SP2-TGL Series
Open-Frame Panel PC
User's Manual
Manual Rev.:
Revision Date:
Part No:
1.0
Nov. 25, 2022
50M-00092-1000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP2-TGL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADLINK Technology SP2-TGL Series

Summary of Contents for ADLINK Technology SP2-TGL Series

  • Page 1 SP2-TGL Series Open-Frame Panel PC User’s Manual Manual Rev.: Revision Date: Nov. 25, 2022 Part No: 50M-00092-1000...
  • Page 2 Revision History Revision Release Date Description of Change(s) 2022-11-25 Initial release...
  • Page 3 SP2-TGL Series Preface Copyright © 2022 ADLINK Technology Inc. This document contains proprietary information protected by copy- right. All rights are reserved. No part of this manual may be repro- duced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
  • Page 4 California Proposition 65 Warning WARNING: This product can expose you to chemicals including acrylamide, arsenic, benzene, cadmium, Tris(1,3-dichloro-2-propyl) phosphate (TDCPP), 1,4- Dioxane, formaldehyde, lead, DEHP, styrene, DINP, BBP, PVC, and vinyl materials, which are known to the State of California to cause cancer, and acrylamide, benzene, cadmium, lead, mercury, phthalates, toluene, DEHP, DIDP, DnHP, DBP, BBP, PVC, and vinyl materials, which are known to the State of California to cause...

  • Page 5: Table Of Contents

    Features................1 Packing List ................. 2 Optional Accessories ............2 2 Specifications ..............3 SP2-TGL Series Specifications ........... 3 SP2-TGL Series Block Diagram .......... 6 Power................... 7 Mechanical Dimensions............8 Thermal Options ..............11 Adding or Changing Memory ..........14 Installing a WiFi Module.............
  • Page 6 Advanced Menu ..............71 Chipset................92 Security ................101 Boot ................. 102 Save & Exit ..............103 5 Driver & Application Installation ........105 Driver Installation Order ........... 105 Chipset Driver Installation ..........106 Graphics Driver Installation..........107 Ethernet Driver Installation..........108 Management Engine Driver Installation ......

  • Page 7: List Of Tables

    SP2-TGL Series List of Tables Table 2-1: SP2-TGL Series Specifications ........3 Table 2-2: Power Consumption ............7 Table 2-3: Heat Sink Components..........12 Table 3-1: External I/O Legend............27 Table 3-2: COM1 Port Pin Definition..........28 Table 3-3: USB 3.2 Connector Pin Definition........29 Table 3-4: USB 3.0 + USB 2 .0 Connector Pin Definition ....
  • Page 8 This page intentionally left blank. viii List of Tables...

  • Page 9: List Of Figures

    SP2-TGL Series List of Figures Figure 2-1: SP2-TGL Series Block Diagram ........6 Figure 2-2: SP2-10WP-TGL Dimensions ........... 8 Figure 2-3: SP2-15WP-TGL Dimensions ........... 9 Figure 2-4: SP2-21WP-TGL Dimensions ......... 10 Figure 2-5: Active Cooling Heat Sink ..........11 Figure 2-6: Heat Sink Dimensions ........... 12 Figure 2-7: Heat Sink Cable Routing ..........
  • Page 10 Figure 3-29: I2C Connector 1 & 2 Pin Definition ........ 56 Figure 3-30: RTC Battery Wafer Pin Definition ........57 Figure 3-31: DB40 Connector Pin Definition ........57 Figure 3-32: GPIO Connector Pin Definition ........60 Figure 3-33: Nano SIM Connector Pin Definition ....... 62 Figure 3-34: Backup Battery Connector Pin Definition.......

  • Page 11: Introduction

    SP2-TGL Series Introduction 1.1 Overview The SP2-TGL Series open-frame panel PC is based on the ultra- low-power 11th Generation Intel® Core™ i7/i5/i3 and Celeron® processors (formerly Tiger Lake-UP3) featuring flexible IO options. The SP2-TGL is a computing module with powerful computing capabilities and compact size that is easy to integrate with kiosk and panel PC applications.

  • Page 12: Packing List

    1.3 Packing List Before unpacking, check the shipping carton for any damage. If the shipping carton and/or contents are damaged, inform your dealer immediately. Retain the shipping carton and packing mate- rials for inspection. Obtain authorization from your dealer before returning any product to ADLINK.

  • Page 13: Specifications

    1x USB 2.0, Type-A, OCP, 1000mA USB Ports 1x USB 3.2, 5 Gbps, Type-A, OCP, 1600mA 2x USB 3.2, Gen 2, 10 Gbps, Type-A, OCP, 1600mA DisplayPort 1x DP, DP++, supports resolutions up to 5120x3200@60Hz 24bpp Table 2-1: SP2-TGL Series Specifications...
  • Page 14 OP 1 Grms, 5-500Hz w/ SSD, (IEC60068-2-64) Vibration X, Y, Z axes, 60 min/axis OP 20G peak acceleration, 11 ms (IEC60068-2-64) Shock ±X, ±Y, ±Z, 3 shocks/asix IP Rating IP65 front panel Air: ±15kV, Contact: ±8kV Table 2-1: SP2-TGL Series Specifications...
  • Page 15 249.66 x 168.3 x 383.56 x 232.99 x 517.46 x 309.19 x (HxWxD) 64.4 ±2mm 65.1 ±2mm 67.6 ±2mm Weight 2.06 ±0.2kg 3.02 ±0.2kg 4.85 ±0.2kg Panel Mounting Mounting (Optional) VESA mounting (requires optional rear cover) Table 2-1: SP2-TGL Series Specifications...

  • Page 16: Sp2-Tgl Series Block Diagram

    Lite BMC FAN CONN I2C*2 STM32L071RBH HW monitor SMBUS SMBUS eSPI LED Driver Wafer eSPI to LPC ECE1200 Full COM DB-9 SP339E Switch DB40 LPC to UART TMUX6112 NCT5104D Full COM Wafer SP339E wafer Wafer Figure 2-1: SP2-TGL Series Block Diagram...

