ADLINK Technology SP2-KL Series User Manual

Open-frame panel pc
Hide thumbs

Advertisement

Quick Links

Download this manual
SP2-KL Series
Open-Frame Panel PC
User's Manual
Manual Rev.:
Revision Date:
Part No:
1.0
Mar. 2, 2023
50M-00124-1000

Advertisement

loading
Need help?

Need help?

Do you have a question about the SP2-KL Series and is the answer not in the manual?

Questions and answers

Related Manuals for ADLINK Technology SP2-KL Series

Summary of Contents for ADLINK Technology SP2-KL Series

  • Page 1 SP2-KL Series Open-Frame Panel PC User’s Manual Manual Rev.: Revision Date: Mar. 2, 2023 Part No: 50M-00124-1000...

  • Page 2: Revision History

    Revision History Revision Release Date Description of Change(s) 2023-03-02 Initial release...

  • Page 3: Environmental Responsibility

    SP2-KL Series Preface Copyright © 2023 ADLINK Technology Inc. This document contains proprietary information protected by copy- right. All rights are reserved. No part of this manual may be repro- duced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.

  • Page 4: California Proposition 65 Warning

    California Proposition 65 Warning WARNING: This product can expose you to chemicals including acrylamide, arsenic, benzene, cadmium, Tris(1,3-dichloro-2-propyl) phosphate (TDCPP), 1,4- Dioxane, formaldehyde, lead, DEHP, styrene, DINP, BBP, PVC, and vinyl materials, which are known to the State of California to cause cancer, and acrylamide, benzene, cadmium, lead, mercury, phthalates, toluene, DEHP, DIDP, DnHP, DBP, BBP, PVC, and vinyl materials, which are known to the State of California to cause...

  • Page 5: Table Of Contents

    Overview................1 Features................1 Packing List ................. 2 Optional Accessories ............2 2 Specifications ..............3 SP2-KL Series Specifications ..........3 SP2-KL Series Block Diagram..........6 Power................... 7 Mechanical Dimensions............8 Thermal Options ..............11 Adding or Changing Memory ..........14 Installing a Wi-Fi Module ...........
  • Page 6 Advanced Menu ..............73 Chipset................95 Security ................107 Boot ................. 108 Save & Exit ..............111 5 Driver & Application Installation ........113 Driver Installation Order ........... 113 Chipset Driver Installation ..........114 Graphics Driver Installation..........115 Ethernet Driver Installation..........116 Management Engine Driver Installation ......

  • Page 7: List Of Tables

    SP2-KL Series List of Tables Table 2-1: SP2-KL Series Specifications .......... 3 Table 2-2: Heat Sink Components..........12 Table 3-1: External I/O Legend............27 Table 3-2: COM1 Port Pin Definition..........28 Table 3-3: COM2 Port Pin Definition..........29 Table 3-4: USB 3.0 + USB 2.0 Connector Pin Definition ....31 Table 3-5: DisplayPort Pin Definition ..........
  • Page 8 Table 3-37: M.2 2280 Connector Pin Definition ........ 65 viii List of Tables...

  • Page 9: List Of Figures

    Figure 2-8: SP2-10WP-KL Cutout Dimensions........ 21 Figure 2-9: SP2-15WP-KL Cutout Dimensions........ 21 Figure 2-10: SP2-21WP-KL Cutout Dimensions........ 22 Figure 3-1: SP2-KL Series External I/O ........... 27 Figure 3-2: COM1 Port Pin Definition..........28 Figure 3-3: COM2 Port Pin Definition..........29 Figure 3-4: USB 3.0 + USB 2.0 Connector Pin Definition ....
  • Page 10 Figure 3-28: Fan Connector Pin Definition......... 54 Figure 3-29: COM2 Connector Pin Definition........55 Figure 3-30: LED Connector Pin Definition ........56 Figure 3-31: I2C Connector 1 & 2 Pin Definition ........ 57 Figure 3-32: Buzzer Connector Pin Definition........57 Figure 3-33: RTC Battery Wafer Pin Definition ........

  • Page 11: Introduction

    SP2-KL Series Introduction 1.1 Overview The SP2-KL Series open-frame panel PC is based on the ultra- low-power 7th Generation Intel® Core™ i7/i5/i3 processors (for- merly Kaby Lake) featuring flexible IO options. The SP2-KL Series features powerful computing capabilities and compact size that are easy to integrate with kiosk and panel PC applications.

  • Page 12: Packing List

    1.3 Packing List Before unpacking, check the shipping carton for any damage. If the shipping carton and/or contents are damaged, inform your dealer immediately. Retain the shipping carton and packing mate- rials for inspection. Obtain authorization from your dealer before returning any product to ADLINK.

  • Page 13: Specifications

    1x USB 2.0, Type-A, OCP, 1000mA USB Ports 1x USB 3.2, 5 Gbps, Type-A, OCP, 1600mA 1x DisplayPort, DP++, supports DP 1.2, resolutions up to 5120x3200@60Hz 24bpp DisplayPort 1x MiniDisplayPort, DP++, supports DP 1.2, resolutions up to 5120x3200@60Hz 24bpp Table 2-1: SP2-KL Series Specifications...

  • Page 14: Table 2-1: Sp2-Kl Series Specifications

    EMI*: IEC/EN 61000-3-2, IEC/EN 61000-3-3, EN 61000-6-4, EN 55032 EMS*: EN 55035, EN 61000-6-2, EMC*: CE, FCC Class B, IEC 60601-1-2:2014/EN60601-1-2:2015, EMC/Safety UNECE R10, EN 50121-3-2 Compliance Safety*: Compliant with 60601-1/61010-1/62368-1 *SP2-KL has passed pre-compliance testing of EMI, EMS, EMC, and Safety. Table 2-1: SP2-KL Series Specifications...
  • Page 15 249.66 x 168.3 x 383.56 x 232.99 x 517.46 x 309.19 x (HxWxD) 64.4 ±2mm 65.1 ±2mm 67.6 ±2mm Weight 2.06 ±0.2kg 3.02 ±0.2kg 4.85 ±0.2kg Panel Mounting Mounting (Optional) VESA mounting (requires optional rear cover) Table 2-1: SP2-KL Series Specifications...

