- Page 1 EN User Manual | Hob NDH74B02CB aeg.com\register...
-
Page 2: Table Of Contents
Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................11 5. -
Page 3: General Safety
• Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. - Page 4 • Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot. • Do not use the appliance before installing it in the built-in structure. • Do not use a steam cleaner to clean the appliance. •...
-
Page 5: Safety Instructions
means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. • WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance. - Page 6 • Use the correct electricity mains cable. • Set the cooking zone to “off” after each • Do not let the electricity mains cable use. tangle. • Do not put cutlery or saucepan lids on the • Make sure that a shock protection is cooking zones.
-
Page 7: Installation
• Be careful not to let objects or cookware use abrasive products, abrasive cleaning fall on the appliance. The surface can be pads, solvents or metal objects, unless damaged. otherwise specified. • Do not activate the cooking zones with 2.5 Service empty cookware or without cookware. -
Page 8: Attaching The Seal
3.3 Attaching the seal Follow the hob connection diagram and the window switch connection diagram (if applicable) presented in the installation booklet and / or the labels under the hob. Only for selected countries In case of exhaust installation a window switch might be required (consult an authorised technician). -
Page 9: Connection Cable
Find the video tutorial "How to install your INTEGRATED INSTALLATION AEG Extractor Hob 70 cm" by typing out the full name indicated in the graphic below. www.youtube.com/electrolux www.youtube.com/aeg How to install your AEG Extractor Hob 70 cm Filter housing assembly... - Page 10 3. Connect the ends of black and brown CAUTION! cables. 4. Apply a new wire end sleeve on the Connections via contact plugs are shared wire's end (special tool required). forbidden. 5. Connect the ends of two blue cables. 6. Apply a new wire end sleeve on the CAUTION! shared wire's end (special tool required).
-
Page 11: Product Description
4. PRODUCT DESCRIPTION 4.1 Product overview Grid Drip tray (under the hood system) Grease filter housing Grease filter (non-removable) Air duct adapter Long life carbon filter (not included in this Air duct fitting for the back wall model) 4.2 Cooking surface layout Induction cooking zone Control panel Hood... -
Page 12: Control Panel Layout
4.3 Control panel layout 1 12 Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions operate. Sensor Function Description field On / Off To activate and deactivate the appliance. Pause To activate and deactivate the function. Timer To set the function. -
Page 13: Before First Use
5. BEFORE FIRST USE 4. Press to exit. WARNING! Power levels Refer to Safety chapters. Refer to “Technical data” chapter. 5.1 Power limitation CAUTION! Power limitation defines how much power is Make sure that the selected power fits used by the hob in total, within the limits of the house installation fuses. -
Page 14: Heat Setting
6.6 OptiHeat Control (3 step Residual heat indicator) WARNING! As long as the indicator is visible, there is a risk of burns from residual heat. The induction cooking zones produce the heat necessary for the cooking process directly in the bottom of the cookware. The glass ceramic is heated by the heat of the cookware. -
Page 15: Minute Minder
To change the time: select the cooking zone • The hood extractor is always available as an electrical load. with and press 6.9 Hood functions To deactivate the function: select the cooking zone with and press . The WARNING! remaining time counts back to 00. Refer to Safety chapters. - Page 16 The hood will react to the heat setting level, 5. To deactivate the function during cooking increasing or decreasing the fan speed level and switch to the manual mode of the accordingly. The indicators above the hood hood, press AUTO. symbol appear.
-
Page 17: Menu Structure
6.10 Menu structure appears on the rear timer and the value appears on the front timer. To navigate The table shows the basic menu structure. between the settings press on the front User settings timer. To change the setting value press Sym‐... -
Page 18: Child Safety Device
When the function operates, To deactivate the function: press . Do be used. All other symbols on the control not set any heat setting / hood setting. Press panels are locked. and hold for 3 seconds, until the indicator above the symbol disappears. Deactivate the The function does not stop the timer functions. -
Page 19: Noises During Operation
8.1 Cookware Steam Vented Lids To further optimize the cooking sessions alongside the hood you can use the special Steam Vented Lids with your cookware. The For induction cooking zones a strong lids are designed to direct the steam electro-magnetic field creates the heat in produced inside the pot towards the hood, the cookware very quickly. -
Page 20: Care And Cleaning
is not proportional to the increase of the consumption of power. It means that a cooking zone with the medium heat setting The data in the table is for guidance only. uses less than a half of its power. Heat setting Use to: Time Hints... -
Page 21: Cleaning The Hob
only as an additional tool for cleaning the to the right. glass after the standard cleaning procedure. WARNING! Do not use knives or any other sharp, metal tools to clean the glass surface. 2. Move the drip tray vertically downwards. 9.2 Cleaning the hob Be careful not to spill the water. - Page 22 • Clean the grease filters as soon as the 3. Reassemble the filtering unit after built-up grease is visible. The cleaning cleaning: frequency depends on the amount of fat a. Place the grease filter housing back and oil used in cooking. It is inside.
-
Page 23: Troubleshooting
10. TROUBLESHOOTING WARNING! Refer to Safety chapters. 10.1 What to do if... Problem Possible cause Remedy You cannot activate or operate The hob is not connected to an elec‐ Check if the hob is correctly connected the hob. trical supply or it is connected incor‐ to the electrical supply. - Page 24 Problem Possible cause Remedy The control bar blinks. There is no cookware on the zone or Put cookware on the zone so that it the zone is not fully covered. fully covers the cooking zone. The cookware is unsuitable. Use cookware suitable for induction hobs.
-
Page 25: Technical Data
11. TECHNICAL DATA 11.1 Rating plate Model NDH74B02CB PNC 949 598 067 00 Typ 67 B4A 01 AD 220 - 240 V / 400 V 2N, 50 Hz Induction 7.35 kW Made in: Germany Ser.Nr....7.35 kW 11.2 Cooking zones specification... - Page 26 12.3 Product Information and Product Information Sheet for hood Product Information Sheet according to (EU) No 65/2014 Supplier’s name or trade mark Model identifier NDH74B02CB Annual Energy Consumption - AEChood 32.7 kWh/a Energy Efficiency Class Fluid Dynamic Efficiency - FDEhood 32.0...
-
Page 27: Environmental Concerns
Measured electric power input at best efficiency point - WBEP 111.9 Nominal power of the lighting system - WL Average illumination of the lighting system on the cooking surface - Emiddle Appliance tested according to: IEC / EN • Increase the fan speed only to get rid of 61591, IEC / EN 60704-1, IEC / EN large amounts of steam or smoke. - Page 28 867379232-A-362023...