  • Page 17: Power

    SP2-TGL Series 2.3 Power Power supply options: 84W (12V/7A)  160W (24V/6.67A)  2.3.1 DC Input Options 12V DC (default) or 9-36V DC (optional) input are supported. 2.3.2 Power Consumption Power consumption is based on lab data in which 12V DC is applied and current is measured by the DC power supply.

  • Page 18: Mechanical Dimensions

    2.4 Mechanical Dimensions All dimensions are in millimeters, unless noted. NOTE: NOTE: 2.4.1 SP2-10WP-TGL Dimensions 237.06 16.53 30.53 64.4 4.51 249.66 22.5 217.96 Figure 2-2: SP2-10WP-TGL Dimensions...

  • Page 19: Figure 2-3: Sp2-15Wp-Tgl Dimensions

    SP2-TGL Series 2.4.2 SP2-15WP-TGL Dimensions 370.8 51.4 129.4 65.1 383.56 22.5 345.56 Figure 2-3: SP2-15WP-TGL Dimensions...

  • Page 20: Figure 2-4: Sp2-21Wp-Tgl Dimensions

    2.4.3 SP2-21WP-TGL Dimensions 504.6 164.3 150.3 67.6 517.46 30.2 477.46 37.4 Figure 2-4: SP2-21WP-TGL Dimensions...

  • Page 21: Thermal Options

    SP2-TGL Series 2.5 Thermal Options 2.5.1 Active Cooling Heat Sink Figure 2-5: Active Cooling Heat Sink...

  • Page 22: Table 2-3: Heat Sink Components

    No. Description Part Number Material Dimensions Remarks PCM4988 25x15x0.2mm Heat Sink 32-20614-4000-A0 AL6063 143x90x27.6mm Fan Bracket 34-35121-0000-A0 SGCC 92.4x72x25mm 32-00086-3000-A0 Plastic 60x10mm Axial Fan Table 2-3: Heat Sink Components 2.5.2 Heat Sink Dimensions All dimensions are in millimeters, unless noted. NOTE: NOTE: Figure 2-6: Heat Sink Dimensions...

  • Page 23: Figure 2-7: Heat Sink Cable Routing

    SP2-TGL Series 2.5.3 Heat Sink Cable Routing Heat sink cable routing should avoid high temperature areas as shown. Figure 2-7: Heat Sink Cable Routing Heat sink designation is based on open-frame locations such as a kiosk installation. NOTE: NOTE: For panel PCs, the design will be different.

  • Page 24: Adding Or Changing Memory

    2.6 Adding or Changing Memory Follow these steps to add or change memory modules. 1. Remove the 3 screws that attach the heat sink to the mainboard and remove the heat sink.
  • Page 25 SP2-TGL Series 2. Add or change memory modules to the SODIMM con- nectors as necessary. 3. Reattach the heat sink to the mainboard with the previ- ously removed screws.

  • Page 26: Installing A Wifi Module

    2.7 Installing a WiFi Module Follow these steps to add or change memory modules. 1. Remove the 3 screws that attach the heat sink to the mainboard and remove the heat sink.
  • Page 27 SP2-TGL Series 2. Install the WiFi module. 3. Reattach the heat sink to the mainboard with the previ- ously removed screws. WiFi antennas must be installed on the SP2-TGL Series hous- ing in order for WiFi to function properly. NOTE: NOTE:...

  • Page 28: Installing A 4G/5G Module

    2.8 Installing a 4G/5G Module Follow these steps to add or change memory modules. 1. Remove the 3 screws that attach the heat sink to the mainboard and remove the heat sink.
  • Page 29 SP2-TGL Series 2. Install the 4G/5G module. 3. Reattach the heat sink to the mainboard with the previ- ously removed screws. Antennas must be installed on the SP2-TGL Series housing in order for 4G/5G to function properly. NOTE: NOTE:...

  • Page 30: Mounting

    2.9 Mounting This section includes details for panel and VESA mounting options. Risk of physical injuries and / or property damage: When mounting the device, use the screws to mount the VESA bracket to the rear of the device. Tighten all four screws firmly WARNING: to support the weight of the device.

  • Page 31: Figure 2-8: Sp2-10Wp-Tgl Cutout Dimensions

    SP2-TGL Series 2.9.1 Panel Mounting The SP2-TGL Series can be panel mounted with 14 mounting clips (optional items sold separately). Make sure there is adequate space behind the panel for ventilation, and that the panel material and thickness can support the weight of the device.

  • Page 32: Figure 2-10: Sp2-21Wp-Tgl Cutout Dimensions

    505.6 Figure 2-10: SP2-21WP-TGL Cutout Dimensions Step 2: Attach I/O cables to the device before installing into the panel if rear access will be limited after installation. Step 3: Place the device into the panel cutout.
  • Page 33 SP2-TGL Series Step 4: Insert the mounting clips into the slots on the sides of the device as shown. Hand-tighten the mounting clips with a Phillips- head screwdriver to secure it to the panel. Do not overtighten the clips to avoid damaging the device enclosure.
  • Page 34 2.9.2 VESA Mounting The SP2-TGL Series can be VESA mounted with a rear cover and VESA bracket. (Optional items sold separately.) All I/O ports must face down. NOTE: NOTE: Step 1: Attach the rear cover to the panel PC with the screws sup- plied in the kit.
  • Page 35 SP2-TGL Series Step 2: Attach the VESA bracket to the rear cover with the screws supplied in the kit. VESA Bracket...
  • Page 36 This page intentionally left blank.

