ADLINK Technology SP2-EHL Series User Manual

Open-frame panel pc
Hide thumbs

Advertisement

Quick Links

Download this manual
SP2-EHL Series
Open-Frame Panel PC
User's Manual
Manual Rev.:
Revision Date:
Part No:
1.0
Oct. 16, 2023
50M-P1400-1000

Advertisement

loading
Need help?

Need help?

Do you have a question about the SP2-EHL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADLINK Technology SP2-EHL Series

Summary of Contents for ADLINK Technology SP2-EHL Series

  • Page 1 SP2-EHL Series Open-Frame Panel PC User’s Manual Manual Rev.: Revision Date: Oct. 16, 2023 Part No: 50M-P1400-1000...

  • Page 2: Revision History

    Revision History Revision Release Date Description of Change(s) 2023-10-16 Initial Release...

  • Page 3: Environmental Responsibility

    SP2-EHL Series Preface Copyright © 2023 ADLINK Technology Inc. This document contains proprietary information protected by copy- right. All rights are reserved. No part of this manual may be repro- duced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
  • Page 4 California Proposition 65 Warning WARNING: This product can expose you to chemicals including acrylamide, arsenic, benzene, cadmium, Tris(1,3-dichloro-2-propyl) phosphate (TDCPP), 1,4- Dioxane, formaldehyde, lead, DEHP, styrene, DINP, BBP, PVC, and vinyl materials, which are known to the State of California to cause cancer, and acrylamide, benzene, cadmium, lead, mercury, phthalates, toluene, DEHP, DIDP, DnHP, DBP, BBP, PVC, and vinyl materials, which are known to the State of California to cause...

  • Page 5: Table Of Contents

    Features................1 Packing List ................. 2 Optional Accessories ............2 2 Specifications ..............3 SP2-EHL Series Specifications ........... 3 SP2-EHL Series Block Diagram .......... 6 Power................... 7 Mechanical Dimensions............8 Thermal Options ..............12 3 Getting Started ..............15 Adding or Changing Memory ..........15 Installing a Wi-Fi Module ...........
  • Page 6 6 Driver & Application Installation ........69 Driver Installation Order ............. 69 Important Safety Instructions..........71 Consignes de Sécurité Importante ........73 EMC Compliance ..............76 Getting Service ..............77...

  • Page 7: List Of Tables

    SP2-EHL Series List of Tables Table 2-1: SP2-EHL Series Specifications ........3 Table 2-2: Heat Sink Components..........13 Table 4-1: External I/O Legend............27 Table 4-2: Power Connector Pin Definition........31 Table 4-3: SATA Power Connector Pin Definition ......31 Table 4-4: SATA Data Connector Pin Definition ......
  • Page 8 This page intentionally left blank. viii List of Tables...

  • Page 9: List Of Figures

    SP2-EHL Series List of Figures Figure 2-1: SP2-EHL Series Block Diagram ........6 Figure 2-2: SP2-7WP Dimensions ............. 9 Figure 2-3: SP2-10WP Dimensions ........... 9 Figure 2-4: SP2-15WP Dimensions ..........10 Figure 2-5: SP2-21WP Dimensions ..........11 Figure 2-6: Active Cooling Heat Sink ..........12 Figure 2-7: Heat Sink Dimensions ...........
  • Page 10 Figure 4-24: LAN2 Connector Pin Definition ........49 Figure 4-25: COM2 Connector Pin Definition........50 Figure 4-26: COM1 Connector Pin Definition........51 Figure 4-27: LED Connector Pin Definition ........52 Figure 4-28: I2C Connector-1 Pin Definition ........53 Figure 4-29: I2C Connector-1 Pin Definition ........54 Figure 4-30: RTC Battery Wafer Pin Definition ........

  • Page 11: Introduction

    SP2-EHL Series Introduction 1.1 Overview The SP2-EHL Series open-frame panel PC is based on the ultra- low-power Intel Atom® x6000E series processors (formerly for- merly Elkhart Lake) featuring flexible IO options. The SP2-EHL Series features efficient capabilities and compact size that are easy to integrate with kiosk and panel PC applications.

  • Page 12: Packing List

    Retain the shipping carton and packing mate- rials for inspection. Obtain authorization from your dealer before returning any product to ADLINK. Ensure that the following items are included in the package. 1x SP2-EHL Series Smart Panel  1.4 Optional Accessories Panel-mount clip kit ...

