Operator's Manual
RE632
Uppercut™
Maximum Height - 20' 11" to shooting rail
Maximum Field Rating - 300 lb
Tree Diameter Range - 12" to 20"
Wear Your
Harness!
GAS/OIL
RATIO
50:1
P/N: OMRELD004
REV5: 02/17/15
Get parts online at
© 2015 RETI
www.HuntRiversEdge.com
All Rights Reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Uppercut RE632 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rivers Edge Uppercut RE632

Summary of Contents for Rivers Edge Uppercut RE632

  • Page 1 Operator's Manual RE632 Uppercut™ Maximum Height - 20' 11" to shooting rail Maximum Field Rating - 300 lb Tree Diameter Range - 12" to 20" Wear Your Harness! GAS/OIL RATIO 50:1 P/N: OMRELD004 REV5: 02/17/15 Get parts online at © 2015 RETI www.HuntRiversEdge.com All Rights Reserved.

  • Page 2: Table Of Contents

    WARRANTY Rivers Edge Tree Stands, Inc. (“RETI”) offers a one year warranty for all components of the treestand. These warranties apply to the original owner with a proof of purchase. These warranties begin on the date of purchase by the first retail consumer and continue for the period specified above. These warranties apply to products that are not modified, abused or used in a manner that deviates from the product’s intended usage.

  • Page 3: Warnings

    Operator's Manual Rivers Edge® Uppercut™ WARNINGS WARNING WARNING DO NOT USE THIS PRODUCT UNTIL YOU HAVE WATCHED DO NOT EXCEED THE TOTAL FIELD RATING- 300 LBS. THE INCLUDED TREESTAND SAFETY DVD, UNDERSTAND IT REPLACE ANY AND ALL TREESTAND STRAPS EVERY TWO...
  • Page 4 Operator's Manual Rivers Edge® Uppercut™ ALWAYS… NEVER… • Be physically fit, mentally alert, and well rested before using this • Sleep in a treestand product. • Use on wet, soft, or unstable ground. • Read, understand and follow all warnings and instructions before • Exceed the total field rating of 300 lbs. use and save for future reference. • Attach to a dead, odd-shaped, leaning, diseased, loose barked • Use the provided Full Body Harness (Fall Arrest System) that meets trees or utility poles. TMA standards immediately upon reaching foot platform. • Use on trees with a diameter smaller than 12 inches or no larger than • Be fully aware of foot placement.

  • Page 5: Inspection And Maintenance

    Operator's Manual Rivers Edge® Uppercut™ INSPECTION AND MAINTENANCE SCHEDULE FOR ALL RIVERS EDGE® PRODUCTS • Inspect all webbing, rope, cord, and strap assemblies for wear or damage. • Inspect cables and cable ends for damage or kinking. • Inspect all hardware and chain components for damage. • Inspect for any structural damage to product. (Return to factory for repair or discard product if any damage is found.) • Inspect all nut and bolt assemblies to be certain none are loose. • Inspect for any missing parts. • Lubricate all pivot and slide together points with powder graphite to prevent noise, wear, and rust.