  • Page 37: System Layout

    SP2-TGL Series System Layout 3.1 External I/O Connectors The SP2-TGL Series provides the following external I/O connec- tors. Figure 3-1: SP2-TGL SeriesExternal I/O 1x DB-9P COM1 port supports RS-232/422/485 2x USB 3.2 Gen2 (10Gbps) Type-A 1x USB 3.2 Gen1 (5Gbps) Type-A 1x USB 2.0 Type-A...

  • Page 38: Table 3-2: Com1 Port Pin Definition

    3.1.1 COM1 Port Connector The COM1 port is a D-sub 9-pin connector supporting RS-232/ 422/485 modes by BIOS setting. Figure 3-2: COM1 Port Pin Definition Signal RS-232 RS-422 RS-485 COM1_DCD-L_CN DCD# TXD422- 485DATA- COM1_RXD_CN TXD422+ 485DATA+ COM1_TXD_CN RXD422+ COM1_DTR-L_CN DTR# RXD422- COM1_DSR-L_CN DSR#...

  • Page 39: Table 3-3: Usb 3.2 Connector Pin Definition

    SP2-TGL Series 3.1.2 USB 3.2 (10 Gbps) Connector Two USB 3.2 Gen2 (10 Gbps) Type-A connectors with 1600 mAP power and OCP protection are provided compatible with Super- Speed, Hi-Speed, Full-Speed, and Low-Speed USB devices suit- able for USB peripherals.

  • Page 40: Figure 3-4: Usb 3.0 + Usb 2 .0 Connector Pin Definition

    3.1.3 USB 3.0 + USB 2.0 Combo Connector USB 3.0 Gen1 (5 Gbps) Type-A + USB 2.0 Type-A connectors are provided compatible with SuperSpeed, Hi-Speed, Full-Speed, and Low-Speed USB devices suitable for USB peripherals. USB 3.1 connector up to 5Gbps with 1600 mA power and ...

  • Page 41: Table 3-4: Usb 3.0 + Usb 2 .0 Connector Pin Definition

    SP2-TGL Series Signal P_+5V_USB3 CN_U2_P1_N CN_U2_P1_P CN_U3_RX1_N CN_U3_RX1_P CN_U3_TX1_N CN_U3_TX1_P P_+5V_USB2 CN_U2_P2_N CN_U2_P2_P G1 GND G2 GND G3 GND G4 GND Table 3-4: USB 3.0 + USB 2 .0 Connector Pin Definition...

  • Page 42: Table 3-5: Displayport Pin Definition

    3.1.4 DisplayPort Connector One DisplayPort connector, supporting the DP++ standard specifi- cation, can connect to VGA, DVI, HDMI, and DisplayPort with a DisplayPort to VGA adapter cable, DisplayPort to DVI adapter cable, or DisplayPort to HDMI adapter cable, or a DisplayPort cable, with DP1.4 support for resolutions up to 5120 x 3200 at 60Hz.

  • Page 43: Figure 3-6: Ethernet Port And Leds

    SP2-TGL Series 3.1.5 Gigabit Ethernet Port Two 2.5 Gigabit Intel® Ethernet Controller i225 Series (V, IT or LM) RJ45 connectors support up to 1000/100/10 Mbit/s connec- tions. The V version supports up to 2.5GbE (without TSN,  selected for a Standard Operating Temperature SKU) The IT version supports the TSN feature (Linux OS) at max- ...

  • Page 44: Table 3-6: Ethernet Port Pin Definition

    Signal L_GBE1_MDI0_P L_GBE1_MDI0_N L_GBE1_MDI1_P L_GBE1_MDI1_N Cap to GND Cap to GND L_GBE1_MDI2_P L_GBE1_MDI2_N L_GBE1_MDI3_P L_GBE1_MDI3_N L_GBE1_LED1_LINK/ACT-L LINK_ACT_LED L_GBE1_LINK100-L L_GBE1_LINK1000-L Table 3-6: Ethernet Port Pin Definition Color Status Description LAN is connected Active/Link Yellow Blinking LAN is initializing None 10/100 Mbps Speed Green 1000 Mbps...

  • Page 45: Internal I/O Connectors

    SP2-TGL Series 3.2 Internal I/O Connectors Installation of add-on devices must be carried out by ADLINK service personnel only. Users must not disassemble the device themselves. WARNING: L'installation de périphériques complémentaires doit être effec- tuée uniquement par le personnel de service ADLINK. Les util- isateurs ne doivent pas démonter l'appareil eux-mêmes.

  • Page 46: Table 3-8: Mainboard Connector Legend

    Figure 3-8: Mainboard Connectors (Bottom) Power connector Key connector (optional) 2.5” SATA data & power Fan connector Touchscreen Clear CMOS Jumper (JP1501) M.2 3042, B Key for 4G/5G PCIe Gen4 x4 slot M.2 2230, A/E Key for WiFi/BT COM2 wafer Mini DP connector LED wafer USB 3.1 Power (S5/S0) Jumper (JP7)

  • Page 47: Table 3-9: Power Connector Pin Definition

    SP2-TGL Series 3.2.2 Power Connector The 6-pin power connector connects an AC/DC power supply adapter, DC to DC power module and battery, with AT and ATX power modes (AT mode start is controlled by BIOS). Figure 3-9: Power Connector Pin Definition...

  • Page 48: Table 3-10: Sata Data Connector Pin Definition

    3.2.3 SATA Data & Power Connectors The SATA data and power connectors are used to connect an internal 2.5” HDD. Figure 3-10: SATA Data Connector Pin Definition Signal SATA_TX1_P SATA_TX1_N SATA_RX1_N SATA_RX1_P Table 3-10: SATA Data Connector Pin Definition Figure 3-11: SATA Power Connector Pin Definition Signal P_+5V_S0 P_+3V3_S0...

  • Page 49: Table 3-12: Touchscreen Connector Pin Definition

    SP2-TGL Series 3.2.4 Touchscreen Connector The USB 2.0 connector supports a PCAP touchscreen. Figure 3-12: Touchscreen Connector Pin Definition Signal TSC_D+ TSC_D- P5V_U2_TOU Table 3-12: Touchscreen Connector Pin Definition...

