INSTRUCTION MANUAL

SLATE MATE HOOK-PORTRAIT

A-SLATE & P-SLATE

SKU

DESCRIPTION

11834

Slate Tile Roof Hook-Portrait

INTRODUCTION

Thank you for selecting and buying V-TAC Product. V-TAC will serve you the

best. Please read these instructions carefully & keep this user manualhandy for

future reference. If you have any another query, please contact our dealer or

local vendor from whom you have purchased the product. They are trained and

ready to serve you at the best.

MULTI-LANGUAGE MANUAL QR CODE

Please scan the QR code to access the manual in

multiple languages.

IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT PLEASE REACH OUT TO US AT

SUPPORT@VTACEXPORTS.COM V-TAC HOUSE, KELPATRICK ROAD, SLOUGH, BERKSHIRE, SL1 6BW, UK.

Need help?

Do you have a question about the 11834 and is the answer not in the manual?

Page 1 Slate Tile Roof Hook-Portrait INTRODUCTION Thank you for selecting and buying V-TAC Product. V-TAC will serve you the best. Please read these instructions carefully & keep this user manualhandy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased the product.
Page 2 Product Reference No. Minimum 15° Roof pitch range Timber ( 50mm minimum rafter or batten thickness) Compatible roof substructure Slates Cpmpatible roof coverings Design wind uplift resistance in (newtons) 1059.9N per bracket Solar Mounting Component reference number Pitched roof Compatibility Above roof Installation System limitations...
Page 3 Reference No. Product • • • • • Certiﬁcated Components: gasket 10mm, bolt SLATE&P-SLATE FSD-ASLATE&PSLATE...
Page 4 L OF P-SLATE Place plastic bases in the fixing Mark the rafters central After locating the battens, B1 position as shown. Hold and drill position X, make sure there & B2 and rafter R positions. through the 2 marked fixing points X is sufficient rafter timber using a 7mm tile drill enough to either side of the X.
Page 5 INSTALL OF A-SLATE Mark the rafters central Place aluminium bases in the After locating the battens, B1 fixing position as shown. Hold and position X, make sure there & B2 and rafter R positions. drill through the 2 marked fixing is sufficient rafter timber either side of the X.
