10. Technical Specification
Recommended separation distances between portable and mobile RF communications equipment and the EQUIPMENT or
SYSTEM – for ME EQUIPMENT or ME SYSTEM that are not LIFE – SUPPORTING
Recommended separation distances between portable and mobile RF communications equipment and the MAT1210001
Alternating Control Unit.
The MAT1210001 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled.
The customer or the user of the system can help prevent electromagnetic interference by maintaining a minimum distance between
portable and mobile RF communications equipment (transmitters) and the system as recommended below, according to the
maximum output power of the communications equipment.
Related maximum output
power of transmitter (W)
0.01
0.1
1
10
100
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters (m) can be
estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the
transmitter in watts (W) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection
from structures, objects and people.
SERVICE MANUAL
Separation distance according to frequency of transmitter (m)
150 KHz to 80 MHz
d = 1.167√P
0.117
0.369
1.167
3.689
11.667
DHG-HEALTHCARE.COM
80 MHz to 800 MHz
d = 1.167√P
0.117
0.369
1.167
3.689
11.667
800 MHz to 2.5 GHz
d = 2.333√P
0.233
0.738
2.333
7.379
23.333
