Page 2: Table Of Contents
Exploded Drawing ......................15 Spare Parts List ....................... 16 WARNING! Features, photos and figures presented in this manual should be considered for information purposes. BIMG BRASIL reserves the right to make modifications as may be necessary without prior notice . -
Page 3: Safety Information
1. Safety Information 1.1 General Instructions • There are care/precautions that should be observed when assembling, use, maintenance and discontinue using this device; • Before performing any operation (installation, use, maintenance and reuse after prolonged interruption in the use of the device), read the manual; •... -
Page 4: Technical Specifications
2. Technical Specifications 2.1 Main Components To the device described in this manual, safety in use, cleaning, maintenance and maximum hygiene are guaranteed by design and the special design of all parts, and also used stainless steel and other suitable materials for the contact with fruit. The device is designed with the following features: •... -
Page 5: Technical Data
2.2 Technical Data Nominal Nominal Measures Voltage Capacity Model Weight Current WidthxHeightxLength (mm) (kg) DG10110M60N4 362x1043x600 25,1 DG10220M50N1 362x1043x600 25,1 DG10220M50N2 362x1043x600 25,1 DG10220M50N4 362x1043x600 25,1 DG10220M60N4 362x1043x600 25,1 DG20110M60N4 356x1043x695 31,0 DG20220M50N1 356x1043x695 31,0 DG20220M50N2 356x1043x695 31,0 DG20220M50N4 356x1043x695 31,0 DG20220M60N4 356x1043x695... -
Page 6: Electrical Connection
WARNING! The installation and the place where it will be set must comply with the rules of prevention of risk and safety at work (Regulatory Standard present on your country) . The manufacturer is not responsible for possible direct or indirect damages caused by non- compliance with rules and instructions in this manual . -
Page 7: Security Measures And User Instructions
All device’s models described on this manual are single phase and mono-voltage, it is, 110 V or 220 V. If necessary to change device’s voltage contact manufacturer or dealer. WARNING! Before connecting your device, always checks if the main supply voltage is the same as the device voltage. -
Page 8: Device's Use
4. Device’s Use 4.1 Utility This device was made only to extract pulp of Açaí and similar fruits. 4.2 Commands The devide consists of only an On/Off switch located on the side of the case. -
Page 9: Operating Procedures
See description of each button: • On/Off Switch – used to turn on an off the device. In position "1" turn on, in position "0" turn off. 4.3 Operating Procedures Before operating your device, perform a cleaning of components that have contact with pulp (Bowl, Bowl Protection, Strainers, Beater, etc.), to do so make sure that the device is disconnected from the power outlet, then disassemble. - Page 10 • Assembly: The assembly procedure is the reverse of removal. When remounting the Strainer, choose the suitable model to the process and mount it on the bottom of the Bowl with fold down. Use screws and nuts to lock the Bowl Support on device’s structure. Mount the Beater’s Ledge on the Strainer Hole.
- Page 11 WARNING! Never turn on the device with the Beater, Bowl or Bowl Protection out of position, because it could cause accidents. • Operation: Before turning on the device, be sure that the demountable components (Bowl, Beater e Strainer) are well seated, the Door is locked by the Lever, and the device’s voltage is according to the electrical outlet.
-
Page 12: Cleaning And Maintenance
IMPORTANT The operator must use the appropriate PPE (personal protective equipment). For example: use cap in hair preventing it from locking up in moving parts and appropriate gloves to guarantee hygiene when handling fruits, also protects the operator during the pulp processing. - Page 13 WARNING! Once the cleaning of the Bowl Protection is finished, reset the Protection and the screws on the Beater Axis. Never operate the device without the Bowl Protection locked with screws and seated on the Bowl, it might cause an accident. IMPORTANT The manufacturer is not responsible for possible direct or indirect damages caused by non- compliance with rules and instructions in this manual.
-
Page 14: Annex
6. ANNEX Wiring Diagram... -
Page 15: Exploded Drawing
Exploded Drawing... -
Page 16: Spare Parts List
Spare Parts List Posição Código Descrição Quant. Aplicação para o Modelo CJT911 Assemble Structure ETR130 Structure ROL006 Bearing EIX047 Semi Axis APE004 Locking Ring PNL009 Elastic Pin LUV005 Sleeve CRC1040 Bottom Cover Electric Motor 1/3 cv – 127 V – 60 Hz MTE283 Electric Motor 1/3 cv –... - Page 17 Notes...
- Page 18 Notes...
- Page 20 BIMG-BRASIL Gastronomy Machinery Industry Ltda. CNPJ 11.193.347/0001-14 - CREA 131726-3 Rod. Antônio Heil – KM 23 Nº 5825 – Limoeiro CEP 88352-502 - Brusque – SC – Brazil Phone/fax. +55 47 3251-5555 - Site: www.metvisa.com.br E-mail: sac@metvisa.com.br - export@metvisa.com.br - export2@metvisa.com.br...
