- Page 1 Operator's Manual LOCKDOWN™ 1-MAN CONCEALMENT KIT MODEL LD701 PRODUCT MEETS INDUSTRY STANDARDS RECOGNIZED BY Get parts online at P/N: 43081 © 2023 RETI C/N: 43244 www.HuntRiversEdge.com All Rights Reserved REV1: 03/24/23 PARTICIPATING MEMBER...
-
Page 2: Table Of Contents
INTRODUCTION Rivers Edge® Treestands are engineered with you the hunter in mind. We appreciate your purchase of one of our world class treestands. Follow these few simple instructions and your stand will provide you many years of trouble-free pleasure. Instructions should be kept in a safe place and reviewed at least annually. -
Page 3: Warnings
Operator’s Manual LOCKDOWN™ 1-MAN CONCEALMENT KIT READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE ASSEMBLY STOP WARNING INSPECTION AND MAINTENANCE Read and understand all of the manufacturer’s Warnings and Instructions and use all safety devices BEFORE EACH USE PERFORM THE FOLLOWING: provided by the manufacturer. -
Page 4: Hardware Identification Chart
Operator's Manual LOCKDOWN™ 1-MAN CONCEALMENT KIT TOOLS REQUIRED 7/16”IN WRENCHES HARDWARE LIST Item Part No. Image Description YELLOW PLASTIC 23572 WASHER 2 MM KNOB 23604 ADJUSTMENT YELLOW PLASTIC 26913 SPACER 6 MM BOLT 30129 M6 X 30 MM YELLOW PLASTIC 36703 SPACER 12 MM Check for parts online at www.HuntRiversEdge.com or call 800-345-6007... - Page 5 Operator’s Manual LOCKDOWN™ 1-MAN CONCEALMENT KIT HARDWARE LIST Item Part No. Image Description BOLT 1/4 X 42914 4-3/4 IN 48752B NUT 1/4 IN BOLT 1/4 X 8909B 1-1/4 IN Check for parts online at www.HuntRiversEdge.com or call 800-345-6007...
-
Page 6: Assembly Instructions
Operator's Manual LOCKDOWN™ 1-MAN CONCEALMENT KIT ASSEMBLY INSTRUCTIONS IMPORTANT ASSEMBLY TIP: All assembly must be done in this order at ground Do not tighten any nut and bolt combinations completely level before uprighting. until all parts are assembled together! Finger tighten plus one turn of a wrench only! This will temporarily hold the Do not remove labels/warnings from product, they are lock-nut on the bolt while helping alignment of all parts! - Page 7 Operator’s Manual LOCKDOWN™ 1-MAN CONCEALMENT KIT Attach the shooting rail to the rest of the stand using two 1/4 X 4-3/4 IN bolts (8), four yellow washers (1), two thin yellow spacers (3), two thick yellow spacers (5), and two nuts (15).
- Page 8 Operator's Manual LOCKDOWN™ 1-MAN CONCEALMENT KIT LOOP HOOK Connect the hook and loop flaps, located at the center of the back panel, together between the top and bottom treeblade. SEE FIGURE 2A. Connect the center buckle behind the top treeblade. SEE FIGURE 2B. FIGURE 2A FIGURE 2B HOOK...
- Page 9 Operator’s Manual LOCKDOWN™ 1-MAN CONCEALMENT KIT Drape the center rigid bar of the front panel (6) over the front side of the shooting rail. The Lockdown™ logo should be readable when sitting in the stand. Connect the two top buckles. SEE FIGURE 4. FIGURE 4 Work around the concealment kit frame while wrapping the lower rigid bars, of the front panel, under the frame...
- Page 10 Operator's Manual LOCKDOWN™ 1-MAN CONCEALMENT KIT Wrap the buckles located in the lower corners of the front panel around the frame and tighten. SEE FIGURE 7. FIGURE 7 Wrap the upper flaps of the back panel around the backrest and connect to each side of the front panel using two REAR buckles.
-
Page 11: Illustrated Parts Breakdown
Operator’s Manual LOCKDOWN™ 1-MAN CONCEALMENT KIT ILLUSTRATED PARTS BREAKDOWN PARTS LIST ITEM # PART # DESCRIPTION QTY. 42923 MIDDLE FRAME 23572 YELLOW PLASTIC WASHER 2 42925 FRONT FRAME 42929 RIGHT REAR FRAME 23604 KNOB 42930 LEFT REAR FRAME 26913 YELLOW PLASTIC SPACER 6 42933 LEFT SLEEVE 42934... - Page 12 Ardisam, Inc. Phone: 800-345-6007 1730 Industrial Avenue, Fax: 715-822-2124 Cumberland, WI 54829 www.huntriversedge.com *All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvements, product images may not be exact. Warning labels in some product images may have been removed for photography purposes only.
