ROOMS TO GO 7450-140 Assembly Instructions

ROOMS
LWYE
QN PNL HDBD / STRG FTB / RVS RAIL
TO GO
7450 / 7452 / 7454 - 140 / 182 / 142
SKU # 32374504 / 32374528 / 32374542 / 33774503 / 33774527 / 33774541 / 32974506 / 32974520 / 32974544
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
parts. Which may have come loose inside the carton during shipment. Identify and count all parts and
compare with the hardware list below :
No.
Hardware List
No.
C
Parts List
Notes :
(*) The manufacturer does NOT provided Item 5.
ASSEMBLY INSTRUCTIONS
1
2
3
4
5
A
Footboard Storage
B
Side Rail
Wooden Slat
D
Center Rail
E
Wooden Slat Support
Description
JCBB (M8) with washer
JCBB (M8) with washer
C.S.K Screw (M4)
Allen Wrench (M5)
Screw Driver (*)
Description
MODEL : 7450 / 7452
Dimension
8 x P1.25 x 20mm
8 x P1.25 x 40mm
4 x 32mm
5 x 65mm
Page 1 of 4
/ 7454
Qty
8 Pcs
2 Pcs
24 Pcs
1 Pc
1 Pc
Qty
1 Pc
2 Pcs
12 Pcs
1 Pc
3 Pcs
