Laguna Tools Fiber Marker/OM Laser Manual

Laguna Tools Fiber Marker/OM Laser Manual

Hide thumbs

Advertisement

Table of Contents

Laguna Tools
Fiber Marker/OM Laser:
Metal Engraving – Metal Etching
Owner's Manual-
•
Introduction
•
Delivery Parameters (Damage Notification)
•
Basic Operations
•
Installation
•
Safety
•
Maintenance
•
Warranty-Coverage, Return Policy
Features:
20,30 and 50W Options.
110 x 110mm Lens.
Laser Wavelength: 1064nm.
Up to 10,000mm/s Marking Speed.
Resolution: 0.001mm.
Repositioning Precision: 0.003mm.
Air Cooling System.
Laguna Tools: 744 Refuge Way
Grand Prairie, TX 75050
U.S.A. Service: +1 (800) 234-1976 or E-Mail:
customerservice@lagunatools.com
Fiber Maker Laser Machine © 2021 Laguna Tools
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fiber Marker/OM Laser and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Laguna Tools Fiber Marker/OM Laser

Summary of Contents for Laguna Tools Fiber Marker/OM Laser

  • Page 1 Up to 10,000mm/s Marking Speed.  Resolution: 0.001mm.  Repositioning Precision: 0.003mm.  Air Cooling System.  Laguna Tools: 744 Refuge Way Grand Prairie, TX 75050 U.S.A. Service: +1 (800) 234-1976 or E-Mail: customerservice@lagunatools.com Fiber Maker Laser Machine © 2021 Laguna Tools...

  • Page 2: Table Of Contents

    Table of Contents- • Introduction of Machine- • Delivery Parameters- • Basic Operation- • Installation Requirements- • Precautions of Machine Use- • Maintenance- • Safety- • Warranty-...
  • Page 3 Fiber Marker/OM Laser- Introduction of the • Summarization- Optical fiber laser marking machine is a kind of professional laser marking equipment which integrated light, machine, electricity, independent research and development and production, The key components are imported. Our machine with advantage of novel style, unique structure, convenient operation, high frequency modulation, high marking speed and precision, stable performance, widely used in all kinds of metallic and nonmetallic surface for permanent marker.
  • Page 4 Fiber Marker/OM Laser (Cont’d.)- Introduction of the • Other Specifications (Optical Output)- Marking Range- Cooling Systems- • F = 160mm •Air-Cooled. • Range: 110 x 110mm (with standard) •0 ~ 35 ℃ (Celsius) or 0 ~ 95 F (Fahrenheit), 90% Humidity.
  • Page 5 Fiber Marker/OM Laser (Cont’d.)- Introduction of the • Special Features- Excellent Beam Quality- The OM Fiber Marker achieves superb beam quality by minimizing the condensation diameter to less than 20um. And with a divergence angle that is 1/4 of the semiconductor pumping source laser, the OM achieves consistent precision. This exceptional accuracy can be run at a marking speed of up to 10,000mm/s.
  • Page 6 Fiber Marker/OM Laser (Cont’d.)- Introduction of the • Special Features (Cont’d.)- Dual-Laser Focusing System- To ensure the best possible outcome, the OM comes with a focusing system. You can manually adjust either before or during the operation to fine tune your project to your liking.
  • Page 7 Fiber Marker/OM Laser (Cont’d.)- Introduction of the • Special Features (Cont’d.)- Applicable Materials (Samples)- • Gold • Silver • Diamonds • Steel • Copper • Iron • Aluminum • Plastic • PVC/PVC Pipe-Polyvinyl Chloride • Ceramics • PCB-Printed Circuit Board •...

  • Page 8: Delivery Parameters

    Delivery Parameters- 1. When the Crate containing your newly purchased Fiber Marker Laser Machine is delivered, it will be delivered “Curbside”, in other words the Machine will be delivered in front of the Driveway of ones Garage/Shop or Workspace. (****It is the Purchasers responsibility of moving the Machine into His or Hers Garage/Shop or Workspace.****) 2.
  • Page 9 Delivery Parameters- Damage Notification: 1.) The Machines are thoroughly tested before leaving any or our Laguna Tools Facilities, but that does not mean the Machines would not experience any damage in transit. 2.) Before one Signs the Bill of Lading (See Example Below) when the Trucking Company drops off the Machine, visually inspect the entire crate and check for any damage.
  • Page 10 Note that on the Bill of Lading as well with any photos. 5.) NOTIFY LAGUNA TOOLS WITHIN 24 HOURS AFTER RECEIVING CRATE WITH SHIPPING or any other type of DAMAGE. We ask customers to notify us within 24 hours of any damage sustained to the packaging and or...
  • Page 11 Delivery Parameters- Unboxing: 1. Acquire some standard tools for taking apart the Crate. a.) Hammer. b.) Pry Bar. c.) Wire Cutters. d.) Cordless Drill.
  • Page 12 Delivery Parameters- Unboxing (Cont’d.): 2. Cut all straps only on the Crate. 3. Unscrew a series of Screws at the Base of Crate using a Cordless Drill.
  • Page 13 Delivery Parameters- Unboxing (Cont’d.): 4. Unscrew and remove Side Panels of Crate.

