, may result in the battery bursting SAVE THESE INSTRUCTIONS. also void the Makita warranty for the Makita tool and charger. WARNING: DO NOT let comfort or familiarity... - Page 6 To install the battery cartridge, align the tongue on the Indicator lamps Remaining battery cartridge with the groove in the housing and slip capacity it into place. Insert it all the way until it locks in place with a little click. If you can see the red indicator on the Lighted upper side of the button, it is not locked completely.
- Page 7 Installing or removing diamond wheel CAUTION: Use only the Makita wrench to install or remove the diamond wheel. CAUTION: When installing the diamond wheel, be sure to tighten the bolt securely.
- Page 8 1. Screw A 2. Tank holder 3. Motor housing 4. Notch BE SURE TO TIGHTEN THE HEX BOLT SECURELY. of the band (part of the tank holder) 5. Screw head of the tool Attach the tank on the tank holder so that the tank on the tube end to the mouth of the tank.
-
Page 9: Operation
CAUTION: Do not use the tool with the dia- mond wheel in an upward or sideways position. be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. CAUTION: The wheel for this tool is a wet- type diamond wheel for glass and tile applica- tions. - Page 12 Makita Corporation 885502A928 20160215 www.makita.com...