  • Page 50: Figure 3-13: M.2 3042 Connector Pin Definition

    3.2.5 M.2 3042 Connector The M.2 B key port supports standard USB3.1 and USB2.0 for 4G/ 5G module. Figure 3-13: M.2 3042 Connector Pin Definition Signal Signal M2B_CONFIG_3 P_+3V3_NGFF_B P_+3V3_NGFF_B FULL_CARD_POWER_OFF U2_USB1_P W_DISABLE1 U2_USB1_N M2B_CONFIG_0 U3_USB1_RX_N_R M2_UIM_RST U3_USB1_RX_P_R M2_UIM_CLK M2_UIM_DATA U3_USB1_TX_N_R P_+3V3_UIM_M2 U3_USB1_TX_P_R...

  • Page 51: Table 3-13: M.2 3042 Connector Pin Definition

    SP2-TGL Series Signal Signal M2_UIM1_DET WWAN_RESET-L M2B_CONFIG_1 P_+3V3_NGFF_B P_+3V3_NGFF_B P_+3V3_NGFF_B M2B_CONFIG_2 Table 3-13: M.2 3042 Connector Pin Definition...

  • Page 52: Figure 3-14: M.2 2230 Connector Pin Definition

    3.2.6 M.2 2230 Connector The M.2 E key port supports standard USB for a WiFi/Bluetooth module. Figure 3-14: M.2 2230 Connector Pin Definition Signal Signal M2B_CONFIG_3 P_+3V3_NGFF_B P_+3V3_NGFF_B FULL_CARD_POWER_OFF U2_USB1_P W_DISABLE1 U2_USB1_N M2B_CONFIG_0 U3_USB1_RX_N_R M2_UIM_RST U3_USB1_RX_P_R M2_UIM_CLK M2_UIM_DATA U3_USB1_TX_N_R P_+3V3_UIM_M2 U3_USB1_TX_P_R...

  • Page 53: Table 3-14: M.2 2230 Connector Pin Definition

    SP2-TGL Series Signal Signal M2B_PLTRST_BUF-L M2_UIM1_DET WWAN_RESET-L M2B_CONFIG_1 P_+3V3_NGFF_B P_+3V3_NGFF_B P_+3V3_NGFF_B M2B_CONFIG_2 Table 3-14: M.2 2230 Connector Pin Definition...

  • Page 54: Table 3-15: Mini Displayport Pin Definition

    3.2.7 Mini DisplayPort Connector Figure 3-15: Mini DisplayPort Pin Definition Signal CON_TCP2_HPD CON_TCP2_TX0_P CON_TCP2_DDC_AUX_SEL CON_TCP2_TX0_N CON_TCP2_TX1_P CON_TCP2_TX3_P CON_TCP2_TX1_N CON_TCP2_TX3_N CON_TCP2_TX2_P CON_TCP2_I2CCLK_AUX_P CON_TCP2_TX2_N CON_TCP2_I2CCLK_AUX_N P_+3V3_DP2 Table 3-15: Mini DisplayPort Pin Definition...

  • Page 55: Table 3-16: Usb 3.1 Power (S5/S0) Jumper (Jp7)

    SP2-TGL Series 3.2.8 USB 3.1 Power (S5/S0) Jumper (JP7) Figure 3-16: USB 3.1 Power (S5/S0) Jumper (JP7) Pin Definition JP7 USB S5/S0 Power +5V_A (Default) +5V_S0 Table 3-16: USB 3.1 Power (S5/S0) Jumper (JP7) 3.2.9 Power & Reset Connector Figure 3-17: Power & Reset Connector Pin Definition...

  • Page 56: Table 3-18: Buzzer Connector Pin Definition

    3.2.10 Buzzer Connector Figure 3-18: Buzzer Connector Pin Definition Signal P_+5V_S0 N40235133 Table 3-18: Buzzer Connector Pin Definition 3.2.11 Mic-in & Line-out Connector The Mic-in/Line-out supports connecting to speakers via cable. Figure 3-19: Mic-in & Line-out Connector Pin Definition Signal CON_MIC1_IN CON_LINE1_OUT_L CON_LINE1_OUT_R...

  • Page 57: Table 3-20: Speaker Connector Pin Definition

    SP2-TGL Series 3.2.12 Speaker Connector The speaker connector supports 2 2x 2W speakers via cable. Figure 3-20: Speaker Connector Pin Definition Signal AMP_L+ AMP_L- AMP_R+ AMP_R- Table 3-20: Speaker Connector Pin Definition 3.2.13 USB 2.0 Connector Figure 3-21: USB 2.0 Connector Pin Definition...

  • Page 58: Table 3-22: Volume & Backlight Control Connector Pin Definition

    3.2.14 Volume & Backlight Control Connector Controls volume and adjusts display brightness. Figure 3-22: Volume & Backlight Control Connector Pin Definition Signal P_+3V3_S0 EC_BTN_33 EC_BTN_34 EC_BTN_35 EC_BTN_36 Table 3-22: Volume & Backlight Control Connector Pin Definition...

  • Page 59: Figure 3-23: Key Connector Pin Definition

    SP2-TGL Series 3.2.15 Key Connector (Optional) The key connector supports 32 physical keys and 5 control keys with the following default values: Directions: ↑, ↓, ←, →  Numbers: 0 to 9  Functions: Enter, ESC, TAB, Backspace, Delete, Clear, ...