  • Page 16: Sp2-Kl Series Block Diagram

    Wafer for IOT sensor GPIO*37 Wafer I2C2, I2C3 IT8528 LVDS BL CN SMBUS SLB9665 COM 232/422/485 SP339E COM IC NCT5104D COM 232/422/485 SP339E Thermal sensor *2 SMBUS TI TM4C123 FAN CONN Wafer Buzzer CONN Figure 2-1: SP2-KL Series Block Diagram...

  • Page 17: Power

    SP2-KL Series 2.3 Power Power supply options: 160W (24V/6.67A)  120W (12V/10A)  84W (12V/7A)  2.3.1 DC Input Options 12V DC (default) or 9-36V DC (optional) input are supported.

  • Page 18: Mechanical Dimensions

    2.4 Mechanical Dimensions All dimensions are in millimeters, unless noted. NOTE: NOTE: 2.4.1 SP2-10WP-KL Dimensions 237.06 16.53 30.53 64.4 4.51 249.66 22.5 217.96 Figure 2-2: SP2-10WP-KL Dimensions...

  • Page 19: Figure 2-3: Sp2-15Wp-Kl Dimensions

    SP2-KL Series 2.4.2 SP2-15WP-KL Dimensions 370.8 51.4 129.4 65.1 383.56 22.5 345.56 Figure 2-3: SP2-15WP-KL Dimensions...

  • Page 20: Figure 2-4: Sp2-21Wp-Kl Dimensions

    2.4.3 SP2-21WP-KL Dimensions 504.6 164.3 150.3 67.6 517.46 30.2 477.46 37.4 Figure 2-4: SP2-21WP-KL Dimensions...

  • Page 21: Thermal Options

    SP2-KL Series 2.5 Thermal Options 2.5.1 Active Cooling Heat Sink Figure 2-5: Active Cooling Heat Sink...

  • Page 22: Table 2-2: Heat Sink Components

    No. Description Part Number Material Dimensions Remarks PCM4988 25x15x0.2mm Heat Sink 32-20614-4000-A0 AL6063 143x90x27.6mm Fan Bracket 34-35121-0000-A0 SGCC 92.4x72x25mm 32-00086-3000-A0 Plastic 60x10mm Axial Fan Table 2-2: Heat Sink Components 2.5.2 Heat Sink Dimensions All dimensions are in millimeters, unless noted. NOTE: NOTE: Figure 2-6: Heat Sink Dimensions...

  • Page 23: Figure 2-7: Cable Routing Considerations For Heat Sinks

    SP2-KL Series 2.5.3 Cable Routing Considerations for Heat Sinks Cable routing should avoid high temperature areas as shown. Figure 2-7: Cable Routing Considerations for Heat Sinks Heat sink design optimized for open-frame installations, such as a kiosk. NOTE: NOTE: For panel PCs, a different design may be required. Consult...

  • Page 24: Adding Or Changing Memory

    2.6 Adding or Changing Memory Follow these steps to add or change memory modules. 1. Remove the 3 screws that attach the heat sink to the mainboard and remove the heat sink.
  • Page 25 SP2-KL Series 2. Install or swap the memory module in the SODIMM socket as necessary. 3. Reattach the heat sink to the mainboard with the previ- ously removed screws.

  • Page 26: Installing A Wi-Fi Module

    2.7 Installing a Wi-Fi Module Follow these steps to add or change a Wi-Fi modules. In the default configuration, only one PCI slot is available. Choose either a Wi-Fi module or a 4G/5G module. NOTE: NOTE: 1. Remove the 3 screws that attach the heat sink to the mainboard and remove the heat sink.
  • Page 27 SP2-KL Series 2. Install the Wi-Fi module. 3. Reattach the heat sink to the mainboard with the previ- ously removed screws. Wi-Fi antennas must be installed on the SP2-KL Series hous- ing in order for Wi-Fi to function properly. NOTE: NOTE:...

  • Page 28: Installing A 4G/5G Module

    2.8 Installing a 4G/5G Module Follow these steps to add or change 4G/5G modules. In the default configuration, only one PCI slot is available. Choose either a WiFi module or a 4G/5G module. NOTE: NOTE: 1. Remove the 3 screws that attach the heat sink to the mainboard and remove the heat sink.
  • Page 29 SP2-KL Series 2. Install the 4G/5G module. 3. Reattach the heat sink to the mainboard with the previ- ously removed screws. Antennas must be installed on the SP2-KL Series housing in order for 4G/5G to function properly. NOTE: NOTE:...

  • Page 30: Mounting

    2.9 Mounting This section includes details for panel and VESA mounting options. Risk of physical injuries and / or property damage: When mounting the device, use the screws to mount the VESA bracket to the rear of the device. Tighten all four screws firmly WARNING: to support the weight of the device.

  • Page 31: Panel Mounting

    SP2-KL Series 2.9.1 Panel Mounting The SP2-KL Series can be panel mounted with 14 mounting clips (optional items sold separately). Make sure there is adequate space behind the panel for ventilation, and that the panel material and thickness can support the weight of the device.

  • Page 32: Figure 2-10: Sp2-21Wp-Kl Cutout Dimensions

    505.6 Figure 2-10: SP2-21WP-KL Cutout Dimensions Step 2: Attach I/O cables to the device before installing into the panel if rear access will be limited after installation. Step 3: Place the device into the panel cutout.
  • Page 33 SP2-KL Series Step 4: Insert the mounting clips into the slots on the sides of the device as shown. Hand-tighten the mounting clips with a Phillips- head screwdriver to secure it to the panel. Do not overtighten the clips to avoid damaging the device enclosure.

  • Page 34: Vesa Mounting

    2.9.2 VESA Mounting The SP2-KL Series can be VESA mounted with a rear cover and VESA bracket. (Optional items sold separately.) All I/O ports must face down. NOTE: NOTE: Step 1: Attach the rear cover to the panel PC with the screws sup- plied in the kit.
  • Page 35 SP2-KL Series Step 2: Attach the VESA bracket to the rear cover with 4x M3 screws. VESA Bracket Optional VESA bracket and M3 screws sold separately. Con- tact your ADLINK reseller for details. NOTE: NOTE: Mounting bracket provides 100 mm x 100 mm VESA mounting and requires 4x M4 screws.
  • Page 36 This page intentionally left blank.

