SPRING NEOTAP
NEOTAP - Hot, Cold, Sparkling MultiTap
INSTALLATION AND OPERATION GUIDE
+ 6 4 0 9 6 3 6 - 7 0 7 0 | W W W . S P R I N G N Z . C O . N Z | S A L E S @ S P R I N G N Z . C O . N Z
CONTENTS
Please read these instructions completely before operating this unit
1
2
3
4
7
8
9
10
13
15
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Spring NEOTAP
Summary of Contents for Spring NEOTAP
-
Page 1: Table Of Contents
SPRING NEOTAP NEOTAP - Hot, Cold, Sparkling MultiTap INSTALLATION AND OPERATION GUIDE CONTENTS Preface - Underbench Parts Multitap - Extended Diagram Multitap - Installation Guide Multitap - Pipework Instructions/Diagram Push Lock Fitting/Plumbers Delight Guide Co2 Bottle Install/Refill Hot water operation - Underbench... -
Page 2: Preface - Underbench Parts
Before using this machine, we advise you to read this manual thoroughly. Please follow the instructions to ensure proper operation and the lasting of the machine Pressure Reducing Valve Brass Tee Off Valve Neotap - Underbench Faucet (PRV) (Plumbers Delight) Boiling, Chilled, Ambient... -
Page 3: Multitap - Extended Diagram
MULTITAP - EXPANDED DIAGRAM Hexagonal Screw Mixer Tap Control Faucet body Drinking water rotatable Ambient water inlet water flexihose controller (Blue striped steel wire) Threaded Housing Hot inlet water flexihose Silicone Shim (Red striped steel wire) Metal Shim Three way tee C-Type Nut Screw Please check the parts are all correct in the box, and read the manual throughly. -
Page 5: Multitap - Pipework Instructions/Diagram
PIPING INSTALLATION 5/16" Pipe Wiring Loom COLD Water Mains (Tee off Valve Fitted) HOT Water Mains One Way Tee Valve (Grey and White Pipe already connected) 1/4" Pipe 2.2L Co2 Bottle Co2 Inlet + 6 4 0 9 6 3 6 - 7 0 7 0 | W W W . S P R I N G N Z . C O . N Z | S A L E S @ S P R I N G N Z . C O . N Z... - Page 6 We recommend the instructions specified in this guide be followed in sequence by a qualified tradesperson for successful installation. This Neotap has a 12 month back to base warranty from purchase, but this may be voided if unsatisfactory installation results in damage to the unit.
- Page 7 14. Open gas bottle by turning the main bottle valve anticlockwise...
-
Page 9: Co2 Bottle Install/Refill
Disassemble the existing flexihose from the Cold Water Tap Reconnect the plumbers delight inline Use tee off for the 1/4 inch pipe to feed the Neotap Connect the flexihose to the male plumbers delight connection to feed the mixer tap 1/4"... -
Page 10: Hot Water Operation - Underbench
HOT WATER OPERATION - UNDERBENCH 1. Press the HOT button on the Faucet. Make sure the water is flowing before turning on the HOT power switch at the rear of the unit (This will ensure the HOT tank in the unit is full before turning on the element to prevent it burning out) 2. -
Page 11: Mixer/Faucet Operation
MULTITAP - MIXER INSTRUCTIONS... - Page 12 MULTITAP - FAUCET INSTRUCTIONS There are 3 functions on the rotation controller and icon for turning off water supply Align the stop dispensing icon on the rotation controller with the stop dispensing icon on the faucet body to stop dispensing water - The blue LED will be on The LED light will be purple, when the water dispenser is heating HOT water...
- Page 13 MULTITAP - FAUCET INSTRUCTIONS Dispensing COLD water, the Light Blue LED will be Dispensing SPARKLING water, the Green LED Will be on MULTITAP - HOT WATER FAUCET INSTRUCTIONS To dispense HOT Water first rotate the controller to HOT water icon to unlock - HOT Water will not be dispensed.
-
Page 14: Faq,Leakage Detection Device And Swivel Tap - Warning
Trouble Shooting CAUTION: For your safety please contact us or a qualified technician for repair if you suspect the water dispenser is damaged + 6 4 0 9 6 3 6 - 7 0 7 0 | W W W . S P R I N G N Z . C O . N Z | S A L E S @ S P R I N G N Z . C O . N Z... - Page 15 LEAKAGE DETECTION - DIAGRAM This device has a leakage detection probe fitted for safety purposes. When the probe detects moisture you may notice the LED on the machine flashing accompianied by a beeping noise We recommend turning off the electricity at the power supply and calling a qualified technician to carry out this work for your safety.
-
Page 16: Data Sheet
PRODUCT DATA SHEET Spring Multitap INSTANT TAP Overview Underbench filter with integrated unit for boiling, chilled, sparkling and ambient drinking water Sparkling, Hot, Cold + Mixer, Hot, Cold, Ambient + Mixer Model Filtration Premium KDF/GAC 30, 1 Micron Filtration Cold Temperature...