  • Page 13: Specifications

    1x DisplayPort, DP++, supports DP 1.2, resolutions up to 5120x3200@60Hz 24bpp DisplayPort 1x MiniDisplayPort, DP++, supports DP 1.2, resolutions up to 5120x3200@60Hz 24bpp Internal I/O with Wire to Board Connectors USB Port 2x USB 2.0 client, wafer Table 2-1: SP2-EHL Series Specifications...
  • Page 14 EN 55032:2015 + A11:2020; EN 55035:2017 + A11:2020; BS EN 55032:2015 + A11:2020; BS EN 55035:2017 + A11:2020; EMC Certifications AS/NZS CISPR 32:2015 + A1:2020 EN 60601-1-2:2015 + A1:2021; IEC 60601-1-2:2014 + A1:2020 BS EN 60601-1-2:2015 + A1:2021 IEC/EN 61000-3-2, IEC/EN 61000-3-3 Table 2-1: SP2-EHL Series Specifications...
  • Page 15 383.56 x 232.99 517.46 x 309.19 (HxWxD) 54.54 ± 2 64.4 ±2mm x 65.1 ±2mm x 67.6 ±2mm Weight 1.09 ±0.2kg 1.5 ±0.2kg 2.63 ±0.2kg 4.86 ±0.2kg Panel Mounting Mounting (Optional) VESA mounting (requires optional rear cover) Table 2-1: SP2-EHL Series Specifications...

  • Page 16: Sp2-Ehl Series Block Diagram

    CONN PCIe PCIe PCIe switch PCIe PI7C9X2G404SVAFDEEX COM wafer SP339E eSPI 71-00404-02L0 PCIe F81804U-I COM wafer SP339E eSPI to LPC GPIO*32 32 Keypad Wafer F85227N IT8528E-I/FX GPIO*6 DB40 BL/Volume wafer I2C*2 Ambient sensor SMBUS Figure 2-1: SP2-EHL Series Block Diagram...

  • Page 17: Power

    SP2-EHL Series 2.3 Power Power supply options: 60W (12V/5A)  84W (12V/7A)  2.3.1 DC Input Options 12V DC (default) or 9-36V DC (optional) input are supported.

  • Page 18: Mechanical Dimensions

    2.4 Mechanical Dimensions All dimensions are in millimeters, unless noted. NOTE: NOTE: 2.4.1 SP2-7WP Dimensions 216 ± 2 (W) 54.04 ± 2 (D) 182.6 1.74 R4.5 155.21 ± 0.5 (CG VA) 16.7 16.7...

  • Page 19: Figure 2-2: Sp2-7Wp Dimensions

    SP2-EHL Series Figure 2-2: SP2-7WP Dimensions 2.4.2 SP2-10WP Dimensions 237.06 30.53 26.53 249.66 ± 2 (W) 64.4 ± 2 (D) 4.51 217.96 ± 0.2 (CG VA) Figure 2-3: SP2-10WP Dimensions...

  • Page 20: Figure 2-4: Sp2-15Wp Dimensions

    2.4.3 SP2-15WP Dimensions 370.8 61.4 129.4 65.1 ± 2 (D) 383.56 ± 2 (W) 22.5 345.56 ± 0.2 (CG VA) Figure 2-4: SP2-15WP Dimensions...

  • Page 21: Figure 2-5: Sp2-21Wp Dimensions

    SP2-EHL Series 2.4.4 SP2-21WP Dimensions 504.6 155.3 164.3 67.6 ± 2 (D) 517.46 ± 2 (W) 477.46 ± 0.3 (CL VA) 30.2 37.4 Figure 2-5: SP2-21WP Dimensions...

  • Page 22: Thermal Options

    2.5 Thermal Options 2.5.1 Active Cooling Heat Sink Figure 2-6: Active Cooling Heat Sink...

  • Page 23: Table 2-2: Heat Sink Components

    SP2-EHL Series No. Description Part Number Material Dimensions Remarks PCM4988 25x15x0.2mm Heat Sink 32-20614-4000-A0 AL6063 143x90x27.6mm Fan Bracket 34-35121-0000-A0 SGCC 92.4x72x25mm 32-00086-3000-A0 Plastic 60x10mm Axial Fan Table 2-2: Heat Sink Components 2.5.2 Heat Sink Dimensions All dimensions are in millimeters, unless noted.

