6.2 RJ45 Ports

The Front Panel has 3 RJ45 Ports on the Front Panel. The POE port should be used for Uplink
purposes and the host device should have PoE enabled to power the unit. The remaining ports (TP1
and TP2) can be used as Access Ports, and do not have PoE capable outputs.
Port
POE
TP1
TP2

6.3 Power Supply Connector

Pin
GND
12V
V-
V+
Note: All Power Supplies should provide over-current and short-circuit protection and should have
a capacity rating to meet the required output current for the device.
PoE/PoE+ Trunk Port
Access Port 1 – No PoE Output
Access Port 2 – No PoE Output
Type
GND Power Output from PoE Source
Output
+12VDC Power Output from PoE Source
Backup GND Supply from External Source
Input
Backup +12VDC Supply from External Source
Function
Description
