Linear Technology DC2121A Demo Manual page 9

parts List
ITEM QTY REFERENCE
Hardware: For Demo Board Only
1 20 E1-E20
2 3 JP1, JP2, JP3
3 1 JP4
4 1 JP5
5 8 J1-J8
6 5 XJP1-XJP5
7 4 (STAND-OFF)
8 2 STENCILS
DEMO MANUAL DC2121A
PART DESCRIPTION
TESTPOINT, TURRET, .094" pbf
HEADER 3 PIN 0.079 SINGLE ROW
HEADER 8 PIN 0.079 DOUBLE ROW
HEADER 2 PIN 0.079 SINGLE ROW
JACK BANANA
SHUNT, .079" CENTER
STAND-OFF, NYLON 0.50"
STENCILS TOP AND BOTTOM
MANUFACTURER/PART NUMBER
MILL-MAX, 2501-2-00-80-00-00-07-0
SULLIN, NRPN031PAEN-RC
SULLIN, NRPN042PAEN-RC
SULLIN, NRPN021PAEN-RC
KEYSTONE, 575-4
SAMTEC, 2SN-BK-G
KEYSTONE, 8833(SNAP ON)
STENCIL DC2121A
