SPRING NEOTAP
Hot, Cold, Sparkling Underbench Unit
INSTALLATION AND OPERATION GUIDE
+ 6 4 0 9 6 3 6 - 7 0 7 0 | W W W . S P R I N G N Z . C O . N Z | S A L E S @ S P R I N G N Z . C O . N Z
CONTENTS
Push Lock Fitting & Plumbers Delight Installation
Operation - Tap Buttons, Sparkling, Chilled and Hot Water
Leakage Detection Device & Swivel Warning
Specification Sheet
Please read these instructions completely before operating this unit
1
2
3
5
6
7
8
9
10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NEOTAP and is the answer not in the manual?

Questions and answers

Related Manuals for Spring NEOTAP

Summary of Contents for Spring NEOTAP

  • Page 1: Table Of Contents

    SPRING NEOTAP Hot, Cold, Sparkling Underbench Unit INSTALLATION AND OPERATION GUIDE CONTENTS Preface/Parts Piping Installation - Diagram Piping Installation Push Lock Fitting & Plumbers Delight Installation Co2 Bottle - Installation Operation - Tap Buttons, Sparkling, Chilled and Hot Water Troubleshooting Leakage Detection Device &...

  • Page 2: Preface/Parts

    Before using this machine, we advise you to read this manual thoroughly. Please follow the instructions to ensure proper operation and the lasting of the machine Top Cover Brass Tee Off Valve Regulator NEOTAP - Hot, Cold, Sparkling Faucet Co2 Bottle (Plumbers Delight) Indicating Panel KDF50 Filter Power Cord 1/4"...

  • Page 3: Piping Installation - Diagram

    PIPING INSTALLATION - DIAGRAM Neotap Faucet One way tee valve Hot Water Tube - Grey (Friction fit) Hot Water Outlet Wiring loom Co2 Bottle Co2 Inlet Water Inlet Cold water Outlet Brass Tee off KDF50 Valve (Directional Flow.Flush out black carbon...

  • Page 4: Piping Installation

    We recommend the instructions specified in this guide be followed in sequence by a qualified tradesperson for successful installation. This Neotap has a 12 month back to base warranty from purchase, but this may be voided if unsatisfactory installation results in damage to the unit.
  • Page 5 PIPING INSTALLATION 14. Open gas bottle by turning the main bottle valve anticlockwise + 6 4 0 9 6 3 6 - 7 0 7 0 | W W W . S P R I N G N Z . C O . N Z | S A L E S @ S P R I N G N Z . C O . N Z...

  • Page 6: Co2 Bottle - Installation

    Co2 BOTTLE - INSTALLATION 1. Ensure the Co2 bottle is connected firmly to the regulator and the Co2 tube is fitted correctly. 2. Slowly turn the dial on the regulator clockwise until the gauge reads 3BAR (Note: If you want to reduce the pressure you must first turn the dial anticlockwise and then vent to relieve existing pressure.
  • Page 7 Disassemble the existing flexihose from the Cold Water Tap Reconnect the plumbers delight inline Use tee off for the 1/4 inch pipe to feed the Neotap Connect the flexihose to the male plumbers delight connection to feed the mixer tap 1/4"...
  • Page 8 HOT WATER OPERATION - UNDERBENCH 1. Press the HOT button on the Faucet. Make sure the water is flowing before turning on the HOT power switch at the rear of the unit (This will ensure the HOT tank in the unit is full before turning on the element to prevent it burning out) 2.
  • Page 9 NEOTAP FAUCET - SYMBOLS HOT WATER TEMPERATURE AND ECO MODE DISPLAY When the light source is off, ECO mode will be starting to shut off water heating system after 1 minute The ECO mode will be off to start reheating automatically after 1...
  • Page 10 NEOTAP FAUCET - COLD AMBIENT INSTRUCTIONS SPARKLING COLD Turn on the COLD switch at the rear of the unit Leave to cool for 40 minutes Press the COLD button for Chilled water Please wait at least 2 seconds after the HOT button is released before pressing for Chilled or Ambient water The water will stop flowing after 1 minute.
  • Page 11 Please contact Spring Water Solutions if any of these issues persist. + 6 4 0 9 6 3 6 - 7 0 7 0 | W W W . S P R I N G N Z . C O . N Z | S A L E S @ S P R I N G N Z . C O . N Z...

  • Page 12: Troubleshooting

    Trouble Shooting + 6 4 0 9 6 3 6 - 7 0 7 0 | W W W . S P R I N G N Z . C O . N Z | S A L E S @ S P R I N G N Z . C O . N Z...
  • Page 13 LEAKAGE DETECTION - DIAGRAM This device has a leakage detection probe fitted for safety purposes. When the probe detects moisture you may notice the LED on the machine flashing accompianied by a beeping noise We recommend turning off the electricity at the power supply and calling a qualified technician to carry out this work for your safety.
