Owner's Manual
Commercial Electric Storage Water Heaters
Standard Models:
315C336, 315C348, 315C360
315C636, 315C648, 315C660
Installation Details
Owner's Information
Warranty
For advice, repairs and service, call:
1300 365 115 (Australia)
0800 729 389 (New Zealand)
Carefully remove all packaging and
transit protection from the heater before
installation. Dispose of the packaging
responsibly using re-cycling facilities
where they exist.
Specifications and materials may change without notice.
Effective for the above model numbers of Titan electric storage water heaters manufactured
and sold after 1st July 2020.
H0426 0426 Rev B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the titan 315C336 and is the answer not in the manual?

Questions and answers