  • Page 24: Figure 2-8: Cable Routing Considerations For Heat Sinks

    2.5.3 Cable Routing Considerations for Heat Sinks Cable routing should avoid high temperature areas as shown. Figure 2-8: Cable Routing Considerations for Heat Sinks Heat sink design optimized for open-frame installations, such as a kiosk. NOTE: NOTE: For panel PCs, a different design may be required. Consult your ADLINK sales representative for guidance.

  • Page 25: Getting Started

    SP2-EHL Series Getting Started Follow the instructions in this chapter to add or change memory; Wi-Fi modules, mounting brackets, and mounting clips. 3.1 Adding or Changing Memory Follow these steps to add or change memory modules. 1. Remove the 3 screws that attach the heat sink to the...
  • Page 26 2. Install or swap the memory module in the SODIMM socket as necessary. 3. Reattach the heat sink to the mainboard with the previ- ously removed screws.

  • Page 27: Installing A Wi-Fi Module

    SP2-EHL Series 3.2 Installing a Wi-Fi Module Follow these steps to add or change a Wi-Fi modules. In the default configuration, only one PCI slot is available. Choose either a Wi-Fi module or a 4G/5G module. NOTE: NOTE: 1. Remove the 3 screws that attach the heat sink to the...
  • Page 28 2. Install the Wi-Fi module. 3. Reattach the heat sink to the mainboard with the previ- ously removed screws. Wi-Fi antennas must be installed on the SP2-EHL Series hous- ing in order for Wi-Fi to function properly. NOTE: NOTE:...

  • Page 29: Mounting

    SP2-EHL Series 3.3 Mounting This section includes details for panel and VESA mounting options. Risk of physical injuries and / or property damage: When mounting the device, use the screws to mount the VESA bracket to the rear of the device. Tighten all four screws firmly WARNING: to support the weight of the device.

  • Page 30: Panel Mounting

    3.3.1 Panel Mounting The SP2-EHL Series can be panel mounted with 14 mounting clips (optional items sold separately). Make sure there is adequate space behind the panel for ventilation, and that the panel material and thickness can support the weight of the device.

  • Page 31: Figure 3-3: Sp2-15Wp Cutout Dimensions

    SP2-EHL Series 371.8 ± 0.5 Figure 3-3: SP2-15WP Cutout Dimensions 505.6 ± 0.5 Figure 3-4: SP2-21WP Cutout Dimensions Step 2: Attach I/O cables to the device before installing into the panel if rear access will be limited after installation.
  • Page 32 Step 3: Place the device into the panel cutout.
  • Page 33 SP2-EHL Series Step 4: Insert the mounting clips into the slots on the sides of the device as shown. Hand-tighten the mounting clips with a Phillips- head screwdriver to secure it to the panel. Do not overtighten the clips to avoid damaging the device enclosure.

  • Page 34: Figure 3-5: Mounting Clip Dimensions

    +0.3 14.2 -0.1 CROSS_P_NI_M4 16.7 ± 0.3 TAP M4 Figure 3-5: Mounting Clip Dimensions Optional mounting clips sold separately. Contact your ADLINK reseller for details. NOTE: NOTE:...

  • Page 35: Vesa Mounting

    SP2-EHL Series 3.3.2 VESA Mounting The SP2-EHL Series can be VESA mounted with a rear cover and VESA bracket. (Optional items sold separately.) All I/O ports must face down. NOTE: NOTE: Step 1: Attach the rear cover to the panel PC with the screws sup- plied in the kit.
  • Page 36 Step 2: Attach the VESA bracket to the rear cover with 4x M3 screws. VESA Bracket Optional VESA bracket and M3 screws sold separately. Con- tact your ADLINK reseller for details. NOTE: NOTE: Mounting bracket provides 100 mm x 100 mm VESA mounting and requires 4x M4 screws.

  • Page 37: System Layout

    SP2-EHL Series System Layout 4.1 External I/O Connectors The SP2-EHL Series provides the following external I/O connec- tors. Figure 4-1: SP2-EHL Series External I/O A 1x USB 3.1 Gen 1, Type-C B 2x USB 3.2 Gen1 (5Gbps) Type-A C 2x USB 2.0 Type-A...

  • Page 38: Internal I/O Connectors

    4.2 Internal I/O Connectors Installation of add-on devices must be carried out by ADLINK service personnel only. Users must not disassemble the device themselves. WARNING: L'installation de périphériques complémentaires doit être effec- tuée uniquement par le personnel de service ADLINK. Les util- isateurs ne doivent pas démonter l'appareil eux-mêmes.

