HRS EXRH Manual

Headphone stand system
Hide thumbs

Advertisement

Table of Contents

EXRH HEADPHONE STAND SYSTEM
A Low Noise Floor Is Fundamental

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXRH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HRS EXRH

Summary of Contents for HRS EXRH

  • Page 1 EXRH HEADPHONE STAND SYSTEM A Low Noise Floor Is Fundamental...
  • Page 2 All items are inspected 100% to verify the assembly fits are up to our exacting standards. This rigorous protocol, combined with precision design, results in a product that is a pleasure to install, use, change, or expand at any time. From all of us here at HRS, we truly hope you enjoy our product.

  • Page 3: Safety Instructions

    Do not place any tall objects on the top level of the EXRH Headphone Stand System. A tall object is any object with a height that is greater than the depth of the EXRH, or any object that has a height greater than its own width or length.
  • Page 4 Leveling the EXRH Headphone Stand System - The EXRH Headphone Stand System is now ready to be leveled. Place the provided level on top of the EXRH, and apply gentle pressure against each side of the system to see if it rocks back and forth. If the system does rock back and forth...
  • Page 5 The maximum load capacity of each level of the EXRH Headphone Stand System is 250 pounds (113 kg). Never load more than 250 pounds onto a single level of the EXRH, and never exceed a total load of 1000 pounds (453 kg) for the full system.
  • Page 6 Modifying your EXRH Headphone Stand System will require use of certain tools and materials that were included in the original EXRH shipment. If you no longer have the WD-40 3-in-1 oil, HRS grip pad, nylon wrench, or bubble level, please contact your authorized HRS dealer.
  • Page 7 If you are adding or removing parts at any location other than the bottom of the system, carefully lift the now unsecured Horizontal Support Assembly off the bottom of the EXRH, and set it aside (photo 6). Struts and Horizontal Support Assemblies can now be removed one layer at a time to expose any locations where parts are being added, removed, or replaced.
  • Page 8 Step 4. Identify the four Struts of the correct size for this level of the system. Keep in mind that the EXRH is upside-down, so the Horizontal Support Assembly resting on the work surface is the top level. The Struts will provide component spacing equal to 3.5 inches less than their total length (including threads).
  • Page 9 Frame Mount and the corresponding Strut, as in photo 13. If this is the case, lift the EXRH Horizontal Support Assembly slightly to relieve pressure on the polymer ring, and make sure it falls back in place to sit completely flat on the Strut, then carefully lower the assembly straight down back into place.
  • Page 10 WD-40 3-in-1 oil to the top end of each thread. Photo 14 If your EXRH Headphone Stand System includes another level, repeat steps 4-7 to install Struts and the Horizontal Support Assembly for the next layer. Be sure to select the correct size of Strut for each level of your stand to provide adequate space for each of your components.
  • Page 11 Assembly of the EXRH Headphone Stand System is now complete. Carefully lift and flip the EXRH upright, and move it to the desired final location for use in your system. Depending on the size of your system, this may require multiple people. Make sure to orient the system so that the front face with the HRS logos faces forward.

  • Page 12: Care And Maintenance

    Do not wash the interior flex element of the HRS Isolation Base feet, even if you see a coating or white substance on the surface of the flex element. This coating is intentional and is put in the flex element to protect the isolation material from the environment.

  • Page 13: Limited Warranty

    This receipt must clearly list the model and serial number, the date of purchase, the name and address of the purchaser, the authorized HRS dealer, and the purchase price. Harmonic Resolution Systems reserves the right to modify the design of any product without obligation to purchasers of previously manufactured products, and to change the prices or specifications of any product, without notice or obligation to any person.
  • Page 14 3. Harmonic Resolution Systems shall not be responsible in any way for damage to finishes resulting from normal use, or exposure to sunlight or the environment, even within the normal and extended limited warranty period. During the limited warranty period, Harmonic Resolution Systems will repair or replace any defective components free of charge.
  • Page 15 (MADE IN USA) All Harmonic Resolution Systems Inc. products are 100% made in The United States of America by skilled craftsmen using only the finest materials and our personal dedication to the highest workmanship standards. ARMONIC ESOLUTION YSTEMS 2495 Main Street, Suite 227 Buffalo, NY 14214 Telephone: 716-873-1437 Web: www.AVisolation.com...
