Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................10 5.
Page 3
• Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down.
Page 4
• Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot. • Do not use the appliance before installing it in the built-in structure. • Do not use a steam cleaner to clean the appliance. •...
means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. • WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance.
Page 6
• Use the correct electricity mains cable. • Set the cooking zone to “off” after each • Do not let the electricity mains cable use. tangle. • Do not put cutlery or saucepan lids on the • Make sure that a shock protection is cooking zones.
• Be careful not to let objects or cookware use abrasive products, abrasive cleaning fall on the appliance. The surface can be pads, solvents or metal objects, unless damaged. otherwise specified. • Do not activate the cooking zones with 2.5 Service empty cookware or without cookware.
Page 8
The window switch has to be installed by an authorised technician. Refer to the installation booklet. Find the video tutorial "How to install your AEG Extractor Hob 70 cm" by typing out the min. min. 500mm full name indicated in the graphic below.
Page 9
Two-phase connection CAUTION! 1. Remove the cable end sleeve from black and brown wires. Connections via contact plugs are 2. Remove a part of the insulation of black forbidden. and brown cable ends. 3. Apply a new end wire sleeve on each CAUTION! wire's end (special tool required).
4. PRODUCT DESCRIPTION 4.1 Product overview Grid Grease filter housing Air duct adapter Grease filter (non-removable) Air duct fitting for the back wall Long life carbon filter Drip tray (under the hood system) 4.2 Cooking surface layout Induction cooking zone Control panel Hood ENGLISH...
Page 11
4.3 Control panel layout 1 12 Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions operate. Sensor Function Description field On / Off To activate and deactivate the appliance. Pause To activate and deactivate the function. Timer To set the function.
5. BEFORE FIRST USE 4. Press to exit. WARNING! Power levels Refer to Safety chapters. Refer to “Technical data” chapter. 5.1 Power limitation CAUTION! Power limitation defines how much power is Make sure that the selected power fits used by the hob in total, within the limits of the house installation fuses.
Page 13
6.6 OptiHeat Control (3 step Residual heat indicator) WARNING! As long as the indicator is visible, there is a risk of burns from residual heat. The induction cooking zones produce the heat necessary for the cooking process directly in the bottom of the cookware. The glass ceramic is heated by the heat of the cookware.
Page 14
To change the time: select the cooking zone • The hood extractor is always available as an electrical load. with and press 6.9 Hood functions To deactivate the function: select the cooking zone with and press . The WARNING! remaining time counts back to 00. Refer to Safety chapters.
Page 15
The hood will react to the heat setting level, 5. To deactivate the function during cooking increasing or decreasing the fan speed level and switch to the manual mode of the accordingly. The indicators above the hood hood, press AUTO. symbol appear.
6.10 Menu structure appears on the rear timer and the value appears on the front timer. To navigate The table shows the basic menu structure. between the settings press on the front User settings timer. To change the setting value press Sym‐...
When the function operates, To deactivate the function: press . Do be used. All other symbols on the control not set any heat setting / hood setting. Press panels are locked. and hold for 3 seconds, until the indicator above the symbol disappears. Deactivate the The function does not stop the timer functions.
Page 18
8.1 Cookware larger than indicated in "Cooking zones specification". Avoid keeping cookware close to the control panel during the cooking session. This might For induction cooking zones a strong impact the functioning of the control electro-magnetic field creates the heat in panel or accidentally activate hob the cookware very quickly.
Page 19
8.3 Öko Timer (Eco Timer) linear. When you increase the heat setting, it is not proportional to the increase of the To save energy, the heater of the cooking consumption of power. It means that a zone deactivates before the count down timer cooking zone with the medium heat setting sounds.
9. CARE AND CLEANING at an acute angle and move the blade on WARNING! the surface. • Remove when the hob is sufficiently Refer to Safety chapters. cool: limescale rings, water rings, fat stains, shiny metallic discoloration. Clean 9.1 General information the hob with a moist cloth and a non- •...
Page 21
The grease filters collect grease, oil, and food remains and prevent them from getting into the hood system. The long life carbon filters , containing active carbon foam, neutralise smoke and cooking smells. Clean the filters regularly and regenerate them periodically: 3.
Page 22
Wash the grease filters and the grease filter housing in the dishwasher on any standard cycle. Depending on the detergent type and the number of dishwasher cycles, some mild discolouration on the mesh may naturally occur. This does 2. Take out the grease filter housing by not affect the performance of the grabbing the protruding handle.
The counter restarts. 4. Press briefly to reset the counter. 10. TROUBLESHOOTING WARNING! Refer to Safety chapters. 10.1 What to do if... Problem Possible cause Remedy You cannot activate or operate The hob is not connected to an elec‐ Check if the hob is correctly connected the hob.
Page 24
Problem Possible cause Remedy The indicator above the symbol Child Safety Device or Lock oper‐ Refer to "Child Safety Device" and ates. "Lock". comes on. The control bar blinks. There is no cookware on the zone or Put cookware on the zone so that it the zone is not fully covered.
Authorised Service Centres are in the guarantee booklet. 11. TECHNICAL DATA 11.1 Rating plate Model NCH74B01AB PNC 949 598 096 00 Typ 67 B4A 01 AD 220 - 240 V / 400 V 2N, 50 Hz Induction 7.35 kW Made in: Germany Ser.Nr.
Page 26
12.3 Product Information and Product Information Sheet for hood according to EU and UK Ecodesign and Energy Labelling Regulations Product Information Sheet Supplier’s name or trade mark Model identifier NCH74B01AB Annual Energy Consumption - AEChood 32.7 kWh/a Energy Efficiency Class Fluid Dynamic Efficiency - FDEhood 32.0...
Additional Information Time increase factor - f Energy Efficiency Index - EEIhood 42.6 Measured air flow rate at best efficiency point - QBEP 286.7 m3/h Measured air pressure at best efficiency point - PBEP Maximum air flow - Qmax 650.0 m3/h Measured electric power input at best efficiency point - WBEP 111.9...
