Milwaukee 48351314 Quick Start Manual

IMPORTANT SAFETY INSTRUCTIONS
Read
WARNING
instructions. Failure to follow all
instructions may result in electric shock, fire
and/or serious personal injury. Save these
instructions.
The base and remote are designed to be
•
powered by AA batteries properly inserted into
the units. Do not attempt to use with any other
voltage or power supply. Do not use zinc-carbon
batteries.
• Do not mix new and used batteries. Do not mix
brands (or types within brands) of batteries.
• Do not mix
non-rechargeable batteries.
• Install batteries according to polarity (+/–)
diagrams. Do not install batteries backwards.
Batteries can explode or leak.
• Do not crush, drop, damage, or expose
batteries to high temperature. Under abusive
conditions, liquid may be ejected from the
battery, avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts
eyes, additionally seek medical help.
• Do not incinerate or dismantle batteries.
Properly dispose of used batteries immediately.
• For indoor use only.
SYMBOLOGY
Volts
Direct Current
Read Operator's Manual
SPECIFICATIONS
Alignment Base Cat. No. ...................... 48351314
Volts...........................................................
Battery Type...........................................
Ingress Protection.............................................
Drop Rating.....................................................
Working Range (Remote W/Base) ..................
Adjustment Horizontal Range.............
Micro-Step Accuracy.....................
Mounting Thread...........................................
Total Movement................................
Remote Control Cat. No. ......................
Volts.............................................................
Battery Type...........................................
Drop Rating.......................................................
Maximum Relative Humidity (RH).....................
Decreasing Linearly Relative Humidity (RH)....
Recommended Ambient
Storage Temperature.........................
Operating Temperature .....................
WIRELESS LASER ALIGNMENT BASE W/ REMOTE
Cat No. 48351314
and understand
rechargeable
4.5 V DC
3 x AA LR6
12 m at 38 m
2.38 mm at 30 m
1/4"-20
18° left to right
22801314
3 V DC
2 x AA LR6
for up to 31°C
at 40° C
-25°C to 60°C
-17°C to 50°C
FUNCTIONAL DESCRIPTION
all
1
and
9
8
11
1. Plumb point indent
2. Rotating top plate
3. Laser level holder
4. Motorised fixed base
5. Height adjustable legs
6. Fast sweep buttons
7. Single step/slow sweep buttons
8. Power button
9. Power/movement LED
10. Threaded 1/4"-20 tripod insert
11. Battery door
IP54
Screw the
0.9 m
corresponding holes on the base of the laser mount.
38 m
Attaching Laser to Laser Mount
The alignment base can be used with MILWAUKEE
M12™, MILWAUKEE
alkaline lasers.
• To attach, align the grooves on the laser pivot
bracket with the base laser level holder brackets
on the rotating top plate. Slide the laser back until
3 m
it latches into in place.
80%
• To remove, carefully slide the pivot bracket on the
forward out of the base of the mount.
50%
1
2 3
10
ASSEMBLY
Attaching Legs
three supplied
REDLITHIUM™ USB, and
®
4
5
6
7
8
9
legs into the
®
