W78H Quick Start
W78H Quick Start
Package Contents
Package Contents
 TIP
TIP
We recommend that you use the accessories provided or approved by Yealink. The use of unapproved third-
party accessories may result in reduced performance.
Assemble W78H
Assemble W78H
1. Insert the battery into the handset.
1
W78H Quick Start

Advertisement

loading
Need help?

Need help?

Do you have a question about the W78H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yealink W78H

Summary of Contents for Yealink W78H

  • Page 1 W78H Quick Start Package Contents Package Contents  TIP We recommend that you use the accessories provided or approved by Yealink. The use of unapproved third- party accessories may result in reduced performance. Assemble W78H Assemble W78H 1. Insert the battery into the handset.

  • Page 2: Hardware Introduction

    4. Connect the charging cradle and charge the handset.  TIP Use Yealink-supplied power adapter (5 V/0.6 A). A third-party power adapter may damage the handset. Check the charging status on the top-right corner of the LCD screen. Hardware Introduction...
  • Page 3 W78H Quick Start Item Item Description Description Receiver Receive audio in receiver mode. Power LED Indicator Indicate call status, message status, and charging status. Phone Screen Show information. Soft Keys Access the function directly. It depends on the operating situation.

  • Page 4: Power Led Indicator

    W78H Quick Start Answer an incoming call. Enter the redial calls list. Off-hook Key Place a call in receiver or headset mode. Keypad Provide digits, letters, and special characters. TRAN Key Transfer a call to another party. Toggle mute feature on or off.
  • Page 5 W78H Quick Start Idle screen introduction Idle screen introduction Items Items Introductions Introductions Weak to strong: Signal No reception: Strength Eco mode+ is on: Battery Low to full: Status Need Charging: Status Bar Displays the feature status icons. The status icons are displayed when features are activated.

  • Page 6: How To Update Firmware

    W78H Quick Start Display the registered line number and the corresponding line (display user name by default). Outgoing The default outgoing line will be displayed in the first line of the screen. Line Display the icon of line status. The icon indicates the corresponding feature assigned to the Line Status line.
