  • Page 1 MCNC Creator Pro I-24P Laguna Tools 744 Refuge Way Grand Prairie, TX lagunatools.com...

  • Page 2: Scope Of This Manual

    LAGUNA® and the LAGUNA Logo® are the registered trademarks of Laguna Tools, Inc. DISCLAIMER Laguna Tools is not responsible for errors or omissions. Specifications subject to change. Machines may be shown with optional accessories. Revision 01 (02/07/2023)

  • Page 3: Table Of Contents

    MCNC Creator Pro I-24P TABLE OF CONTENTS SCOPE OF THIS MANUAL CUSTOMER SERVICE GENERAL INFORMATION AND SAFETY 1.1 Overview 1.2 Safety Signs and Call-Outs 1.3 Safety Information SETUP AND ASSEMBLY 2.1 Packaging Contents 2.2 Hardware package contains 2.3 Tools Required for Assembly 2.4 Packaging contents for CNC machine...
  • Page 4 MCNC Creator Pro I-24P OPERATIONS 4.1 Controller 4.2 Operating Procedure 4.3 HOME Position 4.4 Moving the Router (Spindle) Head 4.5 Setting Work Origin 4.6 Programming Additional Origin 4.7 Setting Spindle RPM 4.8 Processing a file 4.9 Speed Scale Adjustment 4.10 Pausing During Toolpath Operation 4.11...
  • Page 5 MCNC Creator Pro I-24P 6.5 Stop State (Back Position) 6.6 Part Work 6.7 Calculate Boundaries 6.8 Auto Center 6.9 Mill Plane (Surfacing Operation): 6.10 Calculate Work Time 6.11 Scale Work 6.12 Step Work DATA RESTORATION AND UPDATES MAINTENANCE 8.1 Routine Checks (performed daily with machine use) 8.2 Cooling System Flush/Refill...
  • Page 6 MCNC Creator Pro I-24P NOTES:...

  • Page 7: General Information And Safety

    A potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION A potentially hazardous situation which, if not avoided, may result in minor or moderate injury. NOTE A helpful tip from Laguna Tools technical staff.

  • Page 8: Safety Information

    MCNC Creator Pro I-24P Safety Information The Creator Pro CNC machine is an electrical appliance and precision machine. Please read and understand the entire owner’s manual before attempting assembly or operation. Read and understand the warnings posted on the machine and in this manual. Failure to comply with all warnings may cause serious personal injury or damage to the machine.
  • Page 9 MCNC Creator Pro I-24P 1.3.2 Health and Safety 1. Always wear approved personal health and safety equipment as indicated for the materials and type of operations that will be performed. These should include a dust mask, hearing protection, safety clothing, and safety glasses/face shield. Wear ear protectors (plugs or muffs) even during short periods of operation.
  • Page 10 MCNC Creator Pro I-24P 6. Keep the electrical cord away from sharp edges, heat or moving parts, and do not store materials on top of it. Position the cord so it will not become a tripping hazard. 7. While the use of an extension cord is discouraged, if it is necessary verify the cord is in good condition, meets the current requirements, and is located so as not to present a tripping hazard.
  • Page 11 MCNC Creator Pro I-24P 1.3.6 Operational Practice 1. Never leave the machine running unattended. Always be in close reach of the emergency stop button. 2. Turn off the power and do not leave the machine until it comes to a complete stop.
  • Page 12 MCNC Creator Pro I-24P NOTES:...

  • Page 13: Setup And Assembly

    MCNC Creator Pro I-24P 2.0 Setup and Assembly Please carefully read and understand all setup and assembly instructions before beginning this procedure. Packaging Contents  Two (2) Stand Uprights (front and back)  Two (2) Cross Braces  One (1) shelf plate ...

  • Page 14: Tools Required For Assembly

    MCNC Creator Pro I-24P Tools Required for Assembly  #2 Philips Screwdriver  10mm, 13mm and 17mm sockets, and socket wrench  24mm open-end wrench  2mm and 3mm Allen key  Level Packaging contents for CNC machine  One (1) router table assembly ...
  • Page 15 MCNC Creator Pro I-24P 1. Thread one (1) loose hex-nut onto each of the four (4) leveling feet. 2. Turn the square stand uprights upside down. Do this on top of the cardboard packaging to prevent scratching. Install the four (4) leveling feet and four (4)

  • Page 16: Installing The Router Table On The Stand

    MCNC Creator Pro I-24P b. Insert the toolbox into the stand from the top. The hangers will fit snugly between the braces on either side of the toolbox. c. The front can be slid forward to rest within the opening on the stand upright.
  • Page 17 MCNC Creator Pro I-24P 1. Insert the control box into the front right cavity of the toolbox or for a stand without a toolbox sit the control box on the shelf. Power and communication cables will run through the lower hole in the back of the toolbox.
  • Page 18 MCNC Creator Pro I-24P NOTES:...

