Page 1
AC 2-wire Models E2EZ-X8Y1 Connector Models Model Shape Sensing distance Output specifications Operating status DC 2-wire models (3) and (4) E2EZ-X4D1-M1J pin arrangement DC 2-wire models (1) and (4) Shielded E2EZ-X4D1-M1GJ pin arrangement DC 2-wire models (3) and (4) E2EZ-X8D1-M1J...
Page 2
Sensing Distance vs. Sensing Object E2EZ-X4@ E2EZ-X8@ Mild steel Brass Mild Aluminum steel Brass Aluminum Copper Stainless steel (SUS304) Copper Stainless steel (SUS304) Side length of sensing object d (mm) Side length of sensing object d (mm) D-162 Inductive Sensors...
Page 3
*1. Use within a range where the green indicator is lit. *2. The response frequencies for DC switching are average values measured on condition that the distance between each sensing object is twice as large as the size of the sensing object and the sensing distance set is half of the maximum sensing distance.
Indicator Not lit Note: Terminals A and B are not used. E2EZ-X4D1-M1J Indicator Not lit Note: E2EZ-X4D1-M1GJ The load can be connected to either the +V or the 0-V line. Control output E2EZ-X8D1-M1J (M1GJ) E2EZ-X8D1-M1GJ Pin arrangement Load Main circuit Note: Terminals B and C are not used.
Part B Part A E2EZ-X8@ Note: 1 . The table below shows the tightening torques for part A and part B nuts. In the previous examples, the nut is on the sensor head side Aluminum and Cast Iron Cut Chips (part B) and hence the tightening torque for part B applies.
Page 6
30.5-mm dia. ALL DIMENSIONS SHOWN ARE IN MILLIMETERS. To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527. Cat. No. D028-E2-04-X In the interest of product improvement, specifications are subject to change without notice.
