SPRING NEOTAP
NEOTAP - Hot, Cold, Ambient MultiTap
INSTALLATION AND OPERATION GUIDEDE
+ 6 4 0 9 6 3 6 - 7 0 7 0 | W W W . S P R I N G N Z . C O . N Z | S A L E S @ S P R I N G N Z . C O . N Z
CONTENTS
Please read these instructions completely before operating this unit
1
2
3
4
5
6
7
8
11
12
13
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Spring NEOTAP
Summary of Contents for Spring NEOTAP
-
Page 1: Table Of Contents
SPRING NEOTAP NEOTAP - Hot, Cold, Ambient MultiTap INSTALLATION AND OPERATION GUIDEDE CONTENTS Preface/Parts Expanded Faucet Diagram Faucet Installation Guide Neotap - Installation Diagram Push Lock Fitting/Plumbers Delight Guide Piping Installation Hot water operation - Underbench Neotap-- Faucet Operation Troubleshooting... -
Page 2: Preface/Parts
Before using this machine, we advise you to read this manual thoroughly. Please follow the instructions to ensure proper operation and the lasting of the machine Pressure Reducing Valve Brass Tee Off Valve Neotap - Underbench Faucet ((PRV) (Plumbers Delight) Boiling, Chilled, Ambient... -
Page 3: Expanded Faucet Diagram
MULTITAP - EXPANDED DIAGRAM Outlet LED Touch Control Panel Fixed Nut 8 mm Drinking Water Pipe Faucet Connection Cable Please check the parts are all correct in the box, and read the manual throughly. To install and use the faucet by following instruction to avoid damage... -
Page 5: Neotap - Installation Diagram
PIPING INSTALLATIONN Three Way Valve Hot water pipe HOT Water Outlet Connection Cable Wiring loom HOT Switch Co2 Switch Co2 Switch - Not needed in Hot/Cold/Ambient Application Power Cold water pipe Water Co2 Inlet - Not needed in Hot/Cold/Ambient application COLDLWater outlet Please leave plug in Inlet... -
Page 6: Push Lock Fitting/Plumbers Delight Guide
Disassemble the existing flexihose from the Cold Water Tap Reconnect the plumbers delight inline Use tee off for the 1/1/4"4 inch pipe to feed the Neotap Connect the flexihose to the male plumbers delight connection to feed the mixer tap 11/4"/4"... -
Page 7: Piping Installation
We recommend the instructions specified in this guide be followed in sequence by a qualified tradesperson for successful installation. This Neotap has a 12 month back to base warranty from purchase, but this may be voided if unsatisfactory installation results in damage to the unit. -
Page 8: Hot Water Operation - Underbench
HOT WATER OPERATION - UNDERBENCH 1. Press the HOT button on the Faucet. Make sure the water is flowing before turning on the HOT power switch at the rear of the unit (This will ensure the HOT tank in the unit is full before turning on the element to prevent it burning out)) 2. -
Page 9: Neotap-- Faucet Operation
MULTITAP FAUCET - SYMBOLS HOT WATER TEMPERATURE AND ECO MODE DISPLAY When the light source is off, ECO mode will be starting to shut off water heating system after 1 minute The ECO mode will be off to start reheating automatically after 1 minute when the light is on again SETTINGS SYMBOL / REHEATING - Press once to start hot water reheating... - Page 10 MULTITAP FAUCET - HOT WATER INSTRUCTIONS Turn on the COLDLD switch at the rear of the unit Leave to cool for 440 minutes Press the COLDLD button for Chilled water Please wait at least 22 seconds after the HOT button is released before pressing for Chilled or Ambient water The water will stop flowing after 1 minute.
- Page 11 Over time heating warning (Abnormal long heating time) Faucet outlet LED and HOT indicator light is blinking No water is filled into HOT Tank, need to check inlet water supply Please contact Spring Water Solutions if any of these issues persist.
-
Page 12: Troubleshooting
Trouble Shooting CAUTION:: For your safety please contact us or a qualified technician for repair if you suspect the water dispenser is damaged + 6 4 0 9 6 3 6 - 7 0 7 0 | W W W . S P R I N G N Z . C O . N Z | S A L E S @ S P R I N G N Z . C O . N Z... -
Page 13: Leakage Detection Device And Swivel Tap - Warning
LEAKAGE DETECTION - DIAGRAM This device has a leakage detection probe fitted for safety purposes. When the probe detects moisture you may notice the LED on the machine flashing accompianied by a beeping noise We recommend turning off the electricity at the power supply and calling a qualified technician to carry out this work for your safety. -
Page 14: Data Sheet
PRODUCT DATA SHEET Spring NeoTap INSTANT TAP Overview Underbench filter with integrated unit for boiling, chilled, sparkling and ambient drinking water. Model Sparkling, Boiling & Chilled, Boiling, Chilled & Ambient, Sparkling, Chilled & Ambient Filtration Premium KDF/GAC 30, 1 Micron Filtration...