  • Page 39: Figure 4-3: Mainboard Connectors (Bottom)

    SP2-EHL Series Figure 4-3: Mainboard Connectors (bottom)

  • Page 40: Figure 4-4: Mainboard Connector Legend Mainboard Connectors

    Volume & Backlight Control Power connector Connector SATA Power Connector Key Connector SATA Data Connector Fan Connector Resistive Touch Connector Clear CMOS Jumper Capacitive Touch Connector PoE Module (Optional) Mini PCIe connector COM2 Connector M.2 2230, E Key for Wi-Fi/Bluetooth COM1 Connector Modules Function Module...

  • Page 41: Table 4-2: Power Connector Pin Definition

    SP2-EHL Series Figure 4-5: Power Connector Pin Definition Signal PWR_CONN_IN PWR_CONN_IN PWR_CONN_IN Table 4-2: Power Connector Pin Definition 4.2.3 SATA Power Connector The SATA power connector provides a power connection for an internal 2.5” HDD. Figure 4-6: SATA Power Connector Pin Definition...

  • Page 42: Table 4-4: Sata Data Connector Pin Definition

    4.2.4 SATA Data Connector The SATA data connector provides a data connection for aninter- nal 2.5” HDD. Figure 4-7: SATA Data Connector Pin Definition Signal SATA_TX1_P SATA_TX1_N SATA_RX1_N SATA_RX1_P Table 4-4: SATA Data Connector Pin Definition 4.2.5 Resistive Touch Connector The internal USB 2.0 connector supports a resistive digitizer.

  • Page 43: Table 4-5: Capacitive Touch Connector Pin Definition

    SP2-EHL Series Figure 4-8: Resistive Touch Connector Pin Definition Signal SENSE Resistive Touch Connector Pin Definition 4.2.6 Capacitive Touch Connector The internal USB 2.0 connector supports a capacitive digitizer. Figure 4-9: Capacitive Touch Connector Pin Definition Signal TSC_D+ TSC_D- P5V_U2TOU...

  • Page 44: Figure 4-10: Mini Pcie Connector Pin Definition

    4.2.7 Mini PCIe connector The mini PCIe connector supports standard PCIe signals such as PCIe Gen4 and USB2.0. Figure 4-10: Mini PCIe connector Pin Definition Signal Signal PCIE_WAKE-L P_+3V3_S0_mPCIe TP point TP point P_+1V5_S0_mPCIe PCH_CLK_REQ3-L MPCIE_CLK3_N MPCIE_CLK3_P TP point PLTRST-L_MINIPCIE MPCIE_RX6_N P_+3V3_S0_mPCIe MPCIE_RX6_P...

  • Page 45: Table 4-6: Mini Pcie Connector Pin Definition

    SP2-EHL Series Signal Signal PCH_SMB_CLK_MINI MPCIE_TX6_N_C PCH_SMB_DAT_MINI MPCIE_TX6_P_C USB_MINIPCIE_N USB_MINIPCIE_P P_+3V3_S0_mPCIe P_+3V3_S0_mPCIe TP point P_+1V5_S0_mPCIe P_+3V3_S0_mPCIe Table 4-6: Mini PCIe Connector Pin Definition...

  • Page 46: Figure 4-11: E Key Connector Pin Definition

    4.2.8 M.2 2230, E Key for Wi-Fi/Bluetooth Modules Connects to power, reset button, and power LED via cable. Figure 4-11: E Key Connector Pin Definition Signal Signal P_+3V3_NGFF_E M2E_USB_P P_+3V3_NGFF_E M2E_USB_N...

  • Page 47: Table 4-7: Key Connector Connector Pin Definition

    SP2-EHL Series Signal Signal PCIE2_M2E_TX_P PCIE2_M2E_TX_N PCIE2_RX_P PCIE2_RX_N PCIECLK1_100M_P PCIECLK1_100M_N M2E_PLTRST_BUF-L PCH_CLK_REQ1-L M2_E_PEWAKE_N W_DISABLE1 PCH_SMB_DAT_A PCH_SMB_CLK_A GP_C02_SMB_ALERT- P_+3V3_NGFF_E P_+3V3_NGFF_E Table 4-7: Key Connector Connector Pin Definition...

