10. Hardware Specification

ETHERNET
Forwarding and Filtering Rate
INTERFACE
ENVIRONMENTAL
Operating Temperature
ELECTRICAL
Short-Circuit Protection
MECHANICAL
INDICATORS
Standards
Packet Buffer
Packet Length
MAC Address Table
Exchange Property
PoE/PoE+ In
Access Ports
Power
Storage Temperature
Relative Humidity
MTBF
Operating Voltage
Power Consumption
External Load
Reverse Polarity
Dimensions
Weight
Casing
Mounting
PWR
POE/12V
L/A
SPD
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3x Full Duplex Flow Control
IEEE 802.3az Energy Efficient Ethernet
14,880pps (10Mbps)
148,800pps (100Mbps)
1,488,000pps (1000Mbps)
1Mbits
10KB
8K
Backplane Bandwidth 20Gbps
Packet Forwarding Rate 14.88Mbps
1 x 10/100/1000 RJ45
2 x 10/100/1000 RJ45
5 Pin Terminal Block
-40°C to +80°C
-40°C to +85°C
5% - 95% non-condensing
>200,000 hours
+12VDC PoE or DC Terminal Block Input
5w standalone (25W with full external load)
Up to 20W
Auto-Reset
Protected
95mm x 70mm x 29mm
250g
Aluminium
DIN Rail & Wall Mount
Power
+12VDC Output
Link/Activity
Data Transmission Speed
