BELL SYSTEM PRACTICES
Station
Operations Manual
Station
Sets
1.00
INTRODUCTION
TELEPHONE SETS - 302E, G, 5302G
COMMON BATTERY- CONNECTIONS
SECTION C38.551
Issue 1, Aug., 1957
AT&TCo Standard
1.01
This section covers the combination
of
apparatus,
circuit
diagram, and connections
for the 302E and
G,
and
the 5302G telephone sets.
1.02
These
sets are
used for the following services:
• Individual
lines.
• 2-party message rate (manual and ring party
• PBX
stations.
dial)
.
•
2-party flat rate.
• 4-party
semiselective.
•
Multiparty
nonselective.
• Multiparty divided code.
FIG. 1-302 TYPE
FIG.
2-5302
TYPE-G HANDSET
FIG.
3-5302
TYPE-F HANDSET
Hand
Tel. Set
Code
302E
302G
5302G
TABLE A-COMBINATION OF APPARATUS
Components
Use
Apparatus
Induction
Handset
Dial
Blank
Coil
Ringer
Manua
l
-
82A
or
94A
Dial
Dial
Fl
SH
or
6A
-
lOlA
BlAL
Fl,
F4, Gl
SM
or
6H
-
Copyright,
1957,
by American Telephone and Telegraph Company
Printed
in
U.S .A.
Capacitor
19SA
Filter
(Optional)
-
61P
61S
Page 1