  • Page 14: Basic Operation

    Basic Operations- Marking Principle- *Through the laser light energy evaporate the material in the surface and show deep material; *Through the laser light energy cause the surface substance chemical physical change and "engrave" the needed text pattern; *Through the laser light energy burned part of the material, then show the design, text of etching. Structure Description- Optical Fiber Laser “OM”...
  • Page 15 Basic Operations (Cont’d.)- Structure Description- Optical fiber laser marking machine mainly made up of the Following: Focal Length/ Rotary/Optical Control Wheel Computer Monitor 2.) Optical Fiber Laser 4.) Marking Head. 5.) Working Table SCAN BREAKER LASER 3.) Control Panel SWITCH USB Port Power- (Key) Line...
  • Page 16 Basic Operations (Cont’d.)- Structure Description- Optical fiber laser marking machine mainly made up of the Following: Back Panel Fiber Laser (Raycus) System Optical Fiber Laser “OM” Marking Machine Open Back Panel of the Control System.

  • Page 17: Installation Requirements

    10 Degrees Celsius - 35 Degrees Celsius (50 Degrees Fahrenheit- 95 Degrees Fahrenheit), and keep the Optics Device clean & dry. To have the Machine operate to its expectations & specifications, Laguna Tools suggests to have the machine be placed in a separate closed workshop or room to assure constant suggested operating temperatures controlled by a proper HVAC System.
  • Page 18 Installation Requirements & more operating instructions- The wiring diagram of outside Machine- Plug for a Foot Switch/Control, if available. Rotary Controller Plug to Power Machine (110V). Connect the USB line to the control cabinet, then to the USB Port/line- computer system. USB Port/Line...
  • Page 19 Installation Requirements & more operating instructions (Cont’d.)- Operation Process Instructions- Control Panel Start –Up Order. Powering Fiber Marker OM Laser Process- a) Turn “On” Computer. b) Key On & Off Switch. c) Press “RED” Button-”RED” Switch.. d) Press “SCAN” Button-Scanner Switch. e) Press “LASER”...
  • Page 20 Installation Requirements & more operating instructions (Cont’d.)- Operation Process Instructions- Control Panel Start –Up Order. Note: a) Turn “On” Computer. b) Key On & Off Switch (Turnkey to “On” Position.) c) Press “RED” Button-”RED” Switch. d) Press “SCAN” Button-Scanner Switch. e) Press “LASER”...
  • Page 21 Installation Requirements & more operating instructions (Cont’d.)- Operation Process Instructions- Control Panel. Note: a) Turn “On” Computer. b) Key On & Off Switch (Turnkey to “On” Position.) c) Press “RED” Button-”RED” Switch. d) Press “SCAN” Button-Scanner Switch. e) Press “LASER” Button-Laser Switch. ***Frequency Adjustment Range 20 KHZ- 80 KHZ, generally considering to KHZ.
  • Page 22 Installation Requirements & more operating instructions (Cont’d.)- Solution 1: Rotate this up or down to “Adjust Focal Length”. Focal Length/ Rotary/Optical *How to Focus Length of the Laser- Control Wheel 1.) Set “Output Power: 50W or 60W”, Speed “1000mm/sec”. 2.) Place ones Steel Plate or acceptable Workpiece on Worktable.
  • Page 23 Installation Requirements & more operating instructions (Cont’d.)- *How to Focus Length of the Laser- “Laser Power” and “Scanner Power”, place acceptable Workpiece 3.) Open in proper position. Powering Fiber Marker OM Laser Process- a) Turn “On” Computer. b) Key On & Off Switch. c) Press “RED”...
  • Page 24 Installation Requirements & more operating instructions (Cont’d.)- 4.) When “EZCAD Software is opened, choose ”Continue” and ”Mark Sel”, then Press the F2 Key on the Computer Keyboard, or the Computer Screen, meanwhile rotating handle. Continue Mark Sel Press F2...
  • Page 25 Installation Requirements & more operating instructions (Cont’d.)- 4.) When “EZCAD Software is opened, choose ”Continue” and ”Mark Sel”, then Press the F2 Key on the Computer Keyboard, or the Computer Screen, meanwhile rotating handle. Mark Sel Continue . Press F2...
  • Page 26 Installation Requirements & more operating instructions (Cont’d.)- Solution 2: Accept two red light scan head, move the laser head up and down, when 2 dots come together that is when the light beam is the most strongest. To establish the proper “Focal Point”. One can attempt to change the distance (up and down), one will see different marking results.
  • Page 27 Installation Requirements & more operating instructions (Cont’d.)- E.g., One will want to make black mark on Stainless Steel, one will need to adjust the distance above best focal length 2-5mm, set speed at”100mm/s” power at”80%-85%”, you can have a try.
  • Page 28 Installation Requirements & more operating instructions (Cont’d.)- 110*110mm, focal length: 212mm(from the material surface to the bottom of the galvo head edge). 212 mm from Material Surface to bottom of Galvo Head Edge.
  • Page 29 Installation Requirements & more operating instructions (Cont’d.)- Operation Process Instructions-Equipment Shutdown Order: Shutdown Order- Fiber Marker OM Laser Process- a) Close or Turn “Off”- “EZCAD” Software. b) Close or Turn “Off “LASER” -Laser Switch. c) Close or Turn “Off “ “SCAN”-Scanner Switch. d) Close or Turn “Off-“RED”...