  • Page 48: Figure 4-12: Function Module Board Connector Pin Definition

    4.2.9 Function Module Board Connector The function module allows customized expandability of the device. Contact your ADLINK representative for details. Figure 4-12: Function Module Board Connector Pin Definition Signal Signal P_+12V_A P_+12V_A P_+12V_A P_+12V_A P_+5V_A P_+5V_A P_+5V_A P_+5V_A P_+3V3_A P_+3V3_A P_+3V3_A P_+3V3_A PCH_SLP_S3-L...
  • Page 49 SP2-EHL Series Signal Signal SW_PCIE_CLK1_P FM_U3_RX1_P SW_PCIE_CLK1_N FM_U3_RX1_N FM_PCIE_RX1_P FM_U2_P1_P FM_PCIE_RX1_N FM_U2_P1_N FM_PCIE_TX1_P FM_U3_TX2_P FM_PCIE_TX1_N FM_U3_TX2_N SW_PCIE_CLK2_P FM_U3_RX2_P SW_PCIE_CLK2_N FM_U3_RX2_N FM_PCIE_RX2_P FM_U2_P2_P FM_PCIE_RX2_N FM_U2_P2_N FM_PCIE_TX2_P FM_U2_P3_P FM_PCIE_TX2_N FM_U2_P3_N SW_PCIE_CLK3_P FM_U2_P4_P SW_PCIE_CLK3_N FM_U2_P4_N FM_PCIE_RX3_P LPC_AD0_R FM_PCIE_RX3_N LPC_AD1_R LPC_AD2_R FM_PCIE_TX3_P LPC_AD3_R FM_PCIE_TX3_N...

  • Page 50: Table 4-8: Function Module Board Connector Pin Definition

    Signal Signal 113 GND 114 I2S1_SFRM 115 FM_DDI1_TX1_P 116 I2S1_SCLK 117 FM_DDI1_TX1_N 118 I2S_MCLK1 119 GND 120 GND 121 FM_DDI1_TX2_P 122 USB_OC2-L_R 123 FM_DDI1_TX2_N 124 USB_OC3-L_R 125 GND 126 GND 127 FM_DDI1_TX3_P 128 FM_GPIO0 129 FM_DDI1_TX3_N 130 FM_GPIO1 131 GND 132 FM_GPIO2 133 FM_DDI1_I2CCLK_AUX_P_CN 134 FM_GPIO3 135 FM_DDI1_I2CDAT_AUX_N_CN 136 FM_GPIO4...

  • Page 51: Table 4-9: Lvds/Edp Connector Pin Definition

    SP2-EHL Series Figure 4-13: LVDS/eDP Connector Pin Definition Signal Signal BLPWR_12V_5V_CN BLPWR_12V_5V_CN LVDS_A2P_1 BLPWR_12V_5V_CN LVDS_A2N_1 BLPWR_12V_5V_CN CN_LVDS_BKLT_PWM 31 LVDS_A1P_1 CN2_LVDS_BKLT_EN LVDS_A1N_1 LVDS_A0P_1 LVDS_A0N_1 Testpoint LVDS_B3P_1 EDP_HPD LVDS_B3N_1 LCD_SEL68_CN G_LVDS_I2C_CLK_CN 40 LVDS_BCKP_1 G_LVDS_I2C_DAT_CN 41 LVDS_BCKN_1 LCD_LVDS_5V LCD_LVDS_5V LVDS_B2P_1 LVDS_B2N_1 LCD_LVDS_3V3 LCD_LVDS_3V3...

  • Page 52: Table 4-10: Power/Reset Button Connector Pin Definition

    4.2.11 Power/Reset/LED Button Connects to power, reset button, and power LED via cable. Figure 4-14: Power/Reset Button Connector Pin Definition Signal P_+3V3_A PWRBTN-L_R SYS_RESET-L_R SIG_PWRLED-L Table 4-10: Power/Reset Button Connector Pin Definition 4.2.12 Buzzer Connector Top View Side View Figure 4-15: Buzzer Connector Pin Definition Signal P_+5V_S0 N40235133...

  • Page 53: Table 4-12: Mic In/Line Out Connector Pin Definition

    SP2-EHL Series 4.2.13 Mic In/Line Out Connector Supports Mic in/line out, connecting to peripherals via cable. Figure 4-16: Mic In/Line Out Connector Pin Definition Signal CON_MIC1_IN CON_LINE1_OUT_L CON_LINE1_OUT_R- LINE1_OUT_JD AGND_AUDIO Table 4-12: Mic In/Line Out Connector Pin Definition 4.2.14 Speaker Connector Supports 2x 2-watt speakers..

