- Page 1 RXR AUDIO STAND The Foundation of Great System Performance...
- Page 2 Harmonic Resolution Systems, Inc. will enable your audio/video source and amplification components to achieve high levels of performance. The RXR Audio Stand, which includes the HRS Isolation Base as the primary shelf system, is a perfect match for the HRS Damping Plates and Nimbus Products.
-
Page 3: Safety Instructions
Safety Instructions IMPORTANT WARNINGS! Do not place any tall objects on the top shelf of the RXR Audio Stand. A tall object is any object with a height that is greater than the length of the isolation base. A tall object is also any object that has a height greater than its own width or length. -
Page 4: Setup Instructions
Setup Instructions The RXR Audio Stand consists of a frame structure and isolation bases that support each component. The components required to assemble the frame are shipped in one or more boxes. The number of boxes depends on the system size. Each box containing parts for the frame will be marked with the model number starting with RXR. - Page 5 Step 1. Your stand might be fully assembled. If so, skip to Step 7 and proceed. To start assembling the RXR Audio Stand, locate one of the RXR Side Rails. Place it with the side that contains the small threaded holes facing up. Take one of the RXR Primary Supports without the threaded inserts and place it at the top of Side Rail.
- Page 6 Step 2. The Primary Support with threaded inserts will be the bottom of the stand. (Take notice that each of the Primary Supports has two shallow grooves on one side, these grooves are to indicate the front of the RXR Audio Stand. As the stand is assembled every Primary Support should have these grooves facing the same direction.) Attach the bottom Primary Support just as in Step 1.
- Page 7 Their locations will vary depending on the needed space for the components being used. To get a rough idea of where the Primary Supports should go take the component space needed and add 4 ¼” to it. The bottom of the Primary Support should be this distance from the bottom of the support above it.
- Page 8 If building a Double Wide Stand, place the Center Rail on top of the Primary Supports with the threaded inserts pointing toward the bottom of the stand. (See Picture 7.) Picture 7 As in Step 1. Use two of the ¼”-20x 1” button head fastener with a ¼” flat washer on each of the fasteners and place one of them through the Primary Support.
- Page 9 Picture 8 Step 5. Once there are at least two fasteners in each side of all the Primary Supports go back and place the last two fasteners in each side of the supports. All of the fasteners should turn in very easily, if for some reason one seems hard to turn in try moving the Primary Support slightly, this should help the fastener thread in easily.
- Page 10 Step 7. Cut a small opening in the top of the oil provided with the RXR Audio Stand and place a small amount on each of the RXR Threaded Inserts on the bottom Primary Support. (See Picture 9.) Picture 9. Screw on to each of the inserts one RXR Locking Nut and one RXR Point (See pictures 10 and 11).
- Page 11 Step 8. At this point the RXR Frame is completely assembled. (See Picture 12.) Flip the RXR Frame upright, move the frame to the exact final location for use in your system. Make sure the front of the frame is (the side with the grooves on the Primary Supports) facing into the room.
- Page 12 Picture 13 Completed Double Wide Stands You are now ready to load the HRS Isolation Bases and equipment into the RXR frame system. The RXR has a 200 lbs maximum weight limit per level and a total vertical weight limit of 600 lbs. See the chart below for clarification.
- Page 13 Resolution Systems, Inc. or your local certified retail location to arrange to have this corrected. Load the HRS Isolation Bases into the RXR Frame with the HRS logo facing the front of the rack system. Be sure that the isolation base (shelf) foot is located securely in the pocket of the RXR Frame Primary Support.
-
Page 14: Care And Maintenance
Care and Maintenance The RXR Audio Stand is a very low maintenance item that will provide many years of trouble-free performance by applying these basic care instructions. Clean the external surfaces of the RXR Audio Stand frame using a professional quality ultra soft lint-free micro-fiber cloth available in high quality automotive stores. -
Page 15: Limited Warranty
Limited Warranty Harmonic Resolution Systems, Inc. warrants the product designated herein to be free of manufacturing defects in material and workmanship subject to the conditions herein set forth, for a period of 90 days from the date of purchase by the original purchaser. - Page 16 During the warranty period, Harmonic Resolution Systems, Inc. will repair or replace any defective components free of charge. A Return Authorization Number (RA Number) obtained directly from Harmonic Resolution Systems, Inc. is required before any product is returned to Harmonic Resolution Systems, Inc. for any reason.
- Page 17 (MADE IN USA) All Harmonic Resolution Systems, Inc. products are 100% made in the United States of America by skilled craftsmen using only the finest materials and our personal dedication to the highest workmanship standards. ARMONIC ESOLUTION YSTEMS 2495 Main Street, Suite 227 Buffalo, NY 14214 Telephone: 716-873-1437 Web: www.AVisolation.com...
