5. Product Overview

The PDT-SPL-1202-1000-I is an Ultra-Small Form Factor Industrial PoE Splitter capable of
delivering Gigabit Ethernet via RJ-45 Connections, and +12VDC Power via terminal block, to non-
PoE compliant devices, saving the cost of providing on site electrical power to edge devices.
The device is Plug and Play, and is completely unmanaged, therefore requiring no tools or
software configuration for operation. With 2 x RJ45 data ports, the device also functions as an
unmanaged network switch.
The Dual power input (PoE/DC) allows for fault tolerance in network designs as the device will
automatically revert to DC Input in the event of PoE Power Failure, allowing for the use of a
backup battery on-site, should host device PoE power fail.
The device is designed for use in harsh industrial environments, and incorporating a rugged
aluminium housing, it can be operated across a wide temperature range (-40°C to +80°C) making
it suitable for most conditions.
A typical application setup can be seen in the following diagram:
PoE Switch
PoE
IP Camera
Data
Data
GND
+12VDC
