ESCALADE GOALRILLA B6100W Owner's Manual

Basketball system
Hide thumbs

Advertisement

Quick Links

Download this manual
O W N E R ' S M A N U A L
1. Read this manual carefully before starting assembly. Read each step completely before beginning
each step.
2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons
before assembling or ordering parts.
3. Tomake assembly of your basketball system easier, use the Hardware Identifier on page 3
and 4 to identify and sort all fasteners. Check all cartons for kits. All hardware is not
located in one kit.
4. Do not tighten hardware until instructed to do so. If hardware is tightened too soon, mounting
holes may not align and parts may not easily fit together. Leave locknuts slightly loose until you are
instructed to tighten them.
An electric screwdriver is helpful in assembly. However, please set at low torque and use caution
5.
because you could overtighten the hardware and strip the screws.
Save this instruction and your proof of purchase (receipt) in the event that the manufacturer
6.
has to be contacted for replacement parts.
Please Do Not Return This Product To The Store!
Contact Escalade Sports customer service department at:
Phone:
1-888-USA-GOAL
Fax:
1-866-873-3536
E-mail:
basketball@escaladesports.com
Mailing Address:
Escalade Sports
PO Box 889
Evansville, IN 47706
Please visit our World Wide Web site at:
ON-LINE TROUBLE SHOOTING
ON-LINE PARTS REQUESTS
ADDITIONAL ESCALADE® SPORTS PRODUCT INFORMATION
Escalade® Sports products may be manufactured and/or licensed under the following patents.
6419596, 6179733, 5919102, 5071120, 4798381, 4424968, D326128
Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
®
Toll
Free !
Toll
Free !
www.G oalrilla.com
TECHNICAL ASSISTANCE
FREQUENTL Y ASKED QUESTIONS
MODEL NO.
B6100W
DC72
BASKETBALL SYSTEM
2L-7221-03
2011 Escalade Sports

Advertisement

loading
Need help?

Need help?

Do you have a question about the GOALRILLA B6100W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ESCALADE GOALRILLA B6100W

Summary of Contents for ESCALADE GOALRILLA B6100W

  • Page 1 FREQUENTL Y ASKED QUESTIONS ADDITIONAL ESCALADE® SPORTS PRODUCT INFORMATION 2L-7221-03 Escalade® Sports products may be manufactured and/or licensed under the following patents. 6419596, 6179733, 5919102, 5071120, 4798381, 4424968, D326128 2011 Escalade Sports Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
  • Page 2 4L-8090-01...

  • Page 3: Hardware Identifier

    HARDWARE IDENTIFIER 5/8”-11 x 11-1/2” Hex Bolt (1 Piece) 1/2” X 1-1/4” Dia. Plastic-Washer (4 Pieces) / 1 2” -13 x 1” / 1 2” Flat Washer Hex Bolt (2 Pieces) (2 Pieces) Pull Pin (1 Piece) 1/2” Split Lock Washer (2 Pieces) Hardware located in 4A-7810-00 box 1/2”-13...
  • Page 4 HARDWARE IDENTIFIER 3/8” X 19mm Flat Washer (4 pieces) 1/2”-13 x 11” (2 Pieces) Hardware required for rim assembly 1/2”-13 X 1-1/2” Hex Bolt (2 Pieces) 3/8”-16 X 3-3/8” Hex Bolt (4 Pieces) 3/8” X 19mm Flat Washer (4 pieces) / 1 2”...
  • Page 5 INSTALLATION TIMELINE Prior to anchor system and goal assembly, call utility services for location of underground utility lines before you dig. Vertical main post assembly is a two part process. PART 1 PART 2 Day 1. Complete Anchor System Installation Instructions. Day 5.
  • Page 6 GOALRILLA ASSEMBL Y INSTRUCTIONS (Day 5) TOOLS REQUIRED FOR THE FOLLOWING STEPS 1 - 15/16" open end wrench 1 - Level 1 - 15/16” socket and ratchet (optional) 1 - Tape Measure 1 - 9/16” Deep Well Socket & Ratchet 1 - Rubber Mallet 1 - 3/4”...
  • Page 7 Secure Actuator (#16) to Lower Arm (#11) using one bolt (#8), two flatwashers (#37), four plastic washers (#53) and one hex nut (#54). See Figure 5. Tighten bolts (#7) and (#8) snug but, do not over tighten. Board Arms must pivot freely.
  • Page 8 DRAIN HOLE DRAIN HOLE Attach Upper Arm (#6) to both Middle Arms (#24) as shown in Figure 7, using bolt (#10), two Flat Washers (#3), three plastic Washers (#5) and Hex Nut (#4) in each arm. Figure 7 Attach Upper Arms (#6) to Lower Arm (#11) as shown in Figure 7, using bolt (#10), two Flat Washers (#3), three plastic Washers (#5) and Hex Nut (#4) in each side of Lower arm (#11).
  • Page 9 12. Attach Rim Beam (#25) to Upper Arm (#6), using four bolts (#46), four Flat Washers (#26), four Flat Washers (#45) and Hex Nut (#33) but do not tighten until instructed to do so in Step 19. Make sure that angled end is attached to Upper Arm (#6).
  • Page 10 13. Locate hardware needed to mount pole to anchor bolts. You will need, eight flatwashers (#37), four lock washers (#36), four hex nuts (#35) and four thread protectors (#34). Note: Do not remove the nuts you installed in step 2 (pg. 5). PLACING THE POST ON THE ANCHOR SYSTEM 14.
  • Page 11 19. Place a level across rim assembly and adjust rim until it is level. Finish tightening the four nuts. At this time also, tighten ATTACHING BACKBOARD TO BOARD ARMS hardware from Step 12. REQUIRES AT LEAST FOUR CAPABLE ADULTS. Note: DO NOT over tighten these bolts. This is a pivot point.
  • Page 12 22. Adjust unit to lowest position. Use a tape measure to measure from the top of the rim to the playing surface. Stick Height Decal (#17) to back of Actuator (#16) with the measured height mark aligned with bottom of Actuator Sleeve (#15). See Figure 12. Figure 12 Grease fitting Figure 13...
  • Page 13 Two adults are recommended for this step, one to level and one to adjust the bottom #35 nuts. If further leveling is required loosen top #35 nuts but do not loosen past the top of #39 “J” Bolt. DO NOT REMOVE NUTS #35 Place a level on pole and adjust bottom nuts #35 with a 15/16”...

  • Page 14: Limited Lifetime Warranty

    ® Subject to proper installation and normal Residential use, Escalade Sports warrants, subject to the limitations below, to the original retail purchaser all structural components of the Goalrilla™ System to be free of defects in material and workmanship for the duration of ownership by the original retail purchaser.

  • Page 15: Care And Maintenance

    CARE AND MAINTENANCE BACKBOARD CARE AND MAINTENANCE Items needed to clean backboard: 100% cotton soft cloth, (only) Glass cleaner Clean backboard using only a 100% Cotton soft cloth and glass cleaner . Clean glass as you would clean household windows. Strong cleansers will damage backboard and void warranty .
  • Page 16 2L-7221-03...
  • Page 17 2L-7221-03...