  • Page 30: Precautions Of Machine Use

    7.) In working process, someone must wait on duty, especially high-power cut or carving organic ingredients higher material, in order to avoid the eruption or fire. Do not operate without training, or operate, thus Laguna Tools is nor responsible for any...
  • Page 31 Precautions of Machine Use (Cont’d.)- Daily Operation- 8.) Because this kind of laser is invisible light, pay attention to safety when working with machine, the equipment are strictly prohibited to be placed near inflammable, explosive items, in case of the laser is deviated to cause fires. 10.) When the machine working or debugging light path, please be sure to pay attention and not to let any part of the body into the transfer area of light path, to avoid injury.

  • Page 32: Maintenance

    Maintenance- Because of the working environment, optical lens may have dirt build up after a period of time, if not maintained. Dust will corrode lens coating, damaged lens coating can't reflect light to crate laser, oppositely the corrosion will absorb laser heat, affecting marking effect, and easily cause lens to crack.

  • Page 33: Safety

    Safety- Notes- • Avoid dangerous accidents and reduce maintenance costs, reducing downtime of examine and repair, also can improve the credibility and the working life of the machine. • This manual including industrial injury prevention and protection matters for environmental, the user can replenish according to its specific conditions.
  • Page 34 Safety (Cont’d.)- Safety Requirements- 4.) Because this type of laser operates with an invisible light, it is strictly prohibited to have flammable and explosive items near the laser, in case of deviation laser fires. 5.) For invisible laser, we suggest to wear approved safety glasses for Fiber Marker Laser machines when in use. 6.) The top cover plate must be closed when working, in case of the laser deviates and could cause injury.
  • Page 35 Safety (Cont’d.)- Safety Requirements- In a suspicious fault, do not operate. If you suspect the damage is exist, contact us for inspection, do not continue to operate. Do not operate in a wet environment. Do not operate in explosive environment. Keep the surface clean and dry.
  • Page 36 Customer Service and include the (RMA) number with any and all returned parts/components requesting warranty coverage.* Any machines returned to Laguna Tools must be returned with packaging in the same manner in which it was received. If a part or blade is being returned it must have adequate packaging to ensure no damage is received during shipping.
  • Page 37 Laguna Tools Customer Support Website. The labor required to install replacement parts is the responsibility of the user. Laguna Tools is not responsible for damage or loss caused by a freight company or other circumstances not in our control. All claims for loss or damaged goods must be notified to Laguna Tools within twenty-four hours of delivery.
  • Page 38 Laguna Tools Warranty-...
  • Page 39 Parts, under warranty, are shipped at Laguna Tools, Inc.’s cost either by common carrier, FEDEX ground service or a similar method. Technical support to install replacement parts is primarily provided by phone, fax, e-mail or Laguna Tools Customer Support Website.
  • Page 40 Dealer Machinery Warranty **Any machines returned to Laguna Tools must be returned with packaging in the same manner in which it was received. If a part or blade is being returned it must have adequate packaging to ensure no damage is received during shipping.
  • Page 41 Laguna Tools Packaging/Laguna Tools RMA Example- RMA #...
  • Page 42 Laguna Tools Packaging/Laguna Tools BILL of LADING Example-...
