Omron E8M Datasheet

Pressure Sensor
E8MS/E8M
Four-channel Pressure Sensor
Offering Versatile Functions and
High Precision Without Errors
• The industry's smallest pressure sensor, compact,
lightweight - ideal for robot arms or other moving
components
• A highly sensitive minute-pressure sensor model de-
tects very small differences in air pressure
• No wiring conduit required - can be located for sens-
ing in small places
• Simple display panel for efficient space-saving,
though, providing large LEDs
• Easy sensitivity adjustment using the teach function
and channel-to-channel copy function
Ordering Information
Sensors
Sensors
E8MS
Positive pressure
Negative pressure
E8M
Minute differential Differential pressure from 0 to 1,000 Pa (0 to 0.145 psi)
pressure sensor
Positive pressure
Negative pressure
Controller
Supply voltage
24 VDC NPN open collector
Note: 1 ch model available.
Accessories (Order Separately)
Sensor I/O Connectors
Applicable type Shape
E8M
E8MS
Note: E8M-A1 does not require the Sensor I/O Connector.
Pin Controller Connector
Shape Model
XS8A-0442
Note: Orders are accepted in multiples of the minimum order unit.
E8MS/E8M
Pressure range
0 to 100 kPa
0 to 1 MPa
0 to -101 kPa
Pressure range
between positive and negative ports
0 to 1 MPa
0 to -101 kPa
Output form Number of sensor inputs
Model Specifications
4-pin connector
E89-M3 (see note)
with 3 m long cable
3-pin connector
E89-M4
with 3 m long cable
Fitting conductors size (mm) Quantity
0.14 to 0.2
Output form
Linear output 1 to 5 V
Output form
Linear output 1 to 5 V
4
2CH
Quantity
Supplied with one XS8A-0442 Pin Controller
1
Connector
Minimum order unit
1 10
Model
E8MS-01
E8MS-10
E8MS-N0
Model
E8M-A1
E8M-10
E8M-N0
Model
K3C-MP8-T1Z
K3C-DP8-T1Z
Remarks
Remarks
E89-M3 and E89-M4 supplied with
one XS8A-0442 each
F-5
