- Page 1 Betriebsanleitung IDEAL 4810-95 EP Operating Instructions IDEAL 4850-95 EP Mode d'emploi IDEAL 5221-95 EP Gebruiksaanwijzing IDEAL 6550-95 EP Manuale d'istruzione Instrucciones de uso...
-
Page 3: Table Of Contents
IDEAL 4810-95 EP; IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP Table of contents General ..........1.1 Application..........Installation ..........5 2.1 Preparing for installation ......5 2.2 Power supply.......... 5 Operation ..........6 Checklist..........6 3.1 Operating elements........ 6 IDEAL 4810-95 EP 3.2 Start - up .......... -
Page 4: General
IDEAL 4810-95 EP; IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP General 1.1 Application The machine is designed for cutting reams of s Danger! paper to a specified dimension. Dimension Non-compliance of the instructions may setting may be performed via keys or manually endanger persons. -
Page 5: Installation
IDEAL 4810-95 EP; IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP Installation 2.1 Preparing for Installation IDEAL 5221 The machine must be installed on a sturdy,dry The machine is delivered ready for operation. and level floor. s Danger! - The machine must not be located outside. -
Page 6: Operation
IDEAL 4810-95 EP; IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP 3.1 Operating elements Operation s Danger! The machine may only be operated by persons who have read and understood the operating instructions and safety instructions. s Danger! Check safety devices are complete and function prior to starting the machine and after replacing the blade. -
Page 7: Start - Up
IDEAL 4810-95 EP; IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP (1) Safety-guard 3.2 Start - up (2) Two-hand activation (3) Backgauge control (4) Clamp returns (not with IDEAL 4810) (5) Main switch (6) Rotary control for backgauge setting... -
Page 8: Cutting To Specified Dimensions
IDEAL 4810-95 EP; IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP Cutting to specified dimensions Eject function ¢ If you press the key instead of , after insertion of the dimension the backgauge moves to the front for taking out the paper. -
Page 9: Programming
IDEAL 4810-95 EP; IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP Entering a program 3.3 Programming fi " - Press " appears in the Display Enter program number 1..9. First figure in Display = program number. Enter dimension 1..9, or move the backgauge to the desired measurement with 5 5 5 5 7 7 7 7 . -
Page 10: Working With Programs
IDEAL 4810-95 EP; IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP ¢ £ Program keys Working with programs £ ¢ By means of buttons dimension at your choice can be reached. £ ¢ fi resp. resp. appears on the display. -
Page 11: Maintenance
IDEAL 4810-95 EP; IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP Maintenance s Danger - Maintenance work may only be performed by trained staff. - Replacement of blade and cutting stick may only be performed when the main switch is switched off. -
Page 12: Blade Replacement
IDEAL 4810-95 EP; IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP 4.2 Blade replacement Despite correctly set cutting depth and new cutting stick it is not possible to achieve a clean cut fi sharpen or replace the blade. Blade demounting s Danger! The blade is very sharp. -
Page 13: Blade Mounting
IDEAL 4810-95 EP; IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP Blade mounting - The 3 eccentrics (1) should then be used to lower the blade until the paper is cut along the entire length of the blade (The blade must remain parallel to the cutting stick). -
Page 14: Maintenance All 7 Days
IDEAL 4810-95 EP; IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP 4.4 Maintenance cycle all 6 months 4.3 Maintenance cycle all 7 days - Turn main switch to position 0. - Disconnect from the mains. - Remove the upper housing and the wooden front panel or the front housing. -
Page 15: Trouble Shooting
IDEAL 4810-95 EP; IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP Trouble shooting d) Cause: Backgauge not in the right position fi on Display. s Danger! Remedy: Disconnect from the mains before starting Please inform the technical service. any service work or before removing the cover. -
Page 16: Technical Data
IDEAL 4810-95 EP; IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP Technical data Accessories Sound level DIN 45635-1-27: 71dB(A) The exact technical specifications can be found l Important! on the manufacturer's plate on the machine. Only fit accessories recommended by the manufacturer. - Page 17 IDEAL 4810-95 EP; IDEAL 4850-95 EP; IDEAL 5221-95 EP; IDEAL 6550-95 EP 03-01-10 B5221G2w.doc...
