Fire detection and evacuation solutions that save lives.
EvacUElite Remote Paging Console Operators Manual
Contents
1
Purpose ............................................................................................................................................... 2
2
General Overview ................................................................................................................................ 2
3
RPC Idle Screen .................................................................................................................................... 3
4
RPC MainScreen ................................................................................................................................... 4
5
RPC Buttons & Indicators ..................................................................................................................... 5
6
Chime On (User Option) ....................................................................................................................... 6
7
Paging Individual Zones (or Multiple Zones) ......................................................................................... 7
8
9
Paging Groups ...................................................................................................................................... 9
10
RPC Access Level Screen .................................................................................................................11
11
RPC Set up screens .........................................................................................................................12
MAN3189-1
1
Advertisement
Table of Contents
Related Manuals for Halma Ampac EvacUElite
Summary of Contents for Halma Ampac EvacUElite
-
Page 1: Table Of Contents
MAN3189-1 Fire detection and evacuation solutions that save lives. EvacUElite Remote Paging Console Operators Manual Contents Purpose ............................... 2 General Overview ..........................2 RPC Idle Screen ............................ 3 RPC MainScreen ........................... 4 RPC Buttons & Indicators ........................5 Chime On (User Option) ........................6 Paging Individual Zones (or Multiple Zones) .................. -
Page 2: Purpose
MAN3189-1 Fire detection and evacuation solutions that save lives. EvacUElite Remote Paging Console Operators Manual 1 Purpose This document explains how to operate the EvacUElite Remote Paging Console. Ampac Item No: 6310-RPC For a broader understanding please refer to the following documents. •... -
Page 3: Rpc Idle Screen
MAN3189-1 Fire detection and evacuation solutions that save lives. EvacUElite Remote Paging Console Operators Manual 3 RPC Idle Screen When an RPC remains unused for a short period the touchscreen will go blank into sleep mode. This feature increases product life and reduces system power consumptions. When touched the console wakes up showing a screen displaying the RPC descriptor and time and date Pressing the Paging Menu button opens the main RPC control screen. -
Page 4: Rpc Mainscreen
MAN3189-1 Fire detection and evacuation solutions that save lives. EvacUElite Remote Paging Console Operators Manual 4 RPC MainScreen Paging selections are made on the Main screen. The display indicators at the top and control buttons along the bottom are common to each RPC The Paging Zones (and Groups) displayed are fully configurable. -
Page 5: Rpc Buttons & Indicators
MAN3189-1 Fire detection and evacuation solutions that save lives. EvacUElite Remote Paging Console Operators Manual 5 RPC Buttons & Indicators RPC Screen Icons Description Menu Takes you Back to set up screen Home Screen Returns to the RPC idle screen Paging Menu. -
Page 6: Chime On (User Option)
MAN3189-1 Fire detection and evacuation solutions that save lives. EvacUElite Remote Paging Console Operators Manual Down Arrow. When the quantity of Paging Zone >15 Use the Up & Down arrows to scroll through Up Arrow When the quantity of Paging Zone >15 Use the Up &... -
Page 7: Paging Individual Zones (Or Multiple Zones)
MAN3189-1 Fire detection and evacuation solutions that save lives. EvacUElite Remote Paging Console Operators Manual 7 Paging Individual Zones (or Multiple Zones) 1 Press Paging Menu Button. This takes you to Main Paging Screen 2 On Main Screen Select the Zone(s) Pressing Zone button will turn a Red... -
Page 8: Paging "All Zones
MAN3189-1 Fire detection and evacuation solutions that save lives. EvacUElite Remote Paging Console Operators Manual 8 Paging “All Zones” Press Paging Menu Button for Main Paging Screen Select ZONES Button ALL ZONE indicators will turn green Select Press to Tallk ON / OFF button When OK TO TALK OK TO TALK... -
Page 9: Paging Groups
MAN3189-1 Fire detection and evacuation solutions that save lives. EvacUElite Remote Paging Console Operators Manual 9 Paging Groups Paging groups are pre configured by the installer or maintenance provider so they are an “optional configurable feature” Press Paging Menu Button for the Main Screen Press GROUP... - Page 10 MAN3189-1 Fire detection and evacuation solutions that save lives. EvacUElite Remote Paging Console Operators Manual OK TO TALK OK TO TALK indicator will turn grey GROUP On Main Screen will display respective condition INDICATORs Notes Pressing this button in the Main Screen will De select All GROUPS currently selected Pressing this button in the Main Screen will Select ‘All GROUPS’...
-
Page 11: Rpc Access Level Screen
MAN3189-1 Fire detection and evacuation solutions that save lives. EvacUElite Remote Paging Console Operators Manual 10 RPC Access Level Screen This screen appears during power up. User ID and Password are configured (by the Programmer during system set up). The two Access level settings are needed to complete ‘set up’. Or if the RPC system malfunctions or is moved to another location etc. -
Page 12: Rpc Set Up Screens
MAN3189-1 Fire detection and evacuation solutions that save lives. EvacUElite Remote Paging Console Operators Manual 11 RPC Set up screens The set up screens are used during commissioning to set RPC address number as per the system configuration Press the EXIT button to return to the RPC Main Screen. Each of the buttons shown below can be pressed. - Page 13 MAN3189-1 Fire detection and evacuation solutions that save lives. EvacUElite Remote Paging Console Operators Manual RPC Volume setting Press RPC Volume button 100% is the default slider setting. Move the volume slider to select a suitable RPC Volume setting Press RPC Volume button again to save the new setting. LCD Backlight adjustment Press LCD Backlight button Press the blue up or down arrow to adjust...
- Page 14 MAN3189-1 Fire detection and evacuation solutions that save lives. EvacUElite Remote Paging Console Operators Manual RPC Address setting Press RPC Address button Press the blue arrows up or down to select the correct RPC address setting. Only address numbers which exist in the configuration and remain unselected will be available to select Press RPC Address button again to save the new setting.