  • Page 54: Camera Connector

    4.2.15 Camera Connector This internal USB 2.0 connector facilitates connection of a camera to the device. Figure 4-18: Fan Connector Pin Definition Signal P5V_U2_CAM CN_U2_P8_N CN_U2_P8_P Table 4-14: Fan Connector Pin Definition 4.2.16 USB 2.0 Connector The USB 2.0 wafer facilitates connection of peripherals to the device.

  • Page 55: Table 4-15: Usb 2.0 Connector Pin Definition

    SP2-EHL Series Signal Table 4-15: USB 2.0 Connector Pin Definition 4.2.17 Volume & Backlight Control Connector Controls volume and adjusts display brightness. Figure 4-20: Volume & Backlight Control Connector Pin Definition Signal P_+3V3_S0 EC_BTN_33 EC_BTN_34 EC_BTN_35 EC_BTN_36 Table 4-16: Volume & Backlight Control Connector Pin Definition...

  • Page 56: Figure 4-21: Key Connector Pin Definition

    4.2.18 Key Connector The key connector supports 32 physical keys and 5 control keys with the following default values: Directions: ↑, ↓, ←, →  Numbers: 0 to 9  Functions: Enter, ESC, TAB, Backspace, Delete, Clear,  PageUp, PageDn Hot keys: F1 - F10 ...

  • Page 57: Table 4-17: Key Connector Pin Definition

    SP2-EHL Series Function Function Signal Signal Value Value P_+3V3_S0 EC_BTN_17 Tab EC_BTN_1 ↑ EC_BTN_18 Backspace 6 EC_BTN_2 ↓ EC_BTN_19 Delete EC_BTN_3 → EC_BTN_20 Space EC_BTN_4 ← EC_BTN_21 Page Up EC_BTN_5 EC_BTN_22 Page down 14 EC_BTN_6 EC_BTN_23 F1 EC_BTN_7 EC_BTN_24 F2...

  • Page 58: Table 4-18: Fan Connector Pin Definition

    Figure 4-22: Fan Connector Pin Definition Signal FAN_PWR_IN (12V) SIO_FANIN1_CN SIO_PWM_DAC1_CN Table 4-18: Fan Connector Pin Definition 4.2.20 Clear CMOS Jumper Under conditions in which the device fails to boot, clearing the BIOS content stored in CMOS and restoring the default settings may be effective.

  • Page 59: Table 4-20: Lan2 Connector Pin Definition

    SP2-EHL Series 4.2.21 LAN2 Connector Supports an additional GbE LAN port via cable/dongle. Figure 4-24: LAN2 Connector Pin Definition Signal Signal L_GBE2_MDI2_P_PD L_GBE2_MDI0_P_PD L_GBE2_MDI2_N_PD L_GBE2_MDI0_N_PD L_GBE2_MDI3_P_PD L_GBE2_MDI1_P_PD L_GBE2_MDI3_N_PD L_GBE2_MDI1_N_PD P_+3V3_I226_B P_+3V3_I226_B L_GBE2_LED0_1000-L 16 L_GBE2_LED1_LINK/ACT-L Table 4-20: LAN2 Connector Pin Definition...

  • Page 60: Table 4-21: Com2 Connector Pin Definition

    4.2.22 COM2 Connector Side View Top View Figure 4-25: COM2 Connector Pin Definition Signal RS232 RS422 RS485 COM2_DCD-L_CN DCD# TXD422- 485DATA- COM2_RXD_CN TXD422+ 485DATA+ COM2_TXD_CN RXD422+ NC COM2_DTR-L_CN DTR# RXD422- NC COM2_DSR-L_CN DSR# COM2_RTS-L_CN RTS# COM2_CTS-L_CN CTS# COM2_RI-L_CN Table 4-21: COM2 Connector Pin Definition...

  • Page 61: Table 4-22: Com1 Connector Pin Definition

    SP2-EHL Series 4.2.23 COM1 Connector Side View Top View Figure 4-26: COM1 Connector Pin Definition Signal RS232 RS422 RS485 COM1_DCD-L_CN DCD# TXD422- 485DATA- COM1_RXD_CN TXD422+ 485DATA+ COM1_TXD_CN RXD422+ NC COM1_DTR-L_CN DTR# RXD422- NC COM1_DSR-L_CN DSR# COM1_RTS-L_CN RTS# COM1_CTS-L_CN CTS# COM1_RI-L_CN...

