Neotap - Installation Diagram - Spring NEOTAP Installation And Operation Manual

Three Way Valve
Hot water pipe
Connection
Cable
Wiring loom
Cold water pipe
COLDLWater outlet
+ 6 4 0 9 6 3 6 - 7 0 7 0 | W W W . S P R I N G N Z . C O . N Z | S A L E S @ S P R I N G N Z . C O . N Z
PIPING INSTALLATIONN
HOT Water Outlet
HOT Switch
Co2 Switch Co2 Switch - Not needed in Hot/Cold/Ambient
Power
Water
Co2 Inlet - Not needed in Hot/Cold/Ambient application
Please leave plug in
Inlet
1/4" Pipe
KDF50
(Directional Flow.
Flush black carbon
dust before
connecting to the
machine)
Application
PRVV
Directional
Flow)
Brass Tee off valve
(Plumbers Delight)