  • Page 37: System Layout

    SP2-KL Series System Layout 3.1 External I/O Connectors The SP2-KL Series provides the following external I/O connectors. Figure 3-1: SP2-KL Series External I/O 2x DB-9P COM1 port supports RS-232/422/485 1x USB 3.2 Gen1 (5Gbps) Type-A 1x USB 2.0 Type-A 1x DisplayPort 2x RJ45 GbE LAN I225 type, up to 2.5GHz...

  • Page 38: Table 3-2: Com1 Port Pin Definition

    3.1.1 COM1 Port Connector The COM1 port is a D-sub 9-pin connector supporting RS-232/ 422/485 modes by BIOS setting. Figure 3-2: COM1 Port Pin Definition Signal RS-232 RS-422 RS-485 COM1_DCD-L_CN DCD# TXD422- 485DATA- COM1_RXD_CN TXD422+ 485DATA+ COM1_TXD_CN RXD422+ COM1_DTR-L_CN DTR# RXD422- COM1_DSR-L_CN DSR#...

  • Page 39: Table 3-3: Com2 Port Pin Definition

    SP2-KL Series 3.1.2 COM2 Port Connector The COM2 port is a D-sub 9-pin connector supporting RS-232/ 422/485 modes by BIOS setting. Figure 3-3: COM2 Port Pin Definition Signal RS-232 RS-422 RS-485 COM2_DCD-L_CN DCD# TXD422- 485DATA- COM2_RXD_CN TXD422+ 485DATA+ COM2_TXD_CN RXD422+...

  • Page 40: Figure 3-4: Usb 3.0 + Usb 2.0 Connector Pin Definition

    3.1.3 USB 3.0 + USB 2.0 Combo Connector USB 3.0 Gen1 (5 Gbps) Type-A + USB 2.0 Type-A connectors are provided compatible with SuperSpeed, Hi-Speed, Full-Speed, and Low-Speed USB devices suitable for USB peripherals. USB 3.1 connector up to 5Gbps with 1600 mA power and ...

  • Page 41: Table 3-4: Usb 3.0 + Usb 2.0 Connector Pin Definition

    SP2-KL Series Signal P_+5V_USB3 CN_U2_P1_N CN_U2_P1_P CN_U3_RX1_N CN_U3_RX1_P CN_U3_TX1_N CN_U3_TX1_P P_+5V_USB2 CN_U2_P2_N CN_U2_P2_P G1 GND G2 GND G3 GND G4 GND Table 3-4: USB 3.0 + USB 2.0 Connector Pin Definition...

  • Page 42: Table 3-5: Displayport Pin Definition

    3.1.4 DisplayPort Connector One DisplayPort connector, supporting the DP++ standard specifi- cation, can connect to VGA, DVI, HDMI, and DisplayPort with a DisplayPort to VGA adapter cable, DisplayPort to DVI adapter cable, or DisplayPort to HDMI adapter cable, or a DisplayPort cable, with DP1.4 support for resolutions up to 5120 x 3200 at 60Hz.

  • Page 43: Gigabit Ethernet Port

    SP2-KL Series 3.1.5 Gigabit Ethernet Port Two 2.5 Gigabit Intel® Ethernet Controller i225 Series (V, IT or LM) RJ45 connectors support up to 2500/1000/100/10 Mbit/s con- nections. Other combinations supported on a by-project basis. Con-  tact your ADLINK sales representative for more information.

  • Page 44: Table 3-6: Ethernet Port Pin Definition

    Signal L_GBE1_MDI0_P L_GBE1_MDI0_N L_GBE1_MDI1_P L_GBE1_MDI1_N Cap to GND Cap to GND L_GBE1_MDI2_P L_GBE1_MDI2_N L_GBE1_MDI3_P L_GBE1_MDI3_N L_GBE1_LED1_LINK/ACT-L LINK_ACT_LED L_GBE1_LINK100-L L_GBE1_LINK1000-L Table 3-6: Ethernet Port Pin Definition Color Status Description LAN is connected Active/Link Yellow Blinking LAN is initializing None 10/100 Mbps Speed Green 1000 Mbps...

  • Page 45: Internal I/O Connectors

    SP2-KL Series 3.2 Internal I/O Connectors Installation of add-on devices must be carried out by ADLINK service personnel only. Users must not disassemble the device themselves. WARNING: L'installation de périphériques complémentaires doit être effec- tuée uniquement par le personnel de service ADLINK. Les util- isateurs ne doivent pas démonter l'appareil eux-mêmes.

  • Page 46: Figure 3-8: Mainboard Connectors (Bottom)

    Figure 3-8: Mainboard Connectors (bottom)

  • Page 47: Figure 3-9: Mainboard Connector Legend Mainboard Connectors

    SP2-KL Series DC power connector Key connector (optional) Backup battery connector USB 2.0 SATA data Clear CMOS jumper SATA power PCIe Gen3 x4 slot (optional) Resistive touch LED wafer Capacitive touch I2C connector 1 Mini PCIe I2C connector 2 Mini DisplayPort...

  • Page 48: Dc Power Connector

    3.2.2 DC Power Connector The 4-pin power connector connects an AC/DC power supply adapter, DC to DC power module and battery, with AT and ATX power modes (AT mode start is controlled by BIOS). Figure 3-10: Power Connector Pin Definition Signal PWR_CONN_IN PWR_CONN_IN...

  • Page 49: Table 3-9: Power Connector Pin Definition

    SP2-KL Series 3.2.3 Backup Battery Power Connector The SMBUS allows the external battery for data backup to be read. Backup time is around 10 minutes. Figure 3-11: Power Connector Pin Definition Signal P_+3V3_BMC_A CHG_SMBCLK CHG_SMBDAT SMB_ALERT-L_R Table 3-9: Power Connector Pin Definition...

  • Page 50: Table 3-10: Sata Data Connector Pin Definition

    3.2.4 SATA Data & Power Connectors The SATA data and power connectors are used to connect an internal 2.5” HDD. Figure 3-12: SATA Data Connector Pin Definition Signal SATA_TX1_P SATA_TX1_N SATA_RX1_N SATA_RX1_P Table 3-10: SATA Data Connector Pin Definition Figure 3-13: SATA Power Connector Pin Definition Signal P_+5V_S0 P_+3V3_S0...