  • Page 60: Table 3-23: Key Connector Pin Definition

    Function Function Signal Signal Value Code Value Code P_+3V3_S0 EC_BTN_17 EC_BTN_1 EC_BTN_18 EC_BTN_2 Backspace EC_BTN_19 > EC_BTN_3 Delete EC_BTN_20 < EC_BTN_4 Space EC_BTN_21 EC_BTN_5 Page up EC_BTN_22 EC_BTN_6 Page down EC_BTN_23 EC_BTN_7 EC_BTN_24 EC_BTN_8 EC_BTN_25 EC_BTN_9 EC_BTN_26 EC_BTN_10 EC_BTN_27 EC_BTN_11 EC_BTN_28 EC_BTN_12 EC_BTN_29...

  • Page 61: Table 3-24: Fan Connector Pin Definition

    SP2-TGL Series 3.2.16 Fan Connectors Figure 3-24: Fan Connector Pin Definition Signal FAN_PWR_IN (12V) BMC_FAN0_IN BMC_FAN0_OUT Table 3-24: Fan Connector Pin Definition 3.2.17 Clear CMOS Jumper (JP1501) Under conditions in which the SP2-TGL fails to boot, clearing the BIOS content stored in CMOS and restoring the default settings may be effective.

  • Page 62: Figure 3-26: Pcie Gen4 X4 Connector Pin Definition

    3.2.18 PCIe Gen4 x4 Connectors (Optional) Figure 3-26: PCIe Gen4 x4 Connector Pin Definition Side B Connector Side A Connector Name Description Name Description Hot plug +12V +12 volt power PRSNT#1 presence detect +12V +12 volt power +12V +12 volt power +12V +12 volt power +12V...

  • Page 63: Table 3-26: Pcie Gen4 X4 Connector Pin Definition

    SP2-TGL Series Side B Connector Side A Connector Name Description Name Description SMDAT SMBus data JTAG3 Ground JTAG4 +12V +12V power JTAG5 JTAG1 +TRST# +3.3V +3.3 volt power 3.3Vaux 3.3 volt power +3.3V +3.3 volt power WAKE# Link Reactivation PERST#...

  • Page 64: Table 3-27: Com2 Connector Pin Definition

    3.2.19 COM2 Connector Figure 3-27: COM2 Connector Pin Definition Signal COM2_DCD-L_CN COM2_RXD_CN COM2_TXD_CN COM2_DTR-L_CN COM2_DSR-L_CN COM2_RTS-L_CN COM2_CTS-L_CN COM2_RI-L_CN Table 3-27: COM2 Connector Pin Definition...

  • Page 65: Table 3-28: Led Connector Pin Definition

    SP2-TGL Series 3.2.20 LED Connector The LED connector supports up to 10 LEDs. Figure 3-28: LED Connector Pin Definition Signal CN_STDBY_PWR CN_GP3_LED-L CN_GP2_LED-L CN_GP1_LED-L P_+3V3_A CN_COM2_SOUT_LED_L CN_COM2_SIN_LED_L CN_COM1_SOUT_LED_L CN_COM1_SIN_LED_L CN_SATA_LED-L_R P_+3V3_S0 CN_WDT_LED-L P_+3V3_A Table 3-28: LED Connector Pin Definition...

  • Page 66: Table 3-29: Led Connector Pin Functions

    Pin Function Color Remarks COM Tx for COM 1 LED blinks when COM data is transferring HW control COM Rx for COM 1 LED blinks when COM data is transferring HW control COM Tx for COM 2 LED blinks when COM data is transferring HW control COM Rx for COM 2 LED blinks when COM data is transferring HW control...

  • Page 67: Table 3-31: Rtc Battery Wafer Pin Definition

    SP2-TGL Series 3.2.22 RTC Battery Wafer Figure 3-30: RTC Battery Wafer Pin Definition Signal P_+VCC_RTC_CN_A Table 3-31: RTC Battery Wafer Pin Definition 3.2.23 DB40 Connector This connector is particular useful during carrier design and bring up phase. It offers access to the following critical parts of the mod-...
  • Page 68 Signal POSTWDT_DIS# SUS_S5# SUS_S4# SUS_S3# CB_PWROK CB_RESET# SYS_RESET# PWRBTN# OCD0B OCD0A DATA RESET_IN# FUMD0 RXD6 TXD6 3.3V_A 3.3V_SMC LPC_AD0 LPC_AD1 LPC_AD2 LPC_AD3 LPC_FRAME# CLK33_LPC RST# BIOS_DIS0 3V3_LPC SPI_BIOS_CLK SPI_BIOS_MOSI SPI_BIOS_MISO SPI_BIOS_CS1#...

  • Page 69: Table 3-32: Db40 Connector Pin Definition

    SP2-TGL Series Signal SPI_BIOS_CS0# VCC_SPI_IN Table 3-32: DB40 Connector Pin Definition...

  • Page 70: Table 3-33: Gpio Connector Pin Definition

    3.2.24 GPIO Connector SP2-TGL provides 4 channels of non-isolation digital input and 4 channels of non-isolation digital output circuits. 4-channel Digital Input VIH: 2.9 to 3.3V  VIL: 0 to 0.15V  4-channel Digital Output Output type: open drain N-channel ...

  • Page 71: Table 3-34: Gpio Connector Pin Voltage

    SP2-TGL Series Signal PCH GPIO Default Value Input/Output Voltage Range P_+3V3_S0 VIH: 2.9V VIL: 0.15V GPIO_1 GPP_B3 Output High VOH: 2.211V VOL: 0.55V VIH: 2.9V VIL: 0.15V GPIO_2 GPP_B4 Output Low VOH: 2.211V VOL: 0.55V VIH: 2.9V VIL: 0.15V GPIO_3...

  • Page 72: Table 3-35: Nano Sim Connector Pin Definition

    3.2.25 Nano SIM Card Connector The Nano SIM connector provides 4G/5G communication func- tionality. Figure 3-33: Nano SIM Connector Pin Definition Signal P_+3V3_UIM_M2 M2_UIM_RST M2_UIM_CLK_R M2_UIM1_CD M2_UIM_VPP M2_UIM_DATA Table 3-35: Nano SIM Connector Pin Definition...

