- Page 2 CONGRATULATIONS, You have just purchased an IMG-BRASIL equipment, product of the highest quality, safety and efficiency. Founded in 1989, IMG-BRASIL is a respected company as one of the best and most complete companies in the field of gastronomy equipment manufacturing. Constant innovation and improvement of its products, using top-of-line raw materials, ensure superior products consumed in Brazil and in more than 25 countries worldwide.
-
Page 3: Table Of Contents
INDEX 1. Safety Information ......................... 4 1.1 General Warnings ........................4 1.2 Mechanical Safety ........................5 2. Technical Characteristics ......................6 2.1 Main Components ........................6 2.2 Technical Data ........................... 6 3. Installation ............................. 7 3.1 Equipment Layout ........................7 3.2 LPG Gas Installation - Recommendations and Care .............. -
Page 4: Safety Information
1. Safety Information 1.1 General Warnings • Cautions / precautions must be observed when installing, using, maintaining and discontinuing use of this equipment; • Before carrying out any operation (assembly, use, maintenance and reuse after prolonged use of the equipment), read the manual carefully; •... -
Page 5: Mechanical Safety
1.2 Mechanical Safety • Before operating the equipment, make sure that the gas installation does not leak, if the grease collector is well fitted. • Only insert products specific to which the equipment is intended onto the plate and never place your hands or flammable products close to or directly on the heated plate. -
Page 6: Technical Characteristics
2. Technical Characteristics 2.1 Main Components For the equipment described in this manual, safety in use, cleaning, maintenance and maximum hygiene are guaranteed by the design and special design of all parts, as well as the use of stainless steel and other materials suitable for contact with the foods. The equipment was designed with the following characteristics: •... -
Page 7: Installation
ATTENTION! Characteristics like: model, serial number and protection grade of the equipment are provided on the label (figure below). MODELO: CFG06EXXX Equipment CHAPA DE FRITURA A GÁS ESPECIAL Model Nr:000001 Lote:XXXXXX Ano Fab.: XXXX Serial Number CFG06EXXXX000001 TENSÃO: CORRENTE: FREQUÊNCIA: PROTEÇÃO: PESO: IPX1 XX kg... -
Page 8: Lpg Gas Installation - Recommendations And Care
ATTENTION! This equipment uses LPG (liquefied petroleum gas) for heating, and cannot be installed in closed environments where there is no air renewal, as this gas is highly toxic. Keep the gas cylinder at least 1.5 m away from sockets, switches, electrical switches, or any device subject to sparks or flames, where these in contact with LPG gas could cause an explosion, causing serious accidents with risk of death to the operator. - Page 9 ATTENTION! The equipment must be placed in an airy place, but without an air current, thus avoiding the flames in the burners going out, causing gas leaks. The gas installation must be done by a qualified technician for this function and observing the safety rules.
-
Page 10: Safety Procedures And User Instruction
IMPORTANT The manufacturer is not responsible for possible direct or indirect damage caused by non- compliance with the rules and instructions presented in this manual. 3.3 Safety Procedures and User Instruction The professional who sells the equipment must instruct the user on the correct functioning of the equipment and must hand over this instruction manual. -
Page 11: Operating Procedures
• Gas Regulator Knob (flame level): used to regulate the flame according to the desired level. • Automatic Ignitor: used to light the burner flame. (Note: For operation you will need to insert a 1.5V AA battery). IMPORTANT "The manufacturer does not provide the 1.5V AA battery as part of this product, therefore, You will need to purchase them separately for the equipment to work."... - Page 12 ATTENTION! After opening the gas valve, quickly light the burners, as the gas will already be spreading into the air. Light one burner at a time, and as many as necessary to carry out the necessary operation. Make sure the burners are completely lit. If ignition fails and if you smell gas in the room, do not light.
-
Page 13: Cleaning And Maintenance
ATTENTION! After finishing the work stage and turning off the burners, close the gas pressure regulator (registration), as if it remains open, the pressure exerted on the hose could damage or rupture it, which could cause a fire or other accidents. ATTENTION! During operation, hot vapors and splashes of superheated oil or fat may be emitted. -
Page 14: Breakdown Maintenance And Procedures
The detachable parts must be removed from the equipment and washed with warm water and soap or neutral detergent. Clean the corners well, eliminating all residue from the process. When cleaning the structure, dilute soap, neutral detergent, or ammonia-based remover in warm water and apply with a soft cloth. -
Page 15: Prolonged Interruption In Use Of The Equipment
ATTENTION! Preventive maintenance requires a trained professional. Whenever an item related to the safety of the equipment is removed (such as when performing maintenance), put it back in its proper place and confirm that they are performing their function correctly. Detecting broke parts or without the correct functionality, please contact the nearest authorized service center. - Page 16 PROBLEMS POSSIBLE CAUSES SOLUTIONS Yellow flame, Problem mixing with Send the equipment to the nearest authorized equipment generating oxygen. service station or contact the factory. soot Send the equipment to the nearest authorized Burst, loose or broken gas service station or contact the factory, as there is a register risk of accidents.
-
Page 17: Anexxes
7. ANEXXES Exploded View Drawing... -
Page 18: Spare Parts List
Spare Parts List Position Code Description Quantity CJT1285 Top Frame POS157 Stainless Steel Hex Nut CJT1284 Exhaust Pipe Set CRC1452 Front Coating IGN004 Automatic Ignitor Set BOT044 Regulator Knob PRN012 Allen screw CXA024 Grase Collector PEP031 Foot RBT018 Rivet RBT014 Stainless Steel Rivet CRC1574 Chimney GAB275 Structure PTC251 Front Internal Protection... - Page 19 Notes...
- Page 20 IMG BRASIL Gastronomy Machinery Industry Ltda. CNPJ 11.193.347/0001-14 - CREA 131726-3 Road Antônio Heil - KM 23 Nº 5825 - Neighborhood: Limoeiro ZIP CODE 88352-502 - Brusque - SC - Brazil Phone/fax. +55 47 3251-5555 - Site: www.metvisa.com.br Mail: sac@metvisa.com.br - export@metvisa.com.br...