  • Page 51: Table 3-12: Resistive Touch Connector Pin Definition

    SP2-KL Series 3.2.5 Resistive Touch Connector The USB 2.0 connector supports a a resistive digitizer. Resistive Touch Connector Figure 3-14: Pin Definition Signal SENSE Table 3-12: Resistive Touch Connector Pin Definition 3.2.6 Capacitive Touch Connector The USB 2.0 connector supports a a resistive digitizer.

  • Page 52: Table 3-14: Mini Pcie Pin Definition

    3.2.7 Mini PCIe The mini PCIe port supports standard PCIe signals such as PCIe gen3 and USB2.0.. Figure 3-16: Mini PCIe Pin Definition Signal Signal PCIE_WAKE-L P_+3V3_S0_mPCIe TP point TP point P_+1V5_S0_mPCIe PCH_CLK_REQ3-L SIM_VCC SIM_IO MPCIE_CLK3_N UIM2_CLK MPCIE_CLK3_P UIM2_RST UIM2_VPP TP point PLTRST-L_MINIPCIE MPCIE_RX6_N...
  • Page 53 SP2-KL Series Signal Signal MPCIE_TX6_P_C USB_MINIPCIE_N USB_MINIPCIE_P P_+3V3_S0_mPCIe P_+3V3_S0_mPCIe TP point P_+1V5_S0_mPCIe P_+3V3_S0_mPCIe Table 3-14: Mini PCIe Pin Definition...

  • Page 54: Mini Displayport Connector

    3.2.8 Mini DisplayPort Connector Figure 3-17: Mini DisplayPort Pin Definition Signal CON_TCP2_HPD CON_TCP2_TX0_P CON_TCP2_DDC_AUX_SEL CON_TCP2_TX0_N CON_TCP2_TX1_P CON_TCP2_TX3_P CON_TCP2_TX1_N CON_TCP2_TX3_N CON_TCP2_TX2_P CON_TCP2_I2CCLK_AUX_P CON_TCP2_TX2_N CON_TCP2_I2CCLK_AUX_N P_+3V3_DP2 Table 3-15: Mini DisplayPort Pin Definition...

  • Page 55: Table 3-16: Usb 2.0 (Camera) Wafer Connector Pin Definition

    SP2-KL Series 3.2.9 USB 2.0 (Camera) Wafer The USB 2.0 wafer facilitates connection of a camera to the device. Figure 3-18: USB 2.0 (Camera) Wafer Connector Pin Definition Signal P5V_U2_WAFER CN_U2_P10_N CN_U2_P10_P Table 3-16: USB 2.0 (Camera) Wafer Connector Pin Definition...

  • Page 56: Table 3-17: Power/Reset Button Connector Pin Definition

    3.2.10 Power/Reset Button Connects to power, reset button, and power LED via cable. Figure 3-19: Power/Reset Button Connector Pin Definition Signal P_+3V3_BMC_A PWRBTN-L_R SYS_RESET-L_R SIG_PWRLED-L Table 3-17: Power/Reset Button Connector Pin Definition...

  • Page 57: Table 3-18: Mic In/Line Out Connector Pin Definition

    SP2-KL Series 3.2.11 Mic In/Line Out Supports Mic in/line out, connecting to speakers via cable. Figure 3-20: Mic In/Line Out Connector Pin Definition Signal EX_MIC_CN HP_CN_L HP_CN_R AGND_AUDIO Table 3-18: Mic In/Line Out Connector Pin Definition 3.2.12 Speaker Supports 2x 2 watt speakers.

  • Page 58: Table 3-20: Volume & Backlight Control Connector Pin Definition

    3.2.13 Volume & Backlight Control Connector Controls volume and adjusts display brightness. Figure 3-22: Volume & Backlight Control Connector Pin Definition Signal P_+3V3_S0 EC_BTN_33 EC_BTN_34 EC_BTN_35 EC_BTN_36 Table 3-20: Volume & Backlight Control Connector Pin Definition...

  • Page 59: Figure 3-23: Key Connector Pin Definition

    SP2-KL Series 3.2.14 Key Connector (Optional) The key connector supports 32 physical keys and 5 control keys with the following default values: Directions: ↑, ↓, ←, →  Numbers: 0 to 9  Functions: Enter, ESC, TAB, Backspace, Delete, Clear, ...

  • Page 60: Table 3-21: Key Connector Pin Definition

    Function Function Signal Signal Value Code Value Code P_+3V3_S0 EC_BTN_17 EC_BTN_1 EC_BTN_18 EC_BTN_2 Backspace EC_BTN_19 > EC_BTN_3 Delete EC_BTN_20 < EC_BTN_4 Space EC_BTN_21 EC_BTN_5 Page up EC_BTN_22 EC_BTN_6 Page down EC_BTN_23 EC_BTN_7 EC_BTN_24 EC_BTN_8 EC_BTN_25 EC_BTN_9 EC_BTN_26 EC_BTN_10 EC_BTN_27 EC_BTN_11 EC_BTN_28 EC_BTN_12 EC_BTN_29...

  • Page 61: Table 3-22: Usb 2.0 Connector Pin Definition

    SP2-KL Series 3.2.15 USB 2.0 Connector Figure 3-24: USB 2.0 Connector Pin Definition Signal P5V_U2_CAM CN_U2_P8_N CN_U2_P8_P Table 3-22: USB 2.0 Connector Pin Definition 3.2.16 Clear CMOS Jumper (JP6) If the SP2-KL fails to boot, clearing the BIOS content stored in CMOS and restoring the default settings may be effective.

  • Page 62: Figure 3-26: Pcie X4 Gen3 Connector Pin Definition

    3.2.17 PCIe x4 Gen3 Connectors (optional) Figure 3-26: PCIe x4 Gen3 Connector Pin Definition Side B Connector Side A Connector Name Description Name Description Hot plug +12V +12 volt power PRSNT#1 presence detect +12V +12 volt power +12V +12 volt power +12V +12 volt power +12V...