  • Page 19: Electrical Components

    Grounding Instructions Laguna Tools CNC machines must be grounded. This grounding provides a path of least resistance for electrical current, which during a malfunction will reduce the risk of electrical shock.

  • Page 20: Operations

    MCNC Creator Pro I-24P WARNING If grounding instructions are not completely understood or if in doubt as to whether the machine is properly grounded, a qualified electrician should be consulted. The use of extension cords should be discouraged. It is recommended to place the machines as near to the power source as possible.

  • Page 21: Operations

    MCNC Creator Pro I-24P 4.0 Operations Before beginning, Laguna Tools recommends that the operator become familiar with the handheld controller for operation of the machine, setting up a job, and processing a file. Controller Toolpaths that are created in the design software are communicated to the CNC router through the handheld controller.

  • Page 22: Home Position

    MCNC Creator Pro I-24P a. Clamps b. Fixtures c. Vacuum hold-downs (optional accessory) d. Double-sided tape 3. Turn on the machine by rotating the green switch to the right. The controller display should light, displaying the loading screen. The emergency stop button may need to be released if it has been used.

  • Page 23: Moving The Router (Spindle) Head

    MCNC Creator Pro I-24P Selecting the HOME button will display the HOME Type menu where several options are available, such as: 1. Home all 2. Home X (X-Axis only) 3. Home Y (Y-Axis only) 4. Home Z (Z-Axis only) During troubleshooting, each axis may be selected individually to test the position and operation of the Home sensors.
  • Page 24 MCNC Creator Pro I-24P Low Speed (LSP) – has a grid of 0.1mm for positional movements and a continuous speed that is set at 1500mm/min default. High Speed (FSP) – has a grid of 0.5mm for positional movements and a continuous speed that is set at 2500mm/min default.

  • Page 25: Setting Work Origin

    MCNC Creator Pro I-24P e. When all axes have been set, press OK a final time to approve the movement. Once the movement has been approved, all three (3) axes will move simultaneously to the specified locations. Be mindful of fixtures and any hold-downs that may become obstructions during movement.
  • Page 26 MCNC Creator Pro I-24P i. Place the device on top of the material, centered under the cutting tool. It is recommended using the top of the material, however, be sure to select this in the design software when setting up the material parameters.

  • Page 27: Programming Additional Origin

    MCNC Creator Pro I-24P Once the Origin is completely set, the coordinate screen will reflect this information by showing both the X and Y axes zeroed. The Z-Axis will have raised to the programmed safe height after touching the puck and will reflect that distance.

  • Page 28: Setting Spindle Rpm

    MCNC Creator Pro I-24P In the Menu + 1 area (coordinate state #2), the Origin would be set for the second piece of material. The materials can be loaded onto the machine, preferably using a fixture for ease of referencing.

  • Page 29: Speed Scale Adjustment

    MCNC Creator Pro I-24P a. Use the X+/- arrows to scroll up or down the list. b. Highlight the desired selection and press OK to select. 3. The files in that directory will be displayed. a. Display shows three (3) files at a time.

  • Page 30: Pausing During Toolpath Operation

    MCNC Creator Pro I-24P 2. During toolpath operation – While the file is in operation, the Y+/- buttons can be used to increase or decrease the Speed Scale in 0.1 (10%) increments. Cannot exceed 1.0 (100%) of the feed-rate programmed in the software.

  • Page 31: Power Failures

    MCNC Creator Pro I-24P a. Previously stored Breakpoints can be overwritten. b. Use the X+/- buttons to scroll through the list. c. Use the OK button to select the desired location. Before resuming from a Breakpoint, a HOME operation needs to have been performed if the machine was just restarted.
  • Page 32 MCNC Creator Pro I-24P NOTES:...

  • Page 33: Richauto B18E Functions

    MCNC Creator Pro I-24P 5.0 RichAuto B18E Functions 1. The RichAuto motion control system uses 1-button and 2-button combination functions. 2. Only the most used button functions are covered in this section. 3. The RichAuto B18E Handheld Controller (HHC) features the following buttons (from top left):...
  • Page 34 MCNC Creator Pro I-24P Keypad Functions (from upper left to bottom right) BREAK WORK – Resumes work from saved break point. TOOL SET – Enables Z-Axis automatic toolset function. ADVANCED FUNCTION – Advanced Process menu. REPEAT MACHINING – Repeat last machining process.

