EN Operating Instructions
THE 56
IDEAL EBA THE 56 EN 9700319 9700330
08-2022 20230327zm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the THE 56 and is the answer not in the manual?

Questions and answers

Related Manuals for IDEAL THE 56

Summary of Contents for IDEAL THE 56

  • Page 1 EN Operating Instructions THE 56 IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 2: Table Of Contents

    Changing the Cutting Stick Maintenance and Upkeep Yearly Maintenance / Safety Inspection Multi-Touch Display Settings Possible Malfunctions Multi-Touch Display Possible Malfunctions Cutting Machine Accessories / Options Technical Data EC Declaration of Conformity IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 3: Safety Precautions

    Do not use any spray cans with flammable content near to the cutting machine! Do not use any flammable cleaning agents. Blade must always be covered by the pressing bar. This machine is constructed for „one-man operation“ only! IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 4 • In the event of the screen suddenly flickering or the background light failing, then contact your dealer for the matter to be repaired. Do not yourself attempt to repair the monitor. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 5 • Safety light beam curtain • Screwed down panels The dangerous cutting movement is protected by a safety light beam curtain and a two- hand cutting activation! IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 6: Intended Use

    (Main switch to “0”). Intended use This machine is for cutting stacks of paper to a certain size. This machine is only for a “One-man operation”! Caution! Any staples and the like damage the cutting blade. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 7: Overview And Parts Designation

    Main switch (lockable) Tool panel (tool kit) Adjustable foot Belt cover Rear table cover Light beam curtain holder Cover Multi-touch display Safety light beam curtain Mechanical foot pressing Base frame Rear table IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 8: Scope Of Delivery / Options

    Set of side tables Order No. 9000 552 (The add-on instructions are enclosed with the side tables.) Base frame panelling Order No. 9000 553 (The add-on instructions are enclosed with the base frame panel.) IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 9: Setting Up

    Release cam lever and hold, turn the swivel axis, tighten cam lever. • Carefully insert display flat cable into the appropriate machine socket. • Screw down the cover with 2 screws. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 10: Commissioning

    • Light beam curtain: Holding the test rod (tool kit) in the protective field is to result in the immediate stoppage of an activated cycle. It is recommended keeping a test handbook. STOP STOP IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 11: Operating

    Paper installation at the back gauge side stop to the left and right . Use the provided paper knock-up block adjusting paper stacks. (Move back gauge forwards before turning the stack of paper). IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 12 • Blade must always be at the top and covered by the clamp, do not touch the blade (see Page 29). Injury risk. Termination of cutting Release both operating buttons of the two-hand activation system. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 13: Operating / Multi-Touch Display

    Tap on symbol , set from = cutting line indicator off to and save with Button sound Tap on symbol , set from = button sound off up to and save with IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 14 • To change RAPID SELECION dimensions, press the corresponding dimension and keep pressed, then to • To clear RAPID SELECION dimensions, press the corresponding dimension and keep pressed, then to IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 15 40 - 2 = 38, then or instead of immediately tap on , the calculated START 38 dimension is immediately moved to. Note: This function can also be used in the PROGRAM MODE. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 16 • Move to cutting marks with the operating control , using symbol accept the dimension moved to in the program step and with incorporate into the program. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 17 Eject function • Place hook at “Eject” (automatically goes to ) when you want the paper stack to be ejected. Note: Cannot be selected simultaneously with the consecutive cut function. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 18 The first program step is moved to.  TheActivate cut. The second step is moved to etc. On carrying out the last step, tap on the symbol to restart the program. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 19 • To move a program, select it, tap on , select the folder where the program is to be moved to, select and save with IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 20 Set by swiping upwards/ downwards and save with Eject dimension (cm) • With open the appropriate column. Tap in the eject dimension (max. 15.00 cm) and save with IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 21 • Under an activated application (>1), a coloured bar indicates how many cuts could still be carried out before replacing the blade (an extra pointer pops up). • Input value 0 deactivates this application. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 22 • Change to the “home” mode, carry out test steps, possibly repeat operation as described. Power adaption (as-delivered state 100% = full cutting speed) tip and set.  reducible from 100% to 60% IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 23 Updates: 1. Go to https://www.ideal.de/en/downloads-software and download the latest update. 2. Unpack the update (.zip file) into the root directory of the USB stick. 3. Insert the USB stick into the switched-on machine.
  • Page 24 Contact: Service  • www.krug-priester.com • service@krug-priester.com HELP Operating instructions THE 56 • Swiping upwards /downwards and to the left / right allows you to scroll through the detailed digital operating instructions. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 25: Blade Change

