X-401W
power
supply
| Pinout Diagram
Vin+
Vin-
Vout
Gnd
In1+
In1-
In2+
In2-
1C
1NC
1NO
2C
2NC
2NO
Power Supply Input +
Power Supply Input -
Vin - 0.7V (or 11V with POE)
Ground (common)
Optically-Isolated Input 1 +
Optically-Isolated Input 1 -
Optically-Isolated Input 2+
Optically-Isolated Input 2-
Relay 1 common
Relay 1 Normally Closed
Relay 1 Normally Open
Relay 2 Common
Relay 2 Normally Closed
Relay 2 Normally Open