  • Page 63: Table 3-24: Pcie X4 Gen3 Connector Pin Definition

    SP2-KL Series Side B Connector Side A Connector Name Description Name Description SMDAT SMBus data JTAG3 Ground JTAG4 +12V +12V power JTAG5 JTAG1 +TRST# +3.3V +3.3 volt power 3.3Vaux 3.3 volt power +3.3V +3.3 volt power WAKE# Link Reactivation PERST#...

  • Page 64: Figure 3-27: Speaker Connector Pin Definition

    3.2.18 Speaker Connector The speaker connector supports 2 2x 2W speakers via cable. Figure 3-27: Speaker Connector Pin Definition Signal AMP_L+ AMP_L- AMP_R+ AMP_R- Table 3-25: Speaker Connector Pin Definition 3.2.19 Fan Connectors Figure 3-28: Fan Connector Pin Definition Signal FAN_PWR_IN (12V) BMC_FAN0_IN BMC_FAN0_OUT...

  • Page 65: Table 3-27: Com2 Connector Pin Definition

    SP2-KL Series 3.2.20 COM2 Connector Figure 3-29: COM2 Connector Pin Definition Signal COM2_DCD-L_CN COM2_RXD_CN COM2_TXD_CN COM2_DTR-L_CN COM2_DSR-L_CN COM2_RTS-L_CN COM2_CTS-L_CN COM2_RI-L_CN Table 3-27: COM2 Connector Pin Definition...

  • Page 66: Table 3-28: Led Connector Pin Definition

    3.2.21 LED Connector The LED connector supports up to 10 LEDs. Figure 3-30: LED Connector Pin Definition Signal CN_STDBY_PWR CN_GP3_LED-L CN_GP2_LED-L CN_GP1_LED-L P_+3V3_A CN_COM2_SOUT_LED_L CN_COM2_SIN_LED_L CN_COM1_SOUT_LED_L CN_COM1_SIN_LED_L CN_SATA_LED-L_R P_+3V3_S0 CN_WDT_LED-L P_+3V3_A Table 3-28: LED Connector Pin Definition...

  • Page 67: Table 3-29: I2C Connector 1 & 2 Pin Definition

    SP2-KL Series 3.2.22 I2C Connector 1 & 2 Figure 3-31: I2C Connector 1 & 2 Pin Definition Signal P_+5V_I2C P_+3V3_I2C DIO_I2C4_SDA DIO_I2C4_SCL DIO_I2C1_INT Table 3-29: I2C Connector 1 & 2 Pin Definition 3.2.23 Buzzer Connector Figure 3-32: Buzzer Connector Pin Definition...

  • Page 68: Table 3-31: Rtc Battery Wafer Pin Definition

    3.2.24 RTC Battery Wafer Figure 3-33: RTC Battery Wafer Pin Definition Signal P_+VCC_RTC_CN_A Table 3-31: RTC Battery Wafer Pin Definition...

  • Page 69: Table 3-32: Gpio Connector Pin Definition

    SP2-KL Series 3.2.25 GPIO Connector SP2-KL provides 4 channels of non-isolation digital input and 4 channels of non-isolation digital output circuits. 4-channel Digital Input VIH: 2.9 to 3.3V  VIL: 0 to 0.15V  4-channel Digital Output Output type: open drain N-channel ...

  • Page 70: Table 3-33: Gpio Connector Pin Voltage

    Signal PCH GPIO Default Value Input/Output Voltage Range P_+3V3_S0 VIH: 2.9V VIL: 0.15V GPIO_1 GPP_B3 Output High VOH: 2.211V VOL: 0.55V VIH: 2.9V VIL: 0.15V GPIO_2 GPP_B4 Output Low VOH: 2.211V VOL: 0.55V VIH: 2.9V VIL: 0.15V GPIO_3 GPP_E3 Output High VOH: 2.211V VOL: 0.55V VIH: 2.9V...

  • Page 71: Table 3-34: Backup Battery Connector Pin Definition

    SP2-KL Series 3.2.26 Backup Battery Connector (Optional) An optional backup battery connector is available. Contact ADLINK to for more information. Figure 3-35: Backup Battery Connector Pin Definition Signal CHG_PWR CHG_SMBCLK CHG_SMBDAT SMB_ALERT-L_R Table 3-34: Backup Battery Connector Pin Definition...

  • Page 72: Sim Card Connector

    3.2.27 SIM Card Connector The Nano SIM connector provides 4G/5G communication func- tionality. Figure 3-36: SIM Connector Pin Definition Signal P_+3V3_UIM_M2 M2_UIM_RST M2_UIM_CLK_R M2_UIM1_CD M2_UIM_VPP M2_UIM_DATA Table 3-35: SIM Connector Pin Definition...

  • Page 73: Table 3-36: Microsd Card Slot Pin Definition

    SP2-KL Series 3.2.28 MicroSD Card Slot The MicroSD card slot can be used for expanded storage. Signal SOC_SDCARD_D2 SOC_SDCARD_D3 SOC_SDCARD_CMD P_+3V3_SDCARD SOC_SDCARD_CLK SOC_SDCARD_D0 SOC_SDCARD_D1 SOC_SDCARD_CD-L Table 3-36: MicroSD Card Slot Pin Definition...

  • Page 74: Figure 3-37: M.2 2280 Connector Pin Definition

    3.2.29 M.2 2280 SATA SSD Connector The M.2 B+M key supports a SATA SSD. Figure 3-37: M.2 2280 Connector Pin Definition Signal Signal P_+3V3_S0 P_+3V3_S0 P_+3V3_S0 P_+3V3_S0 P_+3V3_S0 P_+3V3_S0 TP85 SATA_RX0_P SATA_RX0_N...
  • Page 75 SP2-KL Series Signal Signal SATA_TX0_N SATA_TX0_P P_+3V3_S0 P_+3V3_S0 P_+3V3_S0 Table 3-37: M.2 2280 Connector Pin Definition...
  • Page 76 This page intentionally left blank.

  • Page 77: Bios Setup (Sp2-Kl)

    SP2-KL Series BIOS Setup (SP2-KL) The Basic Input/Output System (BIOS) is a program that provides a basic level of communication between the processor and peripherals. In addition, the BIOS also contains codes for various advanced features applied to the SP2-KL. The BIOS setup program includes menus for configuring settings and enabling features of the SP2-KL.