  • Page 62: Table 4-23: Led Connector Pin Definition

    4.2.24 LED Connector The Digital Input/Output is an isolated interface that allows opto- isolated communication with Internet-of-Things devices for high reliability in electrically noisy environments. Side View Top View Figure 4-27: LED Connector Pin Definition Signal Signal COM2_SIN_LED_L STDBY_PWR COM1_SOUT_LED_L GP3_LED-L COM1_SIN_LED_L GP2_LED-L...

  • Page 63: Table 4-24: I2C Connector-1 Pin Definition

    SP2-EHL Series 4.2.25 I²C Connector-1 The I²C (Inter-Integrated Circuit) connector is a robust interface that facilitates low-speed, serial communication between various devices within a compact electronic system, enhancing connectiv- ity and data transmission efficiency. Side View Top View Figure 4-28: I2C Connector-1 Pin Definition...

  • Page 64: Table 4-25: I2C Connector-2 Pin Definition

    4.2.26 I²C Connector-2 The I²C (Inter-Integrated Circuit) connector is a robust interface that facilitates low-speed, serial communication between various devices within a compact electronic system, enhancing connectiv- ity and data transmission efficiency. Side View Top View Figure 4-29: I2C Connector-1 Pin Definition Signal P_+5V_I2C2 P_+3V3_I2C2...

  • Page 65: Rtc Battery Connector

    SP2-EHL Series 4.2.27 RTC Battery Connector The Real Time Clock battery connector allows connection of a backup battery to sustain the system clock in the event of a power outage. Top View Side View Figure 4-30: RTC Battery Wafer Pin Definition...

  • Page 66: Figure 4-31: Db40 Connector Pin Definition

    4.2.28 DB40 Connector This connector is useful during the design and development phase. It offers access to the following critical parts of the module: Test points for measurement of internal power rails  I2C bus for BIOS POST code readout ...

  • Page 67: Table 4-27: Db40 Connector Pin Definition

    SP2-EHL Series Signal Signal DATA SPI_BIOS_MISO RESET_IN# SPI_BIOS_CS1# FUMD0 SPI_BIOS_CS0# RXD6 TXD6 VCC_SPI_IN Table 4-27: DB40 Connector Pin Definition...

  • Page 68: Gpio Connector

    4.2.29 GPIO Connector This device provides 4 channels of non-isolation digital input and 4 channels of non-isolation digital output circuits. 4-channel Digital Input VIH: 2.9 to 3.3V  VIL: 0 to 0.15V  4-channel Digital Output Output type: open drain N-channel ...

  • Page 69: Table 4-28: Gpio Connector Pin Definition

    SP2-EHL Series Figure 4-32: GPIO Connector Pin Definition Signal Name P_+3V3_S0 CN_DI0 CN_DI1 CN_DI2 CN_DI3 CN_DO0 CN_DO1 CN_DO2 CN_DO3 Table 4-28: GPIO Connector Pin Definition Signal PCH GPIO Default Value Input/Output Voltage Range P_+3V3_S0 GPIO_1 GPP_B3 Output High VIH: 2.9V...

  • Page 70: Table 4-30: Ups Pin Definition

    4.2.30 UPS Connector The Uninterruptible Power Supply connector allows the device to interface with a UPS device for backup power in the event of power failure. Top View Side View Figure 4-33: UPS Connector Pin Definition Signal CHG_PWR CHG_SMBCLK CHG_SMBDAT SMB_ALERT-L_R Table 4-30: UPS Pin Definition...

  • Page 71: Figure 4-34: M.2 M Key Connector Pin Definition

    SP2-EHL Series 4.2.31 M.2 M Key Connector The M.2 M key supports an SSD. Side View Top View Figure 4-34: M.2 M Key Connector Pin Definition Signal Signal NGFF_CONFIG3 P_+3V3_NGFF_M P_+3V3_NGFF_M P_+3V3_NGFF_M P_+3V3_NGFF_M P_+3V3_NGFF_M P_+3V3_NGFF_M NGFF_CONFIG0 PCIE5_RX_N PCIE5_RX_P...

  • Page 72: Table 4-31: M.2 M Key Connector Pin Definition

    Signal Signal M2_PCIE5_TX_N M2_PCIE5_TX_P PCH_DEVSLP0 M2_PCIE_SATA_RX_P_R 42 M2_PCIE_SATA_RX_N_R 44 M2_PCIE_SATA_TX_N_R 48 M2_PCIE_SATA_TX_P_R 50 M2M_PLTRST_BUF-L PCH_CLK_REQ3-L PCH_PCIE_M2M_WAKE- C_PCIECLK3_100M_N C_PCIECLK3_100M_P NGFF_CONFIG1 P_+3V3_NGFF_M P_+3V3_NGFF_M P_+3V3_NGFF_M NGFF_CONFIG2 Table 4-31: M.2 M Key Connector Pin Definition...