    The blade is thus back in the top position. Fine tuning comes in the form of individual locking options. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 26 2 unscrewed blade screws. • Unscrew the remaining 3 blade screws • Slightly slacken both grips simultaneously and remove downwards blade and blade changing device. Blade weight approx. 4 kg IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 27 • Gently remove the replacement blade from the blade case and screw down with the blade changing device! • Ensure there is a 7 mm or 0.276 spacing! • Blade edge must be covered! Warning! Injury risk! IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 28 • Fit and tighten the 3 blade screws • Slacken blade changing device at the grips and remove. • Loosely screw in the remaining 2 screws Remove all tools from the working area. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 29 (40 Nm). • Simultaneously press both actuators, blade travels upwards at a reduced speed. Warning! The blade must always be covered in the top position by the clamp bar! IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 30 (cutting, lowering, cutting, lowering, ...). Ending blade change mode • Tap on the “okay-Grafik” to end or quit the blade change mode. A test cut then follows at a reduced speed. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 31: Changing The Cutting Stick

    , keep pressed and fine-tune anticlockwise (disengage into the individual locking options). Keep carrying out test cuts until all sheets are cut through (cutting, lowering, cutting, lowering, ...). IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 32: Maintenance And Upkeep

    Note: More than 5 hours of operation /day means carrying out maintenance work that much more often. Without a properly closed cover for the rear table, the machine must not be placed into service. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 33: Yearly Maintenance / Safety Inspection

    A test sticker must be clearly visible when affixed to the machine. This safety inspection is prescribed for Germany, in other countries it is something we recommend. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 34: Multi-Touch Display Settings

    User (user) . The R, G and B colors can be individually adjusted in the “User” color setting. / i / R Back with the key or save with the MENU key. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 35 PC and check if the PC requirements. / i / R audio output cable is connected to the “LINE Back with the key or save with the IN” at the monitor. MENU key. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 36: Possible Malfunctions Multi-Touch Display

    Press the key until DDCCI appears, MENU then press the key again. Tap key until OFF is selected and MENU key again. / i / R To finish, tap the key twice. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 37: Possible Malfunctions Cutting Machine

    Turn the main switch to Position “0”, wait 30 seconds before turning it back to Position “I” Have none of the specified solutions helped you with your problem? Contact: Service  • www.krug-priester.com • service@krug-priester.com Service IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 38: Accessories / Options

    • No. 9000 625 Cuttings container, mobile • No. 4860 141 Options Set of side tables (2 pcs.) • No. 9000 552 Base frame panelling • No. 9000 553 Included in the delivery IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 39: Technical Data

    Subject to technical changes. For specific technical data, please refer to the information on the identification plate of the machine. To file a warranty claim, the device must still bear its original identification plate. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 40 This machine is approved by independent safety laboratories and is in compliance with the EC-regulations 2006/42/EG and 2014/30/EU. Sound level information: Sound measurement to EN 13023 : 70 db (A) Subject to alteration without notice. IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 41 • Quality management system according to DIN EN ISO 9001:2015 • Environmental management system according to DIN EN ISO 14001:2015 • Energy management system according to DIN EN ISO 50001:2018 IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...

  • Page 42: Ec Declaration Of Conformity

    BS EN ISO 13857; BS EN ISO 11204; BS EN 13023; BS EN ISO 13849-1 Authorized representative for technical documentation 10.02.2022 Date Krug & Priester GmbH & Co. KG Simon-Schweitzer-Str. 34 D-72336 Balingen (Germany) - Managing Director - IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 43 Remarks IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
  • Page 44 Made in Germany Krug & Priester GmbH & Co. KG Simon-Schweitzer-Str. 34 D-72336 Balingen (Germany) www.krug-priester.com IDEAL EBA THE 56 EN 9700319 9700330 08-2022 20230327zm...
