HOMCOM 824-072V70 Operating Manual page 9

b. When the air cooler is on, this key is the timing key.
Press to set the timing time, and the setting range is 1 to 15h.
When set in 15h, press this key again to exit the timing function.
c. During the reservation and timing process, the indicator light follows the time
decreasing change.
d. The timing function is not remembered when the machine is switched on and off.
6. Sterilizing (ordinary type does not have this function)
This key is valid when the machine is on or reservation state.
Click to open the sterilizing function. Switch the sterilizing button to follow UV→
anion →UV+ anion → close...cycle.
Sterilizing function switch machine has memory.
(There are two ways to eliminate bacteria: one is the anion, the other is the UV
lamp, both can be turned on at the same time, or you can choose one function to
turn on)
7. Humidification
This key is valid when the air cooler is on or reservation state.
Press this button to turn the humidification function on, and then press the
humidification function to cancel.
When the humidification function is on and the water level switch is closed, the
pump works.
When the humidification function is turned off to start, the pump starts according to
the rule of "working 3s→ stopping 3s → working 3s → stopping 3s → continuing
running".
In the process of humidification operation or when the humidification function is on,
the water in the water tank is short of water, the buzzer makes 3 long sounds and
the indicator flashes at 1Hz until the humidification function is cancelled or the
power is cut off.
After the alarm for lack of water, if the water is replenished again, the alarm will
stop, but the humidification function needs to be manually turned on again.
Humidification function in the absence of water, the switch machine has memory.
Method of Remote control battery installation
1. Gently press the battery cover to pull down and take out the battery cover.
2. Put the battery in the battery box.(Note the positive and negative direction of the
battery)
3. Put the battery cover into the original outlet and buckle it completely.
Note for Remote Control
negative
positive
8