  • Page 73: Bios Setup

    SP2-EHL Series. Most users do not need to use the BIOS setup program, as the SP2-EHL Series ships with default settings that work well for most configurations. BIOS options used in this manual are for reference only, and are subject to change.
  • Page 74 The default BIOS setup fields are black. The BIOS setup fields currently not used are grey. The display strings are black. Using brackets  Editable menu options are marketed with square brackets, ‘[‘ and ‘]’.

  • Page 75: Adlink Unique Settings

    SP2-EHL Series 5.2 ADLINK Unique settings The SP2-EHL Series follows industry-standard conventions. This section highlights the unique features of the ADLINK BIOS imple- mentation that are unique to ADLINK devices. 5.2.1 Advanced > Panel Configuration Feature Options Description eDP/LVDS Disabled, Enabled...
  • Page 76 Feature Options Description Horizontal-Sync Polarity Active High, Active Low Sync Polarization defines the idle and active states of the sync signal. This setting should be set according to your display requirements. Spreading Depth No Spreading, 0.5%, Clock spreading can 1.0%, 1.5%, 2.0%, 2.5% slightly adjust the exact timing of a clock cycle to reduce electromagnetic...
  • Page 77 SP2-EHL Series 5.2.2 Advanced > Watchdog Timer Feature Options Description BIOS Post Watchdog Disabled The watchdog resets the system Enabled after a specified amount of time has passed. Minutes The number of minutes the watchdog [1-255] should wait until it resets the system in minutes.
  • Page 78 This page intentionally left blank.

  • Page 79: Driver & Application Installation

    SP2-EHL Series Driver & Application Installation After installing the operating system, all related drivers must be installed for the system to function properly. This section describes the drivers needed for Windows operating systems and the proce- dures to install them. For other operating system support, contact ADLINK for further information.
  • Page 80 This page intentionally left blank.

  • Page 81: Important Safety Instructions

    SP2-EHL Series Important Safety Instructions For user safety, please read and follow all instructions, Warnings, Cautions, and Notes marked in this manual and on the associated device before handling/operating the device, to avoid injury or damage. Read these safety instructions carefully.
  • Page 82 A Lithium-type battery may be provided for uninterrupted  backup or emergency power. Risk of explosion if battery is replaced with one of an incorrect type; please dispose of used batteries appropriately. CAUTION: The device must be serviced by authorized technicians when: ...

  • Page 83: Consignes De Sécurité Importante

    SP2-EHL Series Consignes de Sécurité Importante Pour la sécurité de l'utilisateur, veuillez lire et suivre toutes les instructions, avertissements, mises en garde et notes marqués dans ce manuel et sur l'appareil associé avant de manipuler/d'uti- liser l'appareil, afin d'éviter toute blessure ou tout dommage.
  • Page 84 Installez/fixez et utilisez l'appareil uniquement sur des  surfaces stables et/ou sur les fixations recommandées. L'ordinateur Smart Touch est alimenté par un adaptateur  ou une source CC. Veuillez vous assurer que l'adapta- teur ou la source CC doit conserver la connexion à la terre s'il est doté...
  • Page 85 SP2-EHL Series Il est recommandé d'installer l'appareil uniquement dans une  salle de serveurs ou une salle informatique où l'accès est: Réservé au personnel de service qualifié ou aux utilisa-  teurs familiarisés avec les restrictions appliquées à l'emplacement, aux raisons de ces restrictions et toutes les précautions requises...

  • Page 86: Fcc Warning

    EMC Compliance CE Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. FCC Warning This equipment has been tested and found to comply with the lim- its for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 87: Getting Service

    San Jose, CA 95119-1208, USA Tel: +1-408-360-0200 Toll Free: +1-800-966-5200 (USA only) Fax: +1-408-600-1189 Email: info@adlinktech.com ADLINK Technology (China) Co., Ltd. 300 Fang Chun Rd., Zhangjiang Hi-Tech Park Pudong New Area, Shanghai, 201203 China Tel: +86-21-5132-8988 Fax: +86-21-5132-3588 Email: market@adlinktech.com ADLINK Technology GmbH Hans-Thoma-Straße 11...