  • Page 78: Menu Selection Bar

    Menu Selection Bar The Menu Selection Bar is located at the top of the screen. It displays the top level menus available to the user. Main Menu  Advanced Menu  Chipset Menu  Security Menu  Boot Menu  Save &...

  • Page 79: Menu Structure

    SP2-KL Series 4.2 Menu Structure This section presents the six primary menus of the BIOS Setup Utility. Use the following tables as a quick reference for the contents of the BIOS Setup Utility. The remainder of this chapter describe the sub-menus and options for each menu item. The default settings are presented in bold, and the function of each setting is described in the right hand column of the table.
  • Page 80 Boot Save & Exit - Boot Configuration ► - Save Changes and Exit - Discard Changes and Exit - UEFI Hard Disk Drive BBS Priorities ► - Save Changes and Reset - UEFI NVME Drive BBS Priorities ► - Discard Changes and Reset - UEFI CDROM/DVD Drive BBS Priorities ►...

  • Page 81: Main Menu

    SP2-KL Series 4.3 Main Menu This menu provides read-only information about your system and also allows you to set the System Date and Time. Refer to the tables below for details of the sub-menus and settings. 4.3.1 Main > BIOS Information...
  • Page 82 4.3.3 Main > Board Information Feature Options Description Board Information Info only Board Information Serial Number Info only Serial Number Manufacturing Date Info only Manufacturing Date Last Repair Date Info only Last Repair Date Runtime Statistics Info only Runtime Statistics Total Runtime Info only Total Runtime...

  • Page 83: Advanced Menu

    SP2-KL Series 4.4 Advanced Menu This menu contains the settings for most of the user interfaces in the system. 4.4.1 Advanced > CPU Configuration Feature Options Description CPU Signature Info only Displays the CPU Signature Microcode Patch Info only Displays the Microcode...
  • Page 84 Feature Options Description Turbo Mode Disabled, Enabled Enable/Disable processor Turbo Mode (requires EMTTM enabled too). AUTO means enabled, unless max turbo ratio is bigger than 16 - SKL A0 W/A Enabled, Disabled C states Enable/Disable CPU Power Management. Allows CPU to go to C states when it's not 100% utilized.
  • Page 85 SP2-KL Series 4.4.2 Advanced > Graphics Configuration Feature Options Description LVDS Info Only eDP/LVDS Disabled Enable/Disable eDP/ Enabled LVDS Data format and Color Auto Data format and Color Depth VESA 24 bpp Depth select JEIDA 24 bpp JEIDA/vesa 18 bpp...
  • Page 86 Feature Options Description LFP Panel Type Auto Select LFP panel used by 640x480 Internal Graphics Device 800x600 by selecting the 1024x768 appropriate setup item. 1280x1024 1400x1050 LVDS1 1400x1050 LVDS2 1600x1200 1366x768 1680x1050 1920x1200 1440x900 1600x900 1280x800 1920x1080 2048x1536 4.4.3 Advanced > Power Management Feature Options Description...
  • Page 87 SP2-KL Series Feature Options Description RTC Wake system from Disabled Enable or disable System Fixed Time wake on alarm event. Dynamic Time FixedTime: system will wake on the hr::min::sec specified. Select DynamicTime: system will wake on the current time + Increase...
  • Page 88 4.4.4 Advanced > Power Management > Power Con- sumption Feature Options Description Power Consumption Info only Current Input Current Info only Current Input Current Current Input Power Info only Current Input Power CPU-Vcore Info only CPU-Vcore VGFX Info only VGFX VCCIO Info only VCCIO...
  • Page 89 SP2-KL Series 4.4.6 Advanced > System Management > SEMA Fea- tures Feature Options Description SEMA Features Info only SEMA Supported Features Info only SEMA Supported Features • Uptime & Power Cycles Info only • Uptime & Power Cycles Counter Counter •...
  • Page 90 4.4.7 Advanced > System Management > Flags Feature Options Description BMC Flags Info only BMC Flags BIOS Select Info only BIOS Select ATX/AT-Mode Info only ATX/AT-Mode Exception Code Info only Exception Code 4.4.8 Advanced > System Management > SEMA > Tem- perature Feature Options...
  • Page 91 SP2-KL Series Feature Options Description Passive Cooling Trip Point Disabled This value is the temperature 60 C threshold of the Passive Cooling Trip 70 C Point. 80 C...
  • Page 92 4.4.9 Advanced > Watchdog Timer Feature Options Description Power-Up Watchdog Disabled Enbles/Disables the Watchdog Timer Enabled 0xFFFF Timeout Time Power Up Watchdog should wait until it resets the system in hex. Range 0x018-0xFFFF (18-65535 minutes, 1 min increments) ATTENTION: Pressing F12 during start up disables the Power Up Watchdog. 4.4.10 Advanced >...
  • Page 93 SP2-KL Series Feature Options Description Storage Do not Controls the execution of UEFI and Legacy Storage launch OpROM UEFI Legacy Video Do not Controls the execution of UEFI and Legacy Video launch OpROM UEFI Legacy Other PCI Do not Determines OpROM execution policy for devices...
  • Page 94 4.4.12 Advanced > Super IO Configuration > Serial Port 1 Configuration Feature Options Description Serial Port Disabled Enables/Disables the serial Enabled port (COM) Device Settings IO=3F8h; IRQ=4 Change Settings Auto Selects optimal settings for IO=3F8h; IRQ=4 Super IO Device IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 IO=2F8h;...
  • Page 95 SP2-KL Series Feature Options Description RS232 COM2 Control Sets COM2 mode as RS- RS422 232, RS-422 or RS-485 RS485 4.4.14 Advanced > Super IO Configuration > Serial Port 3 Configuration Feature Options Description Serial Port Disabled Enables/Disables the serial Enabled...
  • Page 96 Feature Options Description Change Settings Auto Selects optimal settings for IO=3E8h; IRQ=7; Super IO Device IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12 IO=220h; IRQ=3,4,5,6,7,9,10,11,12 IO=228h; IRQ=3,4,5,6,7,9,10,11,12...
  • Page 97 SP2-KL Series 4.4.16 Advanced > Serial Console Redirection Feature Options Description COM0 Console Redirection Disabled Enables/Disables console redirection on Enabled COM0 port. Console Redirection Sub-Menu Settings ► COM1 Console Redirection Disabled Enables/Disables console redirection on Enabled COM1 port. Console Redirection Sub-Menu Settings ►...
  • Page 98 Feature Options Description Parity None A parity bit can be sent with the data Even bits to detect some transmission errors. Even: parity bit is 0 if the num of 1's in Mark the data bits is even. Space Odd: parity bit is 0 if num of 1's in the data bits is odd Mark: Parity bit is always 1.
  • Page 99 SP2-KL Series 4.4.18 Advanced > Console Redirection > COM 1 > Con- sole Redirection Settings Feature Options Description Terminal Type VT100 Emulation: VT100Plus ANSI: Extended ASCII character set. VT-UTF8 VT100: ASCII character set. ANSI VT100Plus: Extends VT100 to support color, function keys, etc.
  • Page 100 Feature Options Description VT-UTF8 Combo Key Disabled Enable VT-UTF8 Combination Key Support Enabled Support for ANSI/VT100 terminals Recorder Mode Disabled With this mode enabled only text will be Enabled sent. This is to capture terminal data. Resolution 100x31 Disabled Enables/Disables extended terminal Enabled resolution VT100...

