Summary of Contents for HRS SXR
- Page 1 HARMONIC RESOLUTION SYSTEMS INSTRUCTION FOR INSTALLATION OF SXR SOLID BRACE INSERTS INTO SXR FRAME SYSTEM The Foundation of Great System Performance...
- Page 2 The SXR Signature Series Frame performance is achieved when latest production version of the SXR Solid Brace Insert is installed at every isolation base location in a SXR system.
- Page 3 Set-Up Instructions The SXR Solid Brace Inserts are use in pairs as shown in photo 1 below. Photo 1 Step 1. Prior to installing the SXR Solid Brace Inserts remove any existing isolation bases from the desired frame location and make sure all of the bolts that attached the cross bars to the frame are not tight (back off 1/8 turn from full tight position).
- Page 4 Once the SXR Solid Brace Inserts are in place you can hand tighten the bolts on the cross frame at each level. There is no need to over torque the frame.
-
Page 5: Care And Maintenance
Care and Maintenance The SXR Solid Brace Inserts are a very low maintenance item that will provide many years of trouble-free performance by applying these basic care instructions. Clean the external surfaces of the SXR Solid Brace Inserts per the same instructions received with your SXR Frame. - Page 6 4. Harmonic Resolution Systems shall not be responsible in any way for damage to finishes resulting from normal use and exposure to sunlight and the environment even within the normal and extended warranty period. During the warranty period, Harmonic Resolution Systems will repair or replace any defective components free of charge.
