Summary of Contents for HRS EXRD
- Page 1 EXRD AUDIO STAND SYSTEM A Low Noise Floor Is Fundamental...
- Page 2 All items are inspected 100% to verify the assembly fits are up to our exacting standards. This rigorous protocol, combined with precision design, results in a product that is a pleasure to install, use, change, or expand at any time. From all of us here at HRS, we truly hope you enjoy our product.
-
Page 3: Safety Instructions
Do not place any tall objects on the top level of the EXRD Audio Stand System. A tall object is any object with a height that is greater than the depth of the EXRD, or any object that has a height greater than its own width or length. - Page 4 Caps bonded into the five EXRD Frame Mounts. Place it upside-down on your work surface so the threads of the installed Caps face up, and the front face with HRS logo faces away from you (photo 1).
- Page 5 Step 3. Identify the five Struts of the correct size for this level of the EXRD. Keep in mind that the EXRD is being assembled upside-down, and so the first EXRD Horizontal Support Assembly is the top level. The struts will provide component spacing equal to 3.5 inches less than their total length (including threads).
- Page 6 Assembly and lower it onto the existing assembly so that the Strut threads pass through the EXRD Frame Mounts as in photo 7. The EXRD Frame Mounts should seat fully onto the threads and rest in full contact with the polymer rings.
- Page 7 If your EXRD Audio Stand System includes another level, repeat steps 2-6 for the next EXRD Horizontal Support Assembly to add it to the stand. Be sure to select the correct size of Struts for each level of your stand to provide adequate space for each of your components. If you have added all necessary levels to the EXRD, proceed to step 7.
- Page 8 Assembly of the EXRD Audio Stand System is now complete. Carefully lift and flip the EXRD upright and move it to the desired final location for use in your system. Depending on the size of your audio stand, this may require multiple people. Make sure to orient the EXRD Audio Stand System so that the front face with the HRS logo(s) faces forward.
- Page 9 Sliding the HRS Isolation Base feet along the shelf surfaces may scratch them. Make sure that the outside edges of each HRS Isolation Base line up with the outside edges of the EXRD Horizontal Support Assembly.
-
Page 10: Care And Maintenance
Do not wash the interior flex element of the HRS Isolation Base feet, even if you see a coating or white substance on the surface of the flex element. This coating is intentional and is put in the flex element to protect the isolation material from the environment. -
Page 11: Limited Warranty
This receipt must clearly list the model and serial number, the date of purchase, the name and address of the purchaser, the authorized HRS dealer, and the purchase price. Harmonic Resolution Systems reserves the right to modify the design of any product without obligation to purchasers of previously manufactured products, and to change the prices or specifications of any product, without notice or obligation to any person. - Page 12 3. Harmonic Resolution Systems shall not be responsible in any way for damage to finishes resulting from normal use, or exposure to sunlight or the environment, even within the normal and extended limited warranty period. During the limited warranty period, Harmonic Resolution Systems will repair or replace any defective components free of charge.
- Page 13 (MADE IN USA) All Harmonic Resolution Systems Inc. products are 100% made in The United States of America by skilled craftsmen using only the finest materials and our personal dedication to the highest workmanship standards. ARMONIC ESOLUTION YSTEMS 2495 Main Street, Suite 227 Buffalo, NY 14214 Telephone: 716-873-1437 Web: www.AVisolation.com...
