Manufactured by (DVDR) for
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
parts. which may have come loose inside the carton during shipment. Identify and count all parts and
compare with the parts list below:
No.
1
2
Hardware List
No.
A
Part List
B
Hardware
Hardware Pack Location (s) : Bolts pack inside carton
Mirror SKU # 32216233
Version #1-2023/10/02
DVDR HD1622-422C MIRROR
JCBC (M6) with Spring Washer and Washer
Allen Key (M4)
Mirror
Mirror Support Rail
ASSEMBLY INSTRUCTION
Description
Description
A
SKU# 32216233
Dimension
M6 x P1.0 x 35mm
4 x 65mm
PAGE 1 OF 2
Qty
8 Pcs
1 Pc
Qty
1 Pc
2 Pcs