  • Page 101: Options Description

    SP2-KL Series 4.4.20 Advanced > Miscellaneous > Network Stack Config- uration Feature Options Description Network Stack Disabled Enables/Disables UEFI Network Stack Enabled IPv4 PXE Support Disabled Enables/Disables IPv4 PXE boot support. If Enabled disabled, IPv4 PXE boot support will not be available.
  • Page 102 Feature Options Description TCM State Disabled Enable/Disable Security Device. NOTE: Enabled Your Computer will reboot during restart in order to change State of the Device. None Pending operation* Schedule an Operation for the Security TPM Clear Device. NOTE: Your Computer will reboot during restart in order to change State of Security Device.
  • Page 103 SP2-KL Series Feature Options Description Disabled SHA512 PCR Bank Enable or Disable SHA512 PCR Bank Enabled SM3_256 PCR Bank Disabled Enable or Disable SM3_256 PCR Bank Enabled Pending operation None Schedule an Operation for the Security TPM Clear Device. NOTE: Your Computer will reboot during restart in order to change State of Security Device.
  • Page 104 Feature Options Description USB transfer time-out 1 sec The time-out value for Control, Bulk, and 5 sec Interrupt transfers. 10 sec 20 sec Device reset time-out 10 sec USB mass storage device Start Unit 20 sec command time-out. 30 sec 40 sec Device power-up Auto...

  • Page 105: Chipset

    SP2-KL Series 4.5 Chipset This menu contains chipset configuration information. 4.5.1 Chipset > System Agent (SA) Configuration Feature Options Description System Agent (SA) Configuration VT-d Supported Memory Configuration ► Sub-menu Graphics Configuration ► Sub-menu VT-d* Disabled VT-d capability Enabled Above 4GB MMIO BIOS...
  • Page 106 Feature Options Description Maximum Memory Auto Maximum Memory Frequency 1067 Frequency 1200 Selections in Mhz. 1333 1400 1600 1800 1867 2000 2133 2200 2400 2600 2667 2800 2933 3000 3100 3200 3467 3733 4000 4133 Max TOLUD Dynamic Maximum Value of 1 GB TOLUD.
  • Page 107 SP2-KL Series 4.5.3 Chipset > System Agent (SA) Configuration > Graphics Configuration Feature Options Description Graphics Info only Graphics Configuration Configuration Disabled Skip Scaning of If Enabled, system will not scan for External Gfx Card Enabled External Gfx Card on PEG and PCH...
  • Page 108 Feature Options Description DVMT Pre- Select DVMT 5.0 Pre-Allocated Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device. 32M/F7 DVMT Total Gfx 256M Select DVMT5.0 Total Graphic 128M Memory size used by the Internal Graphics Device. Gfx Low Power Enabled This option is applicable for SFF only.
  • Page 109 SP2-KL Series Feature Options Description SCS Configuration ► SCS Configuration Menu 4.5.5 Chipset > PCH-IO Configuration > PCI Express Configuration Feature Options Description PCI Express Configuration Info Only PCI Express Clock Gating PCI Express Clock Gating Enable/ Disable for each root port.
  • Page 110 4.5.6 Chipset > PCH-IO Configuration > SATA and RST Configuration Feature Options Description SATA And RST Info Only Configuration SATA Controller(s) Enabled Enable/Disable SATA Disabled Device. SATA Mode Selection AHCI Determines how SATA Intel RST Premium With controller(s) operate. Intel Optane System Acceleration SATA Test Mode Enabled...
  • Page 111 SP2-KL Series Feature Options Description DITO Configuration Disabled Toggle DITO Enabled configuration DITO Value 0x0271 DITO value in hex. Range: 0x0000-0x03FF in increments of 1. DM Value 0x0F DM value in hex. Range: 0x0F-0x00 in increments of 1. Serial ATA Port 1...
  • Page 112 4.5.7 Chipset > PCH-IO Configuration > USB Configura- tion Feature Options Description FALSE XHCI Disable Compliance Options to disable Compliance Mode TRUE Mode. Set TRUE to disable Compliance Mode. xDCI Support Disabled Enable/Disable xDCI (USB Enabled OTG Device). Disabled USB Port Disable Override Selectively Enable/Disable the Select Per-Pin corresponding USB port from...
  • Page 113 SP2-KL Series Feature Options Description USB SS Physical Connector Disabled Enable/Disable the specified Enabled USB Physical Connector (physical port). Once disabled, USB devices plugged into the connector will not be detected by BIOS or OS. USB SS Physical Connector Disabled...
  • Page 114 Feature Options Description USB HS Physical Connector Disabled Enable/Disable the specified Enabled USB Physical Connector (physical port). Once disabled, USB devices plugged into the connector will not be detected by BIOS or OS. USB HS Physical Connector Disabled Enable/Disable the specified Enabled USB Physical Connector (physical port).
  • Page 115 SP2-KL Series Feature Options Description USB HS Physical Connector Enabled Enable/Disable the specified Disabled USB Physical Connector (physical port). Once disabled, USB devices plugged into the connector will not be detected by BIOS or OS. Enabled USB HS Physical Connector...
  • Page 116 Feature Options Description State After G3 S0 State Specify what state to go to when S5 State power is re-applied after a power failure (G3 state). 4.5.9 Chipset > PCH-IO Configuration > HD Audio Con- figuration Feature Options Description HD Audio Subsystem Info Only Configuration Settings HD Audio...