  • Page 6: Assembly Instructions

    Operator's Manual Rivers Edge® Uppercut™ ASSEMBLY INSTRUCTIONS Tools needed – two 7/16” wrenches, one 9/16" wrench IMPORTANT ASSEMBLY TIP: DO NOT TIGHTEN NUT & BOLT COM- BINATIONS COMPLETELY UNTIL ALL PARTS ARE ASSEMBLED TO- GETHER! FINGER TIGHTEN ONLY PLUS ONE TURN OF A WRENCH...
  • Page 7 Operator's Manual Rivers Edge® Uppercut™ 4. Attach the front of the ladder side rails (410053) to the front platform steel washers ladder upper tree blade side rails using (2) provided 1/4-20 x 2” bolts, locknuts and (4) steel washers. SEE FIGURE 3.
  • Page 8 Operator's Manual Rivers Edge® Uppercut™ SEAT ASSEMBLY 9. a. Position the factory assembled mesh seat (360018) upside down Bolt will enter on a sturdy, hard surface. SEE FIGURE 6. at an angle. b. Insert (1) 1/4-20 x 2-3/4” bolt through the rear fixed brace (410122) and side rail of mesh seat.
  • Page 9 Operator's Manual Rivers Edge® Uppercut™ SEAT ASSEMBLY CONTINUED e. Remove the factory installed "locking" bolt and locknut from the front hinged brace (410112), and set aside. Hinge the brace slightly to aid in assembly. SEE FIGURE 10. f. Insert (2) 1/4-20 x 1-1/4" bolts through the front hinged brace and each side rail, and finger tighten locknuts.
  • Page 10 Operator's Manual Rivers Edge® Uppercut™ 10. Remove the locknuts from the (2) 1/4-20 x 2-1/4” bolts that were 1/4-20 x 1-1/4" bolt previously attached to the rear of the seat assembly. Continue by attaching the seat assembly to the ladder side rails using (2) provided shooting 1/4-20 x 2-1/4”...
  • Page 11 Operator's Manual Rivers Edge® Uppercut™ 16. Sections are assembled on the ground in the following order; bottom section (10166 3-step ladder); second section (10168 3-step ladder with stabilizer bar hole); third section (10168 3-step ladder with stabilizer bar hole); fourth section (10170 3-step ladder w/ support brace mounting holes);...

  • Page 12: Finished Uppercut Ladder

    Operator's Manual Rivers Edge® Uppercut™ FINISHED UPPERCUT™ LADDER ratchet straps top section fourth section 20' tie-off ropes third section cam strap second section stabilizer bar stabilizer bar extension tube spring lock pins bottom section Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5...

  • Page 13: Setup And Use Instructions

    Operator's Manual Rivers Edge® Uppercut™ SETUP AND USE INSTRUCTIONS WARNING During installation and removal of ladder treestands, you must DOUBLE CHECK ASSEMBLY STEPS TO BE CERTAIN YOU HAVE always and properly use the included Full Body Harness (Fall Arrest CORRECTLY ASSEMBLED THIS PRODUCT. System). Refer to the Full Body Harness instructions included with STUDY YOUR NEW STAND TO BECOME FAMILIAR WITH ALL this product for proper use.
  • Page 14 Operator's Manual Rivers Edge® Uppercut™ 3. With two people securely holding the ladder, use the three point WARNING contact climbing method to slowly climb the ladder and carefully keep a constant hand grip on the ladder at all times. Always lean...

  • Page 15: Bolt Identification Chart

    Operator's Manual Rivers Edge® Uppercut™ BOLT IDENTIFICATION CHART Bolts shown are for size reference only. Extra hardware may be included in the parts bag. 1/4-20 x 1-1/4" grade 5 hex head bolt 1/4-20 x 1-1/2" grade 5 hex head bolt 1/4-20 x 2"...

  • Page 16: Parts Explosion/Parts List

    Operator's Manual Rivers Edge® Uppercut™ LADDER PARTS EXPLOSION Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5...
  • Page 17 Operator's Manual Rivers Edge® Uppercut™ LADDER PARTS LIST NO EXTENSIONS AVAILABLE FOR THIS MODEL. NEVER MODIFY OR EXCEED ORIGINAL STATED USE HEIGHT! KEY # PART # DESCRIPTION QTY. 10162 WELDMENT TREE BLADE UPPER LADDER KEY # PART # DESCRIPTION QTY. 10164 WELDMENT, TREE BLADE LOWER 410122...
  • Page 18 Operator's Manual Rivers Edge® Uppercut™ NOTES Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5...
  • Page 19 Operator's Manual Rivers Edge® Uppercut™ NOTES Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5...
  • Page 20 Rivers Edge® Treestands, Inc. 1160 Eighth Avenue, PO Box 755 Cumberland, WI 54829 800-450-EDGE (3343) | Fax 715-822-2124 Email: info@huntriversedge.com *All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvements, product images may not be exact. Warning labels in some product images...