  • Page 73: Table 3-36: Backup Battery Connector Pin Definition

    SP2-TGL Series 3.2.26 Backup Battery Connector (Optional) An optional backup battery connector is available. Contact ADLINK to for more information. Figure 3-34: Backup Battery Connector Pin Definition Signal CHG_PWR CHG_SMBCLK CHG_SMBDAT SMB_ALERT-L_R Table 3-36: Backup Battery Connector Pin Definition 3.2.27 M.2 2280 SATA SSD Connector...

  • Page 74: Table 3-37: M.2 2280 Connector Pin Definition

    Signal Signal P_+3V3_S0 P_+3V3_S0 P_+3V3_S0 PCH_DEVSLP0 SATA_RX0_P SATA_RX0_N SATA_TX0_N SATA_TX0_P P_+3V3_S0 P_+3V3_S0 P_+3V3_S0 Table 3-37: M.2 2280 Connector Pin Definition...

  • Page 75: Bios Setup

    SP2-TGL Series BIOS Setup BIOS can be configured via the BIOS Setup Utility that is invoked during BIOS boot phase. The BIOS configuration is kept in NVRAM which is the same hardware part where the BIOS is stored. All settings will remain after the system is powered down.
  • Page 76 Menu Selection Bar The Menu Selection Bar is located at the top of the screen. It displays the top level menus available to the user. Main Menu  Advanced Menu  Chipset Menu  Security Menu  Boot Menu  Save &...

  • Page 77: Menu Structure

    SP2-TGL Series 4.2 Menu Structure This section presents the six primary menus of the BIOS Setup Utility. Use the following tables as a quick reference for the contents of the BIOS Setup Utility. The remainder of this chapter describe the submenus and options for each menu item. The default settings are presented in bold, and the function of each setting is described in the right hand column of the table.
  • Page 78 Boot Save & Exit - Boot Configuration - Save Changes and Exit - UEFI Hard Disk Drive BBS Priorities - Discard Changes and Exit - UEFI NVME Drive BBS Priorities - Save Changes and Reset - UEFI CDROM/DVD Drive BBS Priorities - Discard Changes and Reset - UEFI SD Drive BBS Priorities - Save Options...

  • Page 79: Main Menu

    SP2-TGL Series 4.3 Main Menu This menu provides read-only information about your system and also allows you to set the System Date and Time. Refer to the tables below for details of the submenus and settings. 4.3.1 Main > BIOS Information...
  • Page 80 4.3.3 Main > Board Information Feature Options Description Serial Number Info only Serial Number Manufacturing Date Info only Manufacturing Date Last Repair Date Info only Last Repair Date Runtime Statistics Info only Runtime Statistics Total Runtime Info only Total Runtime Current Runtime Info only Current Runtime...