  • Page 35: B18E Menu Paths

    MCNC Creator Pro I-24P Common Combination Keypad Commands OK + MENU – Update Controller Software MENU + 0 – Machine Coordinate State (identified by prefix A) MENU + (1-9) – Workpiece Coordinate States (store up to nine different systems) MENU + MODE – Enter Coordinates for Go To Position MENU + SPINDLE –...
  • Page 36 MCNC Creator Pro I-24P 5.2.1 Machine Setup...
  • Page 37 The parameters in Machine Setup are set by the manufacturer. It is normally not necessary to change the default settings. Please consult a Laguna Tools technician before making any changes. Pulse Equiv (Pulse Equivalence) - Set the number of pulses sent to the motor for every 1 mm of movement Table Size –...
  • Page 38 MCNC Creator Pro I-24P Dist Time Limit (Distance Time Limit) – Set the time the machine can be idle before returning to continuous mode. The default is 30 seconds. Input Confi (Input Configuration) – Enable or disable the input port.
  • Page 39 MCNC Creator Pro I-24P Work Speed – Set the work speed. Default work speed: 6000 mm/min, default fast speed: 3000 mm/min. Safe Height – Set the Z-Axis maximum lift height. Default height is 40.000 mm. Auto Scale – Set the speed scale for toolpath movement. Set in 0.1 (10%) increments. Cannot exceed 1.0 (100%).
  • Page 40 MCNC Creator Pro I-24P Auto Upgrade – Updates the system online; does not affect system parameters. 5.2.4 Operate File Copy File – Copy files from the U-Disk to internal memory. Del File (Delete File) – Delete files from internal memory.

  • Page 41: Advanced Processing

    MCNC Creator Pro I-24P 6.0 Advanced Processing Functions found under the Advanced Processing category serve to perform a specialized task. The Advanced Processing menu can be accessed using the key combination of RUN + HIGH/LOW. Array Allows multiple copies of a file to be processed along a set number of rows and columns.

  • Page 42: Mirror Work

    MCNC Creator Pro I-24P Mirror Work Allows a job to be mirrored on either the X or Y-axis (it is recommended using an Origin point in the center of the material). Tool Changing While the controller does not allow automatic tool-changing as an option, there are other helpful selections available.

  • Page 43: Part Work

    MCNC Creator Pro I-24P a. FinAct (Finish Action) – press DELETE to change the settings. i. Pickup Z – Will leave the X and Y-axis wherever they are at the end of the file operation, raising the Z-axis to the set safe height (default).

  • Page 44: Calculate Boundaries

    MCNC Creator Pro I-24P 3. The normal file parameters will be displayed and operation will begin once approved. Calculate Boundaries This application will calculate the boundaries of the file. Allowing a user to verify that an operation will fit within the machine limitations.

  • Page 45: Calculate Work Time

    MCNC Creator Pro I-24P Regardless of the type chosen, this program does not use an origin. It accepts the current position of the bit to be the starting point (0,0) with all movements based on that location. A “soft limits error” may occur if the limits entered cannot be supported from the current location.

  • Page 46: Scale Work

    MCNC Creator Pro I-24P To use the Find Break No. option, select Find Break No: 1. Select the file (either from U-Disk or internal memory). 2. Prompt will give the following instructions (use X+/- buttons to scroll). a. Press OK to resume from existing break.

  • Page 47: Data Restoration And Updates

    However, restoration of the factory settings is easily accomplished. Many machines have been equipped with restore files within the internal memory of the controller. Restore files for each machine are available. If needed, Laguna Tools can email these files for emergency repair.
  • Page 48 Occasionally as software evolves, updates may become available for the controller firmware. When this happens, the updates may be supplied to customers by Laguna Tools. Much like the Backup/Restore files, the current version of the firmware Update may be used to correct certain controller software settings.

  • Page 49: Maintenance

    MCNC Creator Pro I-24P 8.0 Maintenance To ensure proper machine operation, it is recommended that the prismatic guides and rolled ballscrews on all axes are kept clean regularly wiped down with a light machine oil lubricant (such as 3-IN-ONE oil).
  • Page 50 MCNC Creator Pro I-24P The output from the pump is going directly into the radiator. From there the fluid travels up the wire chain to the spindle then back to the pump through the return tube. To flush the system, removing all the old coolant and preparing for the new fluids: 1.

  • Page 51: Troubleshooting

    MCNC Creator Pro I-24P 9.0 Troubleshooting Mechanical and Electrical Problems Symptom Possible Cause Correction Short circuit in line cord or plug. Inspect cord or plug for damaged insulation and shorted wires. Motor will not start, fuses blown Loose or separated connection.