  • Page 117: Security

    SP2-KL Series 4.6 Security Feature Options Description Minimum length Password length for both user and administrator passwords. Maximum length...

  • Page 118: Boot

    4.7 Boot 4.7.1 Boot > Boot Configuration Feature Options Description Setup Prompt Timeout 0x0001 Number of seconds to wait for setup activation key in hex. Range: 0x0001-0xFFFF (0 to 65535 seconds, 1 second increments). 0xFFFF (65535 seconds) means indefinite waiting. Bootup NumLock State On Selects the keyboard...
  • Page 119 SP2-KL Series Feature Options Description Hard Disk Boot Option #1 Hard Disk Sets the system NVME boot order Boot Option #2 CD/DVD CD/DVD USB Hard Boot Option #3 Disk:UEFI: USB Hard Disk Sandisk USB CD/DVD Boot Option #4 Partition 1...
  • Page 120 Feature Options Description UEFI Hard Disk Drive Sub-Menu BBS Priorities ► UEFI CDROM/DVD Sub-Menu Drive BBS Priorities ► UEFI USB Hard Disk Sub-Menu Drive BBS Priorities ► UEFI USB CDROM/ Sub-Menu DVD Drive BBS Priorities ► UEFI USB Key Drive Sub-Menu BBS Priorities ►...

  • Page 121: Save & Exit

    SP2-KL Series 4.8 Save & Exit Feature Options Description Save Changes and Exit Exits system setup after saving the changes. Discard Changes and Exit Exits system setup without saving any changes. Save Changes and Reset Resets the system after saving the changes.
  • Page 122 This page intentionally left blank.

  • Page 123: Driver & Application Installation

    SP2-KL Series Driver & Application Installation After installing the operating system, all related drivers must be installed for the system to function properly. This section describes the drivers needed for Windows operating systems and the proce- dures to install them. For other operating system support, contact ADLINK for further information.

  • Page 124: Chipset Driver Installation

    5.2 Chipset Driver Installation The chipset driver directs the operating system to configure the Intel® chipset components in order to ensure that the following features function properly: SATA Storage Support  USB Support  Identification of Intel® Chipset Components in the Device ...

  • Page 125: Graphics Driver Installation

    SP2-KL Series 5.3 Graphics Driver Installation The SP2-KL is equipped with the Intel® Graphics Media Accelera- tor Driver package, which supports Windows 10 IoT Enterprise. To install the graphics driver: 1. Close any running applications. 2. From ADLINK's website, download Windows 10 IoT Enterprise drivers for the SP2-KL.

  • Page 126: Ethernet Driver Installation

    5.4 Ethernet Driver Installation To install the driver for the Intel I225 Gigabit Ethernet controller: 1. Close any running applications. 2. From ADLINK's website, download Windows 10 IoT Enterprise drivers for the SP2-KL. 3. Execute Setup.exe and follow the on-screen instructions to complete the installation.

  • Page 127: Serial I/O Driver Installation

    SP2-KL Series 5.6 Serial I/O Driver Installation To install the driver for the serial I/O controller: 1. Close any running applications. 2. From ADLINK's website, download Windows 10 IoT Enterprise drivers for the SP2-KL. 3. Execute Setup.exe and follow the on-screen instructions to complete the installation.
  • Page 128 This page intentionally left blank.

  • Page 129: Important Safety Instructions

    SP2-KL Series Important Safety Instructions For user safety, please read and follow all instructions, Warnings, Cautions, and Notes marked in this manual and on the associated device before handling/operating the device, to avoid injury or damage. Read these safety instructions carefully.
  • Page 130 A Lithium-type battery may be provided for uninterrupted  backup or emergency power. Risk of explosion if battery is replaced with one of an incorrect type; please dispose of used batteries appropriately. CAUTION: The device must be serviced by authorized technicians when: ...

  • Page 131: Consignes De Sécurité Importante

    SP2-KL Series Consignes de Sécurité Importante Pour la sécurité de l'utilisateur, veuillez lire et suivre toutes les instructions, avertissements, mises en garde et notes marqués dans ce manuel et sur l'appareil associé avant de manipuler/d'uti- liser l'appareil, afin d'éviter toute blessure ou tout dommage.
  • Page 132 Installez/fixez et utilisez l'appareil uniquement sur des  surfaces stables et/ou sur les fixations recommandées. L'ordinateur Smart Touch est alimenté par un adaptateur  ou une source CC. Veuillez vous assurer que l'adapta- teur ou la source CC doit conserver la connexion à la terre s'il est doté...
  • Page 133 SP2-KL Series Il est recommandé d'installer l'appareil uniquement dans une  salle de serveurs ou une salle informatique où l'accès est: Réservé au personnel de service qualifié ou aux utilisa-  teurs familiarisés avec les restrictions appliquées à l'emplacement, aux raisons de ces restrictions et toutes les précautions requises...

  • Page 134: Fcc Warning

    EMC Compliance CE Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. FCC Warning This equipment has been tested and found to comply with the lim- its for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 135: Getting Service

    San Jose, CA 95119-1208, USA Tel: +1-408-360-0200 Toll Free: +1-800-966-5200 (USA only) Fax: +1-408-600-1189 Email: info@adlinktech.com ADLINK Technology (China) Co., Ltd. 300 Fang Chun Rd., Zhangjiang Hi-Tech Park Pudong New Area, Shanghai, 201203 China Tel: +86-21-5132-8988 Fax: +86-21-5132-3588 Email: market@adlinktech.com ADLINK Technology GmbH Hans-Thoma-Straße 11...

This manual is also suitable for:

Sp2-10wp-klSp2-15wp-klSp2-21wp-kl