  • Page 81: Advanced Menu

    SP2-TGL Series 4.4 Advanced Menu This menu contains the settings for most of the user interfaces in the system. 4.4.1 Advanced > CPU Configuration Feature Options Description Type Info only Displays the Processor Type Info only Displays the Processor ID...
  • Page 82 Feature Options Description Package C-State Disabled Package C-State Demotion Demotion Enabled Package C-State \ Disabled Package C-State Un-demotion Un-demotion Enabled DTS SMM Disabled Disabled: ACPI thermal management uses Enabled EC reported temperature values. Critical Temp Reporting (Out Of spec.) 4.4.2 Advanced >...
  • Page 83 SP2-TGL Series Feature Options Description Data format and Color Auto Data format and Color Depth Depth VESA 24 bpp select JEIDA 24 bpp JEIDA/vesa 18 bpp LVDS Output Mode Auto Single/Dual mode select Dual LVDS bus Single LVDS bus DE Polarity...
  • Page 84 Feature Options Description RI Wake Disabled Enables/Disables RI wake Enabled Function. RTC Wake system from Disabled Enables/Disables System Fixed Time wake on alarm event. Dynamic Time Select FixedTime, system will wake on the hr::min::sec specified. Select DynamicTime, System will wake on the current time + Increase minute(s) Wake up hour...
  • Page 85 SP2-TGL Series 4.4.4 Advanced > Power Management > Power Con- sumption Feature Options Description Power Consumption Info only Current Input Current Info only Current Input Current Current Input Power Info only Current Input Power Info only 5VSBY Info only 5VSBY...
  • Page 86 4.4.6 Advanced > System Management > SEMA Fea- tures Feature Options Description SEMA Features Info only Uptime & Power Cycles Counter Info only Uptime & Power Cycles Counter System Restart Event Info only System Restart Event 1024 Bytes User-Flash Info only 1024 Bytes User-Flash Watchdog Info only Watchdog Temperatures...
  • Page 87 SP2-TGL Series 4.4.7 Advanced > System Management > Flags Feature Options Description BMC Flags Info only BMC Flags BIOS Select Info only BIOS Select ATX/AT-Mode Info only ATX/AT-Mode Exception Code Info only Exception Code 4.4.8 Advanced > System Management > SEMA > Tem-...
  • Page 88 4.4.9 Advanced > Watchdog Timer Feature Options Description Power-Up Watchdog Disabled Enbles/Disables the Watchdog Timer Enabled Timeout [Max-Value, The time the Power Up Watchdog Min-Value, Step- should wait until it resets the system. Value] = [0xFFFF, 0x0018, 0x0001] RunTime Watchdog Disabled The RunTime Watchdog resets the Enabled...
  • Page 89 SP2-TGL Series 4.4.11 Advanced > Super IO Configuration > Serial Port 1 Configuration Feature Options Description Serial Port Disabled Enables/Disables the Enabled serial port (COM) Device Settings IO=3F8h; IRQ=4 Change Settings Auto Selects optimal settings IO=3F8h; IRQ=4 for Super IO Device IO=3F8h;...
  • Page 90 4.4.13 Advanced > Super IO Configuration > Serial Port 3 Configuration Feature Options Description Serial Port Disabled Enables/Disables the Enabled serial port (COM) Device Settings Reset Required Change Settings Auto Selects optimal settings IO=3E8h; IRQ=7 for Super IO Device IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 IO=2F8h;...
  • Page 91 SP2-TGL Series 4.4.15 Advanced > Serial Console Redirection Feature Options Description COM0 Console Redirection Disabled Enables/Disables console redirection on Enabled COM0 port. COM1 Console Redirection Disabled Enables/Disables console redirection on Enabled COM1 port. COM2 Console Redirection Disabled Enables/Disables console redirection on Enabled COM2 port.
  • Page 92 Feature Options Description Parity None A parity bit can be sent with the data Even bits to detect some transmission errors. Even: parity bit is 0 if the num of 1's in Mark the data bits is even. Space Odd: parity bit is 0 if num of 1's in the data bits is odd.
  • Page 93 SP2-TGL Series 4.4.17 Advanced > Console Redirection > COM 1 > Con- sole Redirection Settings Feature Options Description Terminal Type VT100 Emulation: VT100Plus ANSI: Extended ASCII character set. VT-UTF8 VT100: ASCII character set. ANSI VT100Plus: Extends VT100 to support color, function keys, etc.
  • Page 94 Feature Options Description Flow Control None Flow control can prevent data loss from Hardware buffer overflow. When sending data, if RTS/CTS the receiving buffers are full, a 'stop' signal can be sent to stop the data flow. Once the buffers are empty, a 'start' signal can be sent to re-start the flow.
  • Page 95 SP2-TGL Series Feature Options Description Parity None A parity bit can be sent with the data Even bits to detect some transmission errors. Even: parity bit is 0 if the num of 1's in Mark the data bits is even.
  • Page 96 4.4.19 Advanced > Console Redirection > COM 3 > Con- sole Redirection Settings Feature Options Description Terminal Type VT100 Emulation: VT100Plus ANSI: Extended ASCII character set. VT-UTF8 VT100: ASCII character set. ANSI VT100Plus: Extends VT100 to support color, function keys, etc. VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes.
  • Page 97 SP2-TGL Series Feature Options Description Flow Control None Flow control can prevent data loss from Hardware buffer overflow. When sending data, if RTS/CTS the receiving buffers are full, a 'stop' signal can be sent to stop the data flow. Once the buffers are empty, a 'start' signal can be sent to re-start the flow.
  • Page 98 4.4.21 Advanced > Trusted Computing > TPM 1.2 Configu- ration Feature Options Description Configuration Info only Security Device Disabled Enables/Disables BIOS support for security Support Enabled device. OS will not show Security Device. TCG EFI protocol and INT1A interface will not be available.
  • Page 99 SP2-TGL Series Feature Options Description TPM Owner Status N/A, reset required TPM Enabled Status N/A, reset required TPM Active Status N/A, reset required TPM Owner Status N/A, reset required 4.4.22 Advanced > TPM 2.0 Configuration Feature Options Description 7.85 Security Device...
  • Page 100 Feature Options Description Pending operation None Schedule an Operation for the Security TPM Clear Device. NOTE: Your Computer will reboot during restart in order to change State of Security Device. Platform Hierarchy Disabled Enables/Disables Platform Hierarchy Enabled Storage Hierarchy Disabled Enables/Disables Storage Hierarchy Enabled Endorsement...
  • Page 101 SP2-TGL Series Feature Options Description Device reset time-out 10 sec USB mass storage device Start Unit 20 sec command time-out. 30 sec 40 sec Device power-up Auto Maximum time the device will take before it delay Manual properly reports itself to the Host Controller.

  • Page 102: Chipset

    4.5 Chipset 4.5.1 Chipset > System Agent (SA) Configuration Feature Options Description VT-d Supported 4.5.2 Chipset > System Agent (SA) Configuration > Memory Configuration Feature Options Description Memory RC Version Info only Memory Speed Info only Memory Timings Info only (tCL-tRCD-tRP-tRAS) Controller 0 Channel 0 Info only...
  • Page 103 SP2-TGL Series Feature Options Description Max TOLUD Dynamic, 1 GB, Maximum Value of 1.25 GB, 1.5 GB, TOLUD. Dynamic 1.75 GB, 2 GB, 2.25 GB, 2.5 GB, assignment would 2.75 GB, 3 GB, 3.25 GB, 3.5 GB adjust TOLUD automatically based...
  • Page 104 Feature Options Description DVMT Total Gfx Mem 128M DVMT5.0 Total Graphic Memory size 256M used by the Internal Graphics Device. VDD Enable Disabled Enables/Disables forcing of VDD in Enabled the BIOS 4.5.4 Chipset > System Agent (SA) Configuration > VDM Configuration Feature Options...
  • Page 105 SP2-TGL Series Feature Options Description Compliance Test Mode Disabled Enable when using Compliance Enabled Load Board PCIe function swap Disabled When Disabled, prevents PCIE Enabled rootport function swap. If any function other than Oth is enabled, Oth will become visible.
  • Page 106 4.5.6 Chipset > PCH-IO Configuration > PCI Express Configuration Feature Options Description Legacy IO Low Latency Disabled Set to enable low latency of legacy Enabled IO. Some systems require lower IO latency irrespective of power. This is a tradeoff between power and IO latency.
  • Page 107 SP2-TGL Series Feature Options Description SATA Test Mode Disabled Enables/Disables Test Mode Enabled (Loop Back). >Software Feature Mask Configuration Aggressive LPM Support Disabled Enables/Disables PCH to aggressively Enabled enter link power state. SATA Controller Speed Default Indicates the maximum speed the Gen1 SATA controller can support.
  • Page 108 Feature Options Description DITO Configuration Disabled Enables/Disables DITO Configuration Enabled DITO Value DM Value Port 1 Disabled Enables/Disables SATA Port Enabled Hot Plug Disabled Designates this port as Hot Pluggable Enabled Configured as eSATA Hot Plug supported External Disabled Marks this port external. Enabled Spin Up Device Disabled...
  • Page 109 SP2-TGL Series 4.5.8 Chipset > PCH-IO Configuration > USB Configura- tion Feature Options Description xDCI Support Disabled Enables/Disables xDCI Enabled (USB OTG Device). USB2 PHY Sus Well Disabled Select 'Enabled' to enable SUS Well Power Gating Enabled PG for USB2 PHY. This option has no...
  • Page 110 Feature Options Description USB HS Physical Disabled Enables/Disables this USB Physical Connector #8 Enabled Connector (physical port). Once disabled, any USB devices plugged USB HS Physical Disabled into the connector will not be detected Connector #9 Enabled by BIOS or OS. 4.5.9 Chipset >...