  • Page 52: Controller Functions Problems

    MCNC Creator Pro I-24P Symptom Possible Cause Correction Loose cutter Tighten cutter in spindle collet. Spoil boards not flat. Check that spoil boards are flat Router cutting depth and clean prior to fitting job. inconsistent. Excessive play in Z-axis Inspect and correct if needed.
  • Page 53 MCNC Creator Pro I-24P Symptom Possible Cause Correction Insufficient power supply. Have qualified electrician check incoming power supply. Local power grid unstable. Contact power company. Controller keeps restarting automatically. Controller damaged. Connect controller to computer via USB cable. If problem still occurs, replace controller.
  • Page 54 MCNC Creator Pro I-24P Symptom Possible Cause Correction Working speed exceeds Z-Axis Set to safe speed in: maximum speed. MENU/Machine Setup/Max Speed Limit. Z-axis depth not consistent each Loose coupling or transmission Tighten connecting parts. time same file is processed and slipping.
  • Page 55 MCNC Creator Pro I-24P Symptom Possible Cause Correction Poor connection of between the Inspect connections inside touch-off device and gantry touch-off device and gantry. connections. Router head does not stop after contacting tool touch-off puck. Poor connection of spindle with Restore proper connection.
  • Page 56 MCNC Creator Pro I-24P NOTES:...

  • Page 57: Parts List

    MCNC Creator Pro I-24P 10.0 Parts List Part No. Description Size RichAuto-B13E HANDHELD CONTROLLER LT00002 HANDHELD CNC CONTROLLER CABLE VW-I/30V/80C LT00003P ELECTRIC CABINET ASSY. LT00003B ELECTRIC CABINET ASSY. FU-10A FUSE FU-5A FUSE LT00004 POWER CORD 15AWGX30X2100L PLUG: LK762OP LT00005 MILLING FORM ZERO GAUGE GDZ.23-1C@80/2.2...
  • Page 58 MCNC Creator Pro I-24P Part No. Description Size LT00020 Z-AXIS MOTOR SEAT SFC20C-8.6.35 COUPLING HS-SCW-M4x12 HEX SOC HD SCR TK268D-02A5 STEPPER MOTOR *NOT USED* HS-SCW-M4x10 HEX SOC HD SCR LT00026 RUBBER PAD HS-SCW-M5x12 HEX SOC HD SCR LT00027 X-AXIS BALLSCREW...
  • Page 59 MCNC Creator Pro I-24P Part No. Description Size W-M4 FLAT WASHER SW-M4 SPRING WASHER W-M5 FLAT WASHER SW-M5 SPRING WASHER A0450.21.KR52 X-AXIS DRAG CHAIN LT00048 SENSOR FIXED PLATE SW-M3 SPRING WASHER *NOT USED* LT00051 RIGHT SIDE COVER *NOT USED* FH-SCW-M6x25 HEX SOC FLAT HD CAP SCR M6xP1.0x25L...
  • Page 60 MCNC Creator Pro I-24P Part No. Description Size BGXS15BN-2820-NZO-20-20 Y-AXIS LINEAR GUIDE BGXS15BN-1120-NZO-20-20 Y-AXIS LINEAR GUIDE BGXS15BN-1420-NZO-20-20 Y-AXIS LINEAR GUIDE HS-SCW-M4X20 HEX SOC HD SCR HS-SCW-M4X20 HEX SOC HD SCR HS-SCW-M4X20 HEX SOC HD SCR 4040M4 SQUARE NUT 4040M4 SQUARE NUT...
  • Page 61 MCNC Creator Pro I-24P Part No. Description Size LT00069B Y-AXIS BALLSCREW LT00069C Y-AXIS BALLSCREW LT00070 Y-AXIS MOTOR SEAT HS-SCW-M5x20 HEX SOC HD SCR LT00072 BASE REAR PLATE HH-SCW-M5x20 HEX HD SCR W-M10 WASHER LT00075 TABLE FOOT HW-2x60 HEX WRENCH LT00077...
  • Page 62 MCNC Creator Pro I-24P NOTES:...

  • Page 63: Warranties

    Laguna Tools Customer Support Website. The labor required to install replacement parts is the responsibility of the user. Laguna Tools is not responsible for damage or loss caused by a freight company or other circumstances not in our control. All claims for loss or damaged goods must be notified to Laguna Tools within twenty-four (24) hours of delivery.
  • Page 64 Laguna Tools Customer Support Website. The labor required to install replacement parts is the responsibility of the user. Laguna Tools is not responsible for damage or loss caused by a freight company or other circumstances not in our control. All claims for loss or damaged goods must be notified to Laguna Tools within twenty-four (24) hours of delivery.
  • Page 65 MCNC Creator Pro I-24P Laguna Tools Warranty...
  • Page 66 Laguna Tools, Inc. 744 Refuge Way Grand Prairie, TX 75050 800-234-1976 www.lagunatools.com Copyright © 2023 Laguna Tools, Inc. All rights reserved.