  • Page 111: Security

    SP2-TGL Series 4.6 Security Feature Options Description Minimum length Maximum length...

  • Page 112: Boot

    4.7 Boot 4.7.1 Boot > Boot Configuration Feature Options Description Setup Prompt Timeout [Max-Value, Number of seconds to wait for setup Min-Value, activation key. 65535 (0xFFFF ) Step-Value] = means indefinite waiting. [0xFFFF, 0x0001, 0x0001] Bootup NumLock State On Selects the keyboard NumLock state. Quiet Boot Disabled Enables/Disables Quiet Boot option.

  • Page 113: Save & Exit

    SP2-TGL Series 4.8 Save & Exit Feature Options Description Save Changes and Exit Exits system setup after saving the changes. Discard Changes and Exit Exits system setup without saving any changes. Save Changes and Reset Resets the system after saving the changes.
  • Page 114 This page intentionally left blank.

  • Page 115: Driver & Application Installation

    SP2-TGL Series Driver & Application Installation After installing the operating system, all related drivers must be installed for the system to function properly. This section describes the drivers needed for Windows operating systems and the proce- dures to install them. For other operating system support, contact ADLINK for further information.

  • Page 116: Chipset Driver Installation

    5.2 Chipset Driver Installation The chipset driver directs the operating system to configure the Intel® chipset components in order to ensure that the following features function properly: SATA Storage Support  USB Support  Identification of Intel® Chipset Components in the Device ...

  • Page 117: Graphics Driver Installation

    SP2-TGL Series 5.3 Graphics Driver Installation The SP2-TGL is equipped with the Intel® Graphics Media Acceler- ator Driver package, which supports Windows 10 IoT Enterprise. To install the graphics driver: 1. Close any running applications. 2. From ADLINK's website, download Windows 10 IoT Enterprise drivers for the SP2-TGL.

  • Page 118: Ethernet Driver Installation

    5.4 Ethernet Driver Installation To install the driver for the Intel I225 Gigabit Ethernet controller: 1. Close any running applications. 2. From ADLINK's website, download Windows 10 IoT Enterprise drivers for the SP2-TGL. 3. Execute Setup.exe and follow the on-screen instructions to complete the installation.

  • Page 119: Serial I/O Driver Installation

    SP2-TGL Series 5.6 Serial I/O Driver Installation To install the driver for the serial I/O controller: 1. Close any running applications. 2. From ADLINK's website, download Windows 10 IoT Enterprise drivers for the SP2-TGL. 3. Execute Setup.exe and follow the on-screen instructions to complete the installation.
  • Page 120 This page intentionally left blank.

  • Page 121: Important Safety Instructions

    SP2-TGL Series Important Safety Instructions For user safety, please read and follow all instructions, Warnings, Cautions, and Notes marked in this manual and on the associated device before handling/operating the device, to avoid injury or damage. Read these safety instructions carefully.
  • Page 122 A Lithium-type battery may be provided for uninterrupted  backup or emergency power. Risk of explosion if battery is replaced with one of an incorrect type; please dispose of used batteries appropriately. CAUTION: The device must be serviced by authorized technicians when: ...

  • Page 123: Consignes De Sécurité Importante

    SP2-TGL Series Consignes de Sécurité Importante Pour la sécurité de l'utilisateur, veuillez lire et suivre toutes les instructions, avertissements, mises en garde et notes marqués dans ce manuel et sur l'appareil associé avant de manipuler/ d'utiliser l'appareil, afin d'éviter toute blessure ou tout dommage.
  • Page 124 Installez/fixez et utilisez l'appareil uniquement sur des  surfaces stables et/ou sur les fixations recommandées. L'ordinateur Smart Touch est alimenté par un adaptateur  ou une source CC. Veuillez vous assurer que l'adapta- teur ou la source CC doit conserver la connexion à la terre s'il est doté...
  • Page 125 SP2-TGL Series Il est recommandé d'installer l'appareil uniquement dans une  salle de serveurs ou une salle informatique où l'accès est: Réservé au personnel de service qualifié ou aux utilisa-  teurs familiarisés avec les restrictions appliquées à l'emplacement, aux raisons de ces restrictions et toutes les précautions requises...

  • Page 126: Emc Compliance

    EMC Compliance CE Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. FCC Warning This equipment has been tested and found to comply with the lim- its for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 127: Getting Service

    San Jose, CA 95119-1208, USA Tel: +1-408-360-0200 Toll Free: +1-800-966-5200 (USA only) Fax: +1-408-600-1189 Email: info@adlinktech.com ADLINK Technology (China) Co., Ltd. 300 Fang Chun Rd., Zhangjiang Hi-Tech Park Pudong New Area, Shanghai, 201203 China Tel: +86-21-5132-8988 Fax: +86-21-5132-3588 Email: market@adlinktech.com ADLINK Technology GmbH Hans-Thoma-Straße 11...

Table of Contents
